Magnum 6K8-Series

Industrial Field Switch

Hardware Installation

and

User Guide

Magnum 6K8-Series Industrial Field Switch Installation & User Guide (03/06)

www GarrettCom com

Magnum



6K8-Series

Industrial Field Switch

Hardware

Installation and User Guide

Part #: 84-00160 (Rev. A)

Trademarks

Ethernet is a trademark of Xerox Corporation

NEBS is a trademark of Telcordia Technologies

UL is a registered trademark of Underwriters Laboratories

GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a

registered trademark of GarrettCom, Inc.

Important: The Magnum 6K8-Series Industrial Field Switch contains no user

serviceable parts. Attempted service by unauthorized personnel shall render all

warranties null and void. If problems are experienced with Magnum 6K8-

Series Switch products, consult Section 6, Troubleshootings, of this User

Guide.

be reproduced without prior written permission from GarrettCom, Inc.

Printed in the United States of America.

Magnum 6K8-Series Industrial Field Switch Installation & User Guide (03/06)

www GarrettCom com

Contacting GarrettCom, Inc

Please use the mailing address, phone and fax numbers and email address listed below:

GarrettCom, Inc.

47823 Westinghouse Dr.

Fremont, CA 94539-7437

Phone (510) 438-9071

Fax (510) 438-9072

Website: http://www.GarrettCom.com

email [email protected]

Federal Communications Commission

Radio Frequency Interference Statement

This equipment generates, uses and can radiate frequency energy and if not

installed and used properly, that is in strict accordance with the manufacturer's

instructions, may cause interference to radio communication. It has been tested and

found to comply with the limits for a Class A computing device in accordance with the

specifications in Subpart J of Part 15 of FCC rules, which are designed to provide

reasonable protection against such interference when operated in a commercial

environment. Operation of this equipment in a residential area is likely to cause

interference, in which case the user, at his own expense, will be required to take

whatever measures may be required to correct the interference.

Canadian Emission

This Class A digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Cet appareil respecte toutes les exigences du Réglement sur le matériel du

Canada. Cet appareil est Classe A..

Magnum 6K8-Series Industrial Field Switch Installation & User Guide (03/06)

www GarrettCom com

Table of Contents........................................................................... Page

1.0

SPECIFICATIONS ............................................................................... 2

1.1

Technical Specifications ...................................................................... 2

1.2

Ordering Information........................................................................... 5

2.0

Introduction............................................................................................ 7

2.1

Inspecting the Package and Product .................................................... 7

2.2

Product Description - Magnum 6K8-Series (6K8) .............................. 8

2.2.1a

Magnum 6K8-Series, Industrial Field Switch.............................. 9

2.2.2

Eight-port SFF fiber modules 100Mb fiber ............................... 11

2.2.3

Eight-Port Copper Module, 6K8-RJ45 ...................................... 12

2.2.4

Six-Port “4 + 2”Combo Modules, fiber

100Mb ST or SC

............ 12

2.2.5

Four-Port 10 Mb and 100Mb mm Fiber ST Modules .............. 13

2.2.6

Gigabit (1000Mbps) port modules............................................. 14

2.2.7

Packet Prioritization, 802.1p QOS............................................. 14

2.2.8

Frame Buffering and Flow Control............................................ 15

2.2.9

Managed Network Software for Magnum 6K8-Series .............. 16

2.3

Features and Benefits......................................................................... 17

2.3

Features and Benefits......................................................................... 17

2.4

Applications ....................................................................................... 18

3.0

Installation............................................................................................ 22

3.1

Locating Magnum 6K8-Series Switches............................................ 22

3.2

Connecting Ethernet Media ............................................................... 23

3.2.1

Connecting Fiber Optic ST-type, “twist-lock”........................... 23

3.2.2

Connecting Fiber Optic SC-type, "Snap-In".............................. 24

3.2.3

Connecting Single-Mode Fiber Optic ........................................ 24

3.2.4

Connecting Twisted Pair Unshielded or Shielded .................... 24

3.2.5

Connecting Twisted Pair Unshielded or Shielded ..................... 25

3.2.6

Connecting Gigabit Media Using GBICs .................................. 25

3.3

DIN-Rail Mounting............................................................................ 25

3.3.1

Installing DIN-RAIL variable brackets on Magnum 6K8 ......... 27

3.3.2

Mounting Dimensions for 6K8 with metal brackets .................. 29

3.4

Powering the Magnum 6K8-Series Industrial Field Switch .............. 30

3.5 Alarm Contacts for monitoring internal power, and Software Traps.... 31

3.6

6K8-Series Port Module (6KPMV) Installation ................................ 31

3.6.1 Preparation for Installing and Removing 6KPMVs from 6K8’s ...... 32

3.6.2

Installing 6KPM Cards in the Magnum 6K8-Series .................. 34

3.6.3

Removing 6KPM Cards ............................................................. 37

3.7

Connecting a Management Console Terminal to Magnum 6K8........ 38

3.7.1

RS-232 (DB-9) Console Com port (Serial port) pin assignments.39

4.0

OPERATION....................................................................................... 40

4.1

Switching Functionality ..................................................................... 40

4.2

Dual LEDs

Status

on TOP and Front of the 6K8-Series unit ............. 41

4.3

Auto-Cross(MDIX) and Auto-negotiation, for RJ-45 ports............... 41

Magnum 6K8-Series Industrial Field Switch Installation & User Guide (03/06)

www GarrettCom com

4.4

Flow-control, IEEE 802.3x Standard................................................. 43

