RF240V-2WP
Instruction Manual
WWW.GAMAINC.COM
Included in this Kit:
(1) RF240V-2WP Receiver
(1) 2-Button Transmitter with Light
Available accessories:
- Package of 6 A23 12V Alkaline Batteries A23-6
- 2-Button Waterproof Transmitter KF340-2WP
The RF240V-2WP is a 340MHz AC motor control, intended to be used in conjunction with a 2-Button transmitter. The
receiver can be configured for either momentary or latching operation. The unit operates on 240VAC and provides two
isolated dry contact closures. All of the electronic components are encapsulated so the receiver is capable of being
operated in harsh environments.
Momentary and Latching Operation Setup:
To place a control in momentary mode set ALL 4 dip switch settings to the OFF position. In momentary mode, the relay
output is energized as long as a transmitter button is held down. Once the button Is released, operation will cease.
To place a control in latching mode se ALL 4 dip switch settings to the ON position. Pressing the transmitter button once
will energize the relay output. Pressing the same button a second time will de-energize the relay output.
Maximum Ratings: Power for the receiver is 240VAC. The output relays are rated at 25A @ 240VAC, 1½ HP 240VAC.
Page 1 REV B 03/09/20
- Rechargeable Transmitter GKF-WPTX-2
- 2-Button Keyfob Transmitter KF340-2
- Long Range Antenna LRA340 **See PAGE 3 FOR SETUP**
- Clear Protective Transmitter Pouch ZLB-67
Programming Instructions
Each transmitter has its own unique internal address along with the data as to which button is pressed and transmitted.
The receiver needs to be programmed to respond only to the specific transmitter it is intended to operate with. The
following steps configure the receiver to operate with a particular transmitter. Up to 30 transmitters can be programmed
to one receiver. Please read the entire programming procedure before starting. When the receiver enters program
mode, all previous transmitter addresses that were programmed will be erased from the receiver's memory.
1. Locate the pushbutton labeled "PROGRAM" on the receiver. Press and hold this button until the red LED next to the
program button illuminates (approximately 3 seconds). The receiver is now in the transmitter program mode. Release
the button. At this point all previously programmed transmitter addresses are erased from the receiver's memory.
2. To configure the receiver for a latching output, go to Step 4.
3. To configure the receiver for momentary output, press and release the UP button on the transmitter and verify that the
red program LED
extinguishes and then illuminates (blinks once). Proceed to Step 5.
4. To configure the receiver for latching output, press and release the DOWN button on the transmitter and verify that
the red program LED extinguishes and illuminates (blinks once).
5. Repeat previous step for additional transmitters that will operate with this particular receiver. The red LED on the
receiver will extinguish and illuminate (blink) once for the first transmitter being programmed, twice for the second, three
times for the third, etc. The receiver will not respond to transmitters that have already been programmed. The first
transmitter that is programmed determines the receiver’s relay operating mode.
6. The receiver will return to normal mode if no transmitter buttons are pressed for 5-seconds. The red LED on the
receiver will blink rapidly, then extinguish. The receiver is now in the normal mode of operation. This completes the
programming instructions. The receiver will retain all of its programming even when power is removed.
WWW.GAMAINC.COM
Page 2 REV B 03/09/20
-AC OUT UP
-AC OUT DOWN
-AC OUT COMM
-AC IN 240VAC
-AC IN 240VAC
Program
LED
Long Range
Antenna Jack
Program
Switch
RF240V-2WP
Instruction Manual
WWW.GAMAINC.COM
Page 3 REV B 03/09/20
To Add Long Range Functionality
The remote control system is equipped with an internal antenna. The expected range in normal conditions is
approximately 100 feet. When additional range is needed, or if the control is placed locations adverse to RF signal
reception, a long range antenna can be added to the system. GAMA Electronics long range antenna, part number LRA-
340, replaces the internal antenna on the system. In normal operating conditions expected range is greater than 500 feet.
If the long range option is purchased with the system, this modification will be made prior to shipment.
To add long range functionality:
1. Plug long range antenna (Part number LRA-340) into the long range antenna jack.
2. Clip the Long Range Antenna Bypass Wire (This will deactivate the internal antenna)
NOTE: It is recommended that you cover the exposed wires with RTV silicone sealant.
NOTE: ONCE THE LONG RANGE MODIFICATIONS HAVE BEEN MADE TO THE SYSTEM THEY CANNOT
BE REVERSED.
RF240V-2WP
Instruction Manual
COM
MOTOR
RECEIVER
RF240V-2WP
240VAC MOTOR REVERSING CIRCUIT
MOTOR WIRING
240V
240V240V
240V
C
O
M
D
W
N
U
P
RECEIVER
RF240V-2WP
240VAC MOTOR REVERSING CIRCUIT
2 ON-OFF OUTPUTS
240V
240V
C
O
M
D
W
N
U
240V 240V
LOAD #1 LOAD #2
240VAC IN 240VAC IN
WWW.GAMAINC.COM
Page 4 REV B 03/09/20
Troubleshooting
All remote-control systems shipped by GAMA Electronics are 100% functionally tested just prior to shipment.
If your RF remote control system does not work out of the box, stops working or functions intermittently please take the
following steps to resolve common issues. Please note that you must be 2-3 feet away from the receiver when operating
the remote control. Operating within 2-3 feet may result in no operation or intermittent operation.
1. Replace the A23 12V Battery in the transmitter
· The remote control can activate during shipping and drain the battery that is installed in the control. We
send a replacement battery with the system if this occurs.
2. Check the voltage supply at the receiver
· The receiver is designed to function at 240VAC. Voltage on the (+) and (-) terminals on the control should
be within this range.
3. Reprogram the remote control
· If the system is non-functional try to reprogram the remote control. The program may not have taken
during the programming process or the program button may have been pressed. If the program button is
pressed the memory of the remote controls programed to the receiver are erased.
4. Listen and look for functionality on the receiver.
· The LED that is used for programming the system will illuminate when the receiver is activated. You will
also hear a “click” when the internal relays engage. If you can see the LED illuminate and you hear the
relay “click” the issue is most likely in the wiring or device being controlled.
5. Add a long-range antenna
· If the receiver is in an area that is averse to the reception of an RF signal, such as near a motor or in a
metal casing, a long-range antenna may solve the issue. Connect the antenna per the instructions on
page 3 and mount the antenna in an exposed area away from any motor.
RF240V-2WP
Instruction Manual
