GANN HYDROMETTE BL COMPACT Bedienungsanleitung

Hydromette BL Compact

assignementsreservedmulti

HYDROMETTE BL

COMPACT

Operating Instructions

Version 2.1

Hydromette BL Compact

Contents

0.1 Publication Declaration......................................................4

0.2 WEEE Directive 2002/96/EC Electrical and Electronic

Equipment Act...................................................................4

0.3 Safety Instructions.............................................................5

1Introduction.......................................................................... 8

1.1 Description.........................................................................8

1.2 Instrument Design and Key Assignments.......................... 9

1.3 Display Icons................................................................... 10

2Basic Functions................................................................. 11

2.1 Switching the Instrument On............................................ 11

2.2 Display in Measuring Mode ............................................. 12

2.3 Settings Menus................................................................ 12

2.3.1 Measuring Menu (main menu)............................ 13

2.3.2 Material Settings................................................. 14

2.3.3 Maximum Value.................................................. 15

2.3.4 Minimum Value................................................... 18

2.4 Additional Functions........................................................ 19

2.4.1 Automatic Shut-down ......................................... 19

2.4.2 Battery Monitoring .............................................. 19

2.4.3 Electrode Replacement...................................... 19

Hydromette BL Compact

3Specifications..................................................................... 20

3.1 Technical Specifications.................................................. 20

3.2 Intolerable Ambient Conditions........................................ 20

3.3 Measuring Range............................................................ 21

4Notes on Use...................................................................... 22

4.1 General Notes ................................................................. 22

4.2 Notes on Measuring Wood Moisture ............................... 22

4.2.1 Introduction......................................................... 22

4.2.2 Static Electricity.................................................. 24

4.2.3 Wood Moisture Equilibrium................................. 24

4.2.4 Fungal Growth Ranges....................................... 25

4.2.5 Moisture Ranges for Coatings............................ 25

4.2.6 Swelling and Shrinking of Wood......................... 25

4.3 Notes on Building Moisture Measurements..................... 26

4.3.1 Introduction......................................................... 26

4.3.2 Equilibrium Moisture/Balance Moisture .............. 27

4.3.3 Material not Covered by the Type Tables........... 27

5Annex.................................................................................. 28

5.1 Type Table....................................................................... 28

5.2 Wood Types Table .......................................................... 29

5.3 Comparison Graph of Humidity - Material Moisture Content

........................................................................................ 30

Introduction

Hydromette BL Compact

0.1 Publication Declaration

This publication replaces all previous versions. It may not be

reproduced or electronically processed, duplicated or distributed in

any way without the written permission of Gann Mess- u.

Regeltechnik GmbH. Subject to technical and documentary

necessary care. Gann Mess- u. Regeltechnik GmbH accepts no

liability whatsoever for errors or omissions.

GANN Mess- u. Regeltechnik GmbH, Gerlingen, 07 Nov. 2014

0.2 WEEE Directive 2002/96/EC Electrical and

Electronic Equipment Act

The packaging, battery and instrument must be disposed of in a

recycling centre in accordance with legal regulations.

The instrument was manufactured after 01.10.2009

Introduction

Hydromette BL Compact

0.3 Safety Instructions

This measuring instrument conforms to the 2004/108/EG)

(EN61010) standard and fulfils the requirements of applicable

European and national directives. Appropriate declarations and

documentation are located with the manufacturer. The user must

read these operating instructions in order to guarantee problem-

free instrument operation and operational safety. The measuring

instrument may only be operated under the specified climatic

conditions. These conditions can be found in Section 3.1

"Specifications". In addition, this measuring instrument may only be

operated under the conditions and for the purpose it was designed

for. The operational safety and functionality are no longer

guaranteed if the instrument is modified or converted. Gann Mess-

u. Regeltechnik GmbH assumes no liability for any ensuing

damage. All risks are assumed solely by the user.

The instrument may not be stored or operated in

aggressive atmospheres or atmospheres containing

solvents!

Static electricity - At low humidities static electricity

charges with high voltages may build up, favoured by

external influences (friction during material transport, high

environmental isolation value), which may not only lead to

strong fluctuations in the measured data or negative

values, but also to the destruction of electrical

components in the instrument. Even the instrument

operator may - inadvertently - contribute to the build up of

a static charge by the clothing worn. A considerable

improvement can be achieved by the operator and the

measuring instrument being absolutely still during

measuring, as well as by earthing (contact with conducting

metal, water or heating pipes, etc.).

Introduction

Hydromette BL Compact

Frozen wood cannot be measured.

The notes and tables on allowable or common moisture

conditions in practice and general definitions given in

these instructions were taken from the technical literature.

The manufacturer therefore cannot accept any liability for

correctness. The conclusions drawn from the

measurement results depend on each user's individual

requirements and practical, professional empiricism.

Because the measuring instrument adheres to the stricter

emitted interference (EMC) Class B it may be operated in

residential and commercial environments.

The measuring instrument and any accessories used may

only be used for the purpose intended, as described in

these instructions. The instrument and accessories should

be kept away from children!

Do not measure wood or other materials on conductive

surfaces.

Gann Mess- u. Regeltechnik GmbH accepts no liability for damage

caused by non-compliance with the operating instructions or by

violation of a duty to care during transport, storage and handling of

the instrument when operating, even if this duty to care is not

specifically discussed in the operating instructions.

Introduction

Hydromette BL Compact

CAUTION: There is a danger of injury from the measuring

pins if the measuring instrument is carried without the protective

cover or other protective packaging. There is also a danger of injury

due to careless handling of the measuring pins during the

measuring procedure. Before pressing the electrode pins into walls

or ceilings, ensure that no electrical cables, water pipes or other

utilities are present using suitable means.

Introduction

Hydromette BL Compact

1 Introduction

1.1 Description

The Hydromette BL Compact is an electronic moisture meter for

various types of wood and soft building and insulating materials

with a 3-line LCD display. The measuring pins are pressed into the

respective medium and allow recording of the moisture content of

sawn timber, chipboard, veneers and wood fibre materials up to a

maximum of 25 mm thick, as well as insulating materials or normal

gypsum and mixed plasters.

Introduction

Hydromette BL Compact

1.2 Instrument Design and Key Assignments

Measuring pins

Display

Up key

Measue key

On/Off key

Down key

Introduction

Hydromette BL Compact

1.3 Display Icons

Main menu icons

Additional icons

Temperature in °C

Type Icon

Measured value on hold;

Ready to measure

Material moisture content

Min./Max. display

Battery icon

Temperature in °C

Wood types icon

Building materials icon

Type ID

Wood type icon

Building material icon

Temperature in °C

Type ID

Type icon

Temperature in °C

Measured value on

hold; ready to measure

Material moisture

content

Main menu icons

Additional icons

Battery icon

Alarm „Off“

Max. / alarm display
