Ganz ZN-DNT352XE-MIR Gebrauchsanweisung



NC3502Ver1.3

1

ZN-DNT352XE-MIRQuickUserGuide



ThismanualprovidesinstructionsforquickinstallationandbasicconfigurationofyourIPdevice.



Step1.ConnectcablestoIPdevice

ConnectrequiredcablestothedeviceincludingthepowercableandLANcable.Toseethecorrectpositions

ofallconnectors,refertothefollowingimagebelow.



Makesurethepolarityiscorrect.Incorrectconnectionmay

causemalfunctionordamagetotheIPdevice.

Caution

!PowerAdaptorConnector(DC12V)



*Modeldesignandappearancearesubjecttochangewithoutanypriornotice

ResetButton

OutputConfiguration

Switch

ClampingCore *Thisusestoprevent

electromagnetic

interference

LANCablePowerCable

ClampingCore

*Thisbuttonis

locatedunderPCB.



NC3502Ver1.3

2

Step2. InstallIPdevice



Caution



Topreventproductsfromdamaging,placethecameraonstableandnon‐vibratingsurfacesIf

thestabilityisindoubt,consultwithsafetypersonnelforreinforcements,andthenproceed

withtheinstallation.



 



1) Placetheinstallationtemplate(paper)

thatisincludedinthepackageonthe

desiredinstallationsurface.



2)Drillthreeholesincorrectpositions

basedonthetemplatepaper,andinsert

anchorblocksintotheholes.



3)Placethewaterproofsiliconbandonthe

bottomplateofthedeviceandmakeit

alignwithscrewholes.



4)Placethecamerabodytothe

installationsurfaceandmatchthree

alignmentholeswiththreeanchorblocks.

Thentightenthesurfaceanchorstuds.



5)Connectalltherequiredcablestothe

camera.



6)Adjustthelensposition.



7)Placethedomecoveronthemainbody

ofthecamera.Domecoverhasthree

alignmentholesthatmatchcamerabody’s

alignmentholes.



8)Onceproperlyplaced,insertscrewsinto

thethreeholesofthebodyandtighten

themup.



NC3502Ver1.3

3

Step3. Setthelensposition

1)Removethedomecover.



2)Setthelenspositionbyrotatingthecameragimbal;topan,rotatethereinforcedlowerbodyofthe

gimbal;totilt,verticallyadjustthecameragimbal.



Caution



Refrainfromcontinuouslyrotatingthecameragimbalwithexcessiveforcetoasingledirection

asitisattachedwiththeIR‐LEDcableinsidethedome.



3)Thefigureandtablebelowexplainsthelensswitchsettings.



SW1SW2SW3

PAL/NTSC TELEWIDE



SW4SW5SW6

FARNEARAuto‐

Focus

B.Topan,rotatethelower

bodyofthecameragimbal

C.Tiltthelensbyvertically

adjustingthecameragimbal

A.Toadjustlensposition,

rotatethecameragimbal



NC3502Ver1.3

4

Step4.Setupnetworkenvironment

ThedefaultIPaddressofthedeviceis192.168.XXX.XXX.UserscanidentifytheIPaddressofthedevicefrom

convertingtheMACaddress’shexadecimalnumbers,whichisattachedtothedevice.Besurethatthedevice

andPCareonasameareanetworkbeforerunningtheinstallation.



GenericIPEnvironment

IncaseofgenericprivatenetworkenvironmentwhereIPaddress192.168.XXX.XXXareused,usersmayview

thelivestreamingimagesonawebpageusingthedevice’sdefaultIPaddress:

1. Convertthedevice’sMACaddresstotheIPaddress.RefertotheHexadecimal‐DecimalConversionChart

attheendofthemanual.

(TheMACaddressofthedeviceisattachedonthesideorbottomofthedevice.)



2. StarttheMicrosoft®InternetExplorerwebbrowserandentertheIPaddressofthedevice.

3. WebstreaminganddeviceconfigurationsaresupportedthroughActiveXprogram.WhentheActiveX

installationpop‐upwindowappears,authorizeandinstalltheActiveXsetup.exe,

MACaddress=00‐13‐23‐01‐14‐B1 →IPaddress=192.168.20.177

Convertthelasttwosetofhexadecimalnumberstodecimalnumbers.



NC3502Ver1.3

5

CustomIPEnvironment

IPAdminToolisprovidedwithSDKatthefollowingSDKpath.

{SDK root}\BIN\TOOLS\AdminTool\



IPAdminToolisamanagementtool,whichautomaticallyscansallofthenetworkproductsforuserstoperform

administrativetasks,whichincludesnetworkconfigurations,firmwareupdate,devicereboot,anddevice

organizations.



