Ganz ZN-YH305 Bedienungsanleitung

Warning Before Installation

Contact your distributor when such

cases happen.

Power off the IP Camera as

soon as it is found smoking or

smelt unusual.

Do not place the IP Camera

around the heat sources, such

as television or oven.

Keep the IP Camera away

from direct sunlight.

Keep the IP Camera away

from water. If the IP

Camera is wet, power off

immediately.

Refer to your user's

manual for the operating

temperature.

Do not place the IP Camera

in high humid environments.

Contact your distributor when such

cases happen.

Do not place the IP Camera on

unsteady surfaces.

Do not disassemble the IP

Camera.

Do not insert any object

into the IP Camera, such as

needles.

Do not touch the IP Camera

when it's lightening.

Do not drop the IP Camera.

Camera stand

ZN-YH305

Quick installation guide Warranty card

Power adapter

Software CD

Check Package Contents

Front panel

Manual focus ring

MIC

Internal ring screw

MIC In

Power cord socket

Audio out

General I/O

terminal block

Indented

reset button

Ethernet 10/100

RJ45 socket

Back panel

Up cover

Status LED

Physical Description

Install your IP Camera in Ethernet network

1. If you have external

devices such as sensors

and alarms, make

connection from general

I/O terminal block.

3. Finally, connect power

cord to a power outlet.

2. Use Ethernet cable to make

connection from Ethernet 10/100

RJ45 socket to the hub.

＊Use Category 5 Cross Cable when

IP Camera is directly connected to

PC.

Make Connections

001CB83

RoHS

Pat. 6,930,709

IP Camera

Model No:ZN-YH305-A

Note the serial number from the label on the unit.

This serial number is same as Ethernet address,

for example: 001CB8300052=00-1C-B8-30-00-52

001CB83

RoHS

Pat. 6,930,709

IP Camera

Model No:ZN-YH305-A

Assign IP Address

Assign IP address

Using Installer program

1. Run the "Installation Wizard" under the Software Utility directory from software CD.

2. The program will search the GANZ Video receivers, Video servers or IP cameras

on the same LAN.

00-1C-B8-30-00-52

3.After searching, the main installer

window will pop up. Click on serial

number that matches the one you

just noted from previous page.

4.Click "Link to selected device(s)" to

connect the Internet Explorer to the

IP Camera.

For further setup, please check the user's manual on the software CD.

The Internet Explorer Connects to the IP Camera
