Gainsborough H285 Bedienungsanleitung
Koi Carp Pond Fountain &
Oxygenator
H285 v03: 14/11/22
Please read and retain these instructions for future reference
The Enterprise
Department
UK Head Office, 11 Bridge Street, Bishop’s Stortford, CM23 2JU
Tel: 0844 4824400*, Fax: 01279 756595
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: (+44) 1279 701269
*UK Calls cost around 7 pence per minute plus your telephone company’s network access.
Please check with your telephone supplier.
ALWAYS POSITION IN DIRECT SUNLIGHT
To easily insert stakes into the ground, it is recommended to wet the ground first. To avoid damaging garden
stakes when inserting into the ground, select a spot in soft, rock-free soil. Insert the base of the stake first
then gently insert the rest of the stake into the base. DO NOT push directly against the solar cell or the
ornament housing containing the actual LED light.
Find an ideal Place for the Solar Light.
Place the solar light in an area where it will receive direct sunlight for at least 8 hours per day. The number of
hours the light will illuminate is directly proportional to the hours of sunlight it receives. If the light is placed
in a shaded area, it will not be able to fully charge and its illumination time will be limited. Do not place the
light near other outdoor lighting like porch or streetlights. These may fool the sensor and keep the light from
coming on, or cause it to turn off automatically
Dimensions
21 x11 x14cm
Battery
Lithium 7.4V1500MA (not replaceable)
•DELIGHTFUL KOI CARP SOLAR POND FOUNTAIN WILL
GIVE YOUR POND THE PERFECT FINISHING TOUCH
•NOT ONLY IS IT A FOUNTAIN THAT SPOUTS WATER
FROM ITS MOUTH INTO YOUR POND CREATING A
RELAXING NOISE BUT IT ALSO WORKS AS AN
OXYGENATOR, ADDING VALUABLE AIR BUBBLES INTO
YOUR POND TO HELP IMPROVE THE WATER QUALITY
FOR FISH AND OTHER AQUATIC LIFE AND PLANTS IN
YOUR POND
•POWERED BY SOLAR SO NO CUMBERSOME CABLES
•COMES COMPLETE WITH PUMP AND SOLAR PANEL
•PIPE LENGTH 1.54M CABLE LENGTH 3M
•SIMPLY PERCH IT ON THE SIDE OF YOUR POND AND
POSITION THE SOLAR PANEL IN DIRECT SUNLIGHT,
CONNECT THE PUMP AND PIPE AND IT WILL GET TO
WORK!
•PUMP POWER 180 LH
IMPORTANT: DOUBLE CHECK CONTENTS BEFORE DISCARDING THE PACKAGING TO PREVENT LOSING
PARTS THAT ARE NEEDED FOR ASSEMBLY
Koi Carp Pond Fountain & Oxygenator H284 Instructions for Use
Please read and retain these instructions for future reference v002:14/11/22
The Enterprise
Department
UK Head Office, 11 Bridge Street, Bishop’s Stortford, CM23 2JU
Tel: 0844 4824400*, Fax: 01279 756595
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: (+44) 1279 701269
*UK Calls cost around 7 pence per minute plus your telephone company’s network access.
Please check with your telephone supplier.
Parts
INSTALLATION:
1. Attach the pump to the solar panel before use, plug the sprinkler head or hose into the outlet of the
pump. Make sure the water level covers the pump, but is lower than the sprinkler head.
2. Plug the power cord of the pump into the plug of the solar panel, and then fasten.
3. Position the solar panel in full sun to optimally run the pump, the backup battery will be charged from
the solar panel during normal operation and automatically run the pump without direct sunshine.
4. If required the pump can be run by the battery in times of low sunlight. Turn on the switch at located at
the back of the solar panel, if the battery is fully charged the pump will start to work immediately.
CHARGING AND OPERATION
1. Turn the switch, which is located under the solar panel, to “ON” position and
the battery will work automatically. Charge the solar product by placing it
under direct sunlight for at least 8 hours. Recommend longer charging time
for the first use. If the switch is “OFF” the battery will not work, solar panel
ensures the pump works directly.
2. The light will work automatically.
HOW TO USE: The pump/fountain function will work best when fully
charged under direct sunlight. When there is no sun, the built-in batteries will
power the fountain water and light for a minimum of a few hours.
Koi Carp Pond Fountain & Oxygenator H284 Instructions for Use
Please read and retain these instructions for future reference v002:14/11/22
The Enterprise
Department
UK Head Office, 11 Bridge Street, Bishop’s Stortford, CM23 2JU
Tel: 0844 4824400*, Fax: 01279 756595
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: (+44) 1279 701269
*UK Calls cost around 7 pence per minute plus your telephone company’s network access.
Please check with your telephone supplier.
Care and Maintenance Recommendations
1. Clean solar panel with a soft sponge every couple of weeks.
2. Make sure all connectors are still tight and no water getting in.
3. Keep the water clean during the summer keep topping up every 3 or 4 days with clean water.
4. Clean any pipes every month stop any build-up of algae which could put an extra pressure on your
pump.
5. Take out any foreign body around the pump and keep clean solar product.
6. Always make sure there is enough water for the pump to work otherwise you could damage the pump.
7. Make sure you clean the pump on a regularly bases when you are cleaning face the solar panel face
down on a towel this will stop the pump running or switch it off.
8. During the winter if you can bring it inside and give a good clean ready for next year.
BATTERIES
•Keep batteries away from children and pets.
•Do not mix used and new batteries.
•Remove the batteries if left for long periods.
•Never dispose of batteries in a fire.
•Battery disposal, spent or expired batteries must be properly disposed of and recycled in compliance
with local regulations. For detailed information, contact your local authority.
•Follow the battery manufacturer’s safety, usage, and disposal instructions.
DISPOSAL
•Coopers of Stortford use recyclable or recycled packaging where possible.
•Please dispose of all packaging, paper, cartons, packaging in accordance with your local
recycling regulations.
•Plastics, polybags –Contains the following recyclable plastic.
Code & Symbol
Type of Plastic
Polyresin
Polypropylene
Commonly used for
CD’s, crisp packets, various flexible packaging,
baby bottles, sunglass lenses
Microwaveable food containers, yoghurt
pots, butter tubs, disposable plates and cups
Notes
Not often or widely recycled
Commonly recycled and collected from
household recycling bins (packaging tape
itself not recyclable but does not interfere
with cardboard)
•At the end of the product’s lifespan please check with your local
council authorised household waste recycling centre for
disposal.