Tomodifythedevice’sdefaultIPaddressforcustomizednetworkarea;



1. FindthedevicefromtheIPAdminTool’slistandhighlightthedevice’sname.



2. Right‐clickthemouseandselect“IPAddress”;IPSetupwindowappears.



3. IntheIPSetup’swindow,informationunder‘LocalNetworkinformation’displaystheuser/PC’snetwork

areainformation.ThoseinformationneedtobeincorporatedtotheIPAddress,SubnetMask,Gateway,

andDNSboxes,exceptthelast2setsofIPAddress,whicharetobetheuniquenumbersforthedevice.

Refertotheimageaboveforthesetting



4. Click‘Setup’tocompletethemodification.

PCenvironmentInfo

GivenewuniqueIPaddressin

lasttwosetsandmirrorother

informationinotherboxes



NC3502Ver1.3

6

Step5.Viewvideoonwebpage

OncethedevicehastheproperIPaddress,userscanviewthelivestreamingimagesthroughawebbrowser.

Thedefaultusernameandpasswordisroot/pass.



1. Whenthedevice’swebaddressisaccessed,thebrowseraskstoinstalltheActiveX.ClickAllow.



2. Setup.exeinstallationlinkorpop‐upwindowappears,dependsonMicrosoft®InternetExplorerversion.

Proceedwithrestofsetupinstallation.



3. Followtheinstructionsofthedialogboxesandcompletetheinstallation.Oncetheinstallationis

complete,startthewebbrowseragainandcheckifvideostreamisdisplayedinthemainviewframe.



NC3502Ver1.3

7

Rebooting

Performthefollowingprocedurestoresetyourdevice:

1. PresstheResetbuttonfor2seconds.

2. ThepowerLEDturnstoredandWaitforthesystemtoreboot.

ResettingtotheFactoryDefaultSettings

Ifyouresetyourdevicetothefactorydefaultsetting,allparametersincludingtheIPaddresswillbeinitialized.

FortheFactoryDefaultreset:

1. Pressresetbuttonandholdfor5seconds..

2. ReleasethebuttonwhenthegreenPowerLEDblinksat150msinterval.

3. ThepowerLEDbuttonturnstoredandwaitforthesystemtoreboot.



MoreInformation

Tolearnmoreaboutusingotherfeaturesofyourdevices,refertothemanual,whichisavailableontheSDKat

thefollowingpath.

{SDK root}\DOC\



NC3502Ver1.3

8

Hexadecimal-DecimalConversionTable

RefertothefollowingtablewhenyouconverttheMACaddressofyourdevicetoIPaddress.



HexDecHexDec HexDec Hex Dec Hex Dec HexDecHex Dec

0025374A746F111 94148 B9185DE222

1126384B7570112 95149 BA186DF223

2227394C7671113 96150 BB187E0224

3328404D7772114 97151 BC188E1225

4429414E7873115 98152 BD189E2226

552A424F7974116 99153 BE190E3227

662B43508075117 9A154 BF191E4228

772C44518176118 9B155 C0192E5229

882D45528277119 9C156 C1193E6230

992E46538378120 9D157 C2194E7231

0A102F47548479121 9E158 C3195E8232

0B11304855857A122 9F159 C4196E9233

0C12314956867B123 A0160 C5197EA234

0D13325057877C124 A1161 C6198EB235

0E14335158887D125 A2162 C7199EC236

0F15345259897E126 A3163 C8200ED237

101635535A907F127 A4164 C9201EE238

111736545B9180128 A5165 CA202EF239

121837555C9281129 A6166 CB203F0240

131938565D9382130 A7167 CC204F1241

142039575E9483131 A8168 CD205F2242

15213A585F9584132 A9169 CE206F3243

16223B59609685133 AA170 CF207F4244

17233C60619786134 AB171 D0208F5245

18243D61629887135 AC172 D1209F6246

19253E62639988136 AD173 D2210F7247

1A263F6364100 89137 AE174 D3211F8248

1B27406465101 8A138 AF175 D4212F9249

1C28416566102 8B139 B0176 D5213FA250

1D29426667103 8C140 B1177 D6214FB251

1E30436768104 8D141 B2178 D7215FC252

1F31446869105 8E142 B3179 D8216FD253

203245696A106 8F143 B4180 D9217FE254

213346706B107 90144 B5181 DA218FF255

223447716C108 91145 B6182 DB219

233548726D109 92146 B7183 DC220

243649736E110 93147 B8184 DD221


