Gama Sonic 214001 Bedienungsanleitung

STAINLESS STEEL

BOLLARD SOLAR LAMP

with EZ Anchor

Part#: 214001/214801

Version 1.2 Instruction Manual

US Patent #9458970

SolarLampLocation:

For optimum light duration throughout the night, it is very

important to place your solar light in a spot where it will receive

the maximum amount of direct sunlight throughout the day.

Note: For best results, the solar light must be charged on the

“ON” position for two sunny days.

page 2

Thank you for your purchase. GAMA SONIC

solar charged accent lighting eliminates the

problems associated with most solar lighting available today.

GAMA SONIC

solar charged lights are brighter and last all night with a typical solar

charge. Unique design, superior light output, and numerous installation options conﬁrm

the outstanding value of our product.

GAMA SONIC

has been recognized as a worldwide leader in the lighting industry for over

20 years. The company also offers unique multi-purpose rechargeable products that range

from party lights to emergency lighting products.

For technical assistance and more information

call our Toll-Free number:

800-835-4113 (only within the US)

visit our website or download the latest version

of your instruction manual:

www.gamasonic.com Or

www.gamasonic.com/user-guides

Please read the instruction manual carefully to obtain the best results from your purchase.

Adaptor Auger

Ground

Stop

Ring

Level Tool

Turning

Bar

page 3

1. Remove the Adaptor from the base by

unscrewing the two silver caps from the

bottom of the Bollard Pole (A).

2. Secure the Ring Assembly (B) to the Bollard

Pole (A) using the glass and twisting it

clockwise.

NOTE: If the two parts do not easily ﬁt, try

inserting the glass into the Bollard Pole at an

angle until the glass starts to thread in.

3. Insert the GS Solar LED Bulb into the Top (A)

by screwing it in clockwise.

4. Set the operation switch to one of the

following settings:

High = Brighter light output

Low = Softer light, longer duration.

5. Connect the Top (A) to the Ring Assembly

(B) by twisting clockwise.

6. The Solar light will automatically operate

from dusk to dawn.

1. Insert the Auger bit into the Adaptor and

secure it from the bottom using the four

supplied screws.

2. Place the Turning bar in the hole through

the Auger bit and begin turning the Auger

clockwise in the desired mounting location.

3. Apply downward pressure while turning

clockwise and occasionally check the level in

the Auger so it is vertical.

4. Stop turning once the Ground Stop Ring is

ﬂush with the ground.

5. Remove the turning bar and place the

assembled lamp on the Adaptor.

6. Secure the lamp with the two silver caps.

1. Using the Adaptor as a template, drill two

holes no larger than the anchors in the

desired mounting location.

2. Insert the anchors in the holes and secure

the Adaptor using the provided screws.

3. Attach the assembled lamp to the Adaptor

and secure using the silver caps.

Operation and assembly instructions.

Flat surface installation Instruction

EZ Anchor installation

TOP

RING

ASSEMBLY

BOLLARD

POLE

WARNING: GAMA SONIC®Light bulbs are not to be used

in other electrical sockets. They are low-voltage light

bulbs that are built and designed for our products only!

page4

ReplacingtheBatteries

Replacement batteries are available

at www.gamasonic.com or via our Toll free number: +1-800-835-4113

(After several years of use, the batteries may need replacing).

1. Remove the Top (A) from the Ring Assembly (B) by twisting counter clockwise.

2. Switch the lamp OFF and remove the bulb.

3. Unscrew and remove the battery compartment covers.

4. Remove the batteries and unclip the connectors.

5. Make sure the new batteries are high quality 3.2V/1000mAh Li-Ion rechargeable batteries

with a matching connector (Item# GS32V10).

6. Clip in the new batteries and install into the compartment.

7. Reassemble the lamp by reversing steps 1-3.

WARNING: Do not dispose of Li-Ion batteries in the regular trash, municipal waste stream or by

ﬁre as batteries may leak or explode. Do not open, short circuit, or mutilate batteries as injury may

occur. Preserve our environment by recycling Li-Ion batteries or disposing of them in accordance

with local, State and federal regulations. Do not mix old and new batteries.

Maintenance

Clean the solar module regularly with a damp towel to guarantee optimum performance

of the solar panel. Do not use any type of solvent for cleaning and be careful not to put too

much pressure on the module while cleaning.

Trouble Shooting

If your solar charged light does not come on at dusk despite

observance of all the instructions, please try the following steps:

1. Make sure that the solar light is not being affected by any other light source.

2. Ensure the solar light is not positioned in the shade during the day.

3. Make sure the switch in the lamp head is in the ”LOW” or "HIGH" position.

4. Check that the batteries are installed correctly.

NOTE: The performance of the solar light will vary with the time of year. It will deliver

longer duration when it has had a full day in the sun rather than a day in overcast

weather.

WINTERTIME TIPS: For optimal performance, be sure to remove any snow or debris

accumulation from solar panel(s). A solar panel free of debris will charge the batteries

much more efﬁciently.

WARNING: Please keep out of reach of children.