4.5

Power Budget Calculations for Magnum 6K8-with Fiber Media ...... 43

5.0

Introduction - Magnum 6K8 Industrial Field Switch Port Modules45

5.1

Inspecting the Package and Product .................................................. 45

5.2

6KPMV Module Description............................................................. 45

5.2.1

6KP6-RJMST, FX-ST “twist lock” Combo Module ................. 46

5.2.1a

6KP6-RJ10ST, mm FX-ST “twist lock” Combo Module.......... 46

5.2.1b

6KP4-F10ST, multi-mode FX-ST “twist lock” Module ........... 47

5.2.1c

6KP4-FLSTFX,multi-mode FX-ST “twist lock” Module.......... 47

5.2.2. 6KP6-RJMSC multi-mode FX-SC “snap-in” Fiber connector ........ 48

5.2.3

6KP6-RJSSC single-mode FX-SC-type, “snap-in” connector... 48

5.2.4

6KP6-RJSSCL single-mode FX-SC-type, “snap-in” connector 49

5.2.4a

6KP6-RJ10ST multi-mode FL-ST-type, “twist-lock” connector49

5.2.5 6KP8-MTRJ, small-Form-factor..................................................... 50

5.2.5a 6KP6-MT10ST, MTRJ Small-Form-Factor ST-Fiber port.......... 50

5.2.6

6KP8-45MT, MTRJ Small-Form-Factor ................................... 51

5.2.7

6KP8-MLC, Small-Form Factor ............................................... 51

5.2.8

6KP8-45LC, LC small-form factor ............................................ 52

5.2.9

6KP8-RJ45 (Twisted Pair), 10/100Mb 8-Port .......................... 52

5.2.10

6KP8-45-2MT, multi-mode FX , MTRJ Small-Form-Factor .... 53

5.2.10a

6KP8-45-2LC, single-mode FX , LC Small-Form-Factor ..... 53

5.2.11

GBIC-SXSC Gigabit fiber(1000Mb)multi-mode SC Connector54

5.2.11a

GBIC-LXSC Gigabit fiber multi-mode SC Connector .......... 55

6.0

TROUBLESHOOTING...................................................................... 56

6.1

Before Calling for Assistance ............................................................ 56

6.2

When Calling for Assistance ............................................................. 57

6.3

Return Material Authorization (RMA) Procedure ............................. 57

6.4

Shipping and Packaging Information................................................. 58

APPENDIX A: WARRANTY INFORMATION......................................... 58

APPENDIX B : Internal DC Power Supply Options.................................... 58

APPENDIX C: Internal DC Dual-Source Power Option............................. 61

Revisions

03/06: Minor update on

10/05 : Initial Release, Rev A

09/05 : Draft of Initial Release, Rev A

Magnum 6K8-Series Industrial Field Switch Installation and User Guide 03/06)

www GarrettCom com

THE MAGNUM LINE

Ethernet connectivity products

"Designed and Manufactured in the USA"

Overview

GarrettCom, Inc. offers the premium-quality Magnum



line of Ethernet LAN

connectivity products with industry-standard functionality and built-in fiber

configurability. Magnum products are designed for use in demanding Carrier

Class, Industrial Grade and OEM applications where reliability is a primary

consideration.

6K-Series Managed Fiber Switches, MODULAR- Gigabit, 100 and 10 Mbps, fiber and

copper ports, mix-and match. Features SFF fiber and DC power in 1U units.

Edge SwitcHEs, Economical 6 port 10/100 and a combo of fiber+copper, provide an

effective solution for Industrial and outdoor environment.

POE POWER SOURCE SWITCH, 4 10/100 Power source switch to provide power,

data, and voice through RJ-45 ports.

Converter and convenient switches, 4 port 10/100 compact & economical switcehs and

3-port (2 10/100 and one fiber 10 or 100Mbps) converter switches for temperature

uncontrolled locations.

4K-Series Switches, 100 and 10 Mbps, copper ports with optional fiber port, with auto-

negotiating full switching performance.

Quad-Series Fiber Switches, MODULAR- 100 & 10Mbps, fiber and copper ports,

mixed-speed and mixed-media types, full switching performance.

“Outdoor” Ethernet Switch, for temperature uncontrolled locations

6 10/100 and 2 100Mb fiber ports, can be connected in strings

Mixed-Media Fiber Hub, 16-port Stackable,10/100 auto-sensing

Dual Speed 8-port and 16-port Stackables, 10/100 auto-sensing

Stackable Hubs, SNMP Optional

10Mb series(12/24 ports RJ-45), w/ optional port modules

Personal Switches, 10/100Mb

8 port dual speed, Auto-negotiable with fiber option

Personal Hubs, 100Mb or 10/100Mb

8-port, with two switched ports (1 fiber built in)

Personal Hubs, 10Mb series

8-port + AUI, stackable to 5 high, + optional BNC of fiber port

8 or 9-port and 4 or 5-Port Personal Hubs, w/ man. up-link sw.

Media Converters, 10Mb and 100Mb series

All media combinations, incl. fiber ST, SC, mm., single mode

The “X-line” of configurable MiXed Media products:

Stackable Concentrators, SNMP optional, 13-Ports

Mini-Concentrators, 7 Ports, Repeaters, 2-Ports

Repeater Port Modules (RPMs),6 types for Ethernet media

Bridge Port Modules (BPMs), 4 types, for segment isolation

Transceivers, 10Mb series Mini-Transceivers and Coax Models

Mar., 06

Magnum 6K8-Series Industrial Field Switch Installation and User Guide 03/06)

www GarrettCom com

1.0 SPECIFICATIONS

1.1 Technical Specifications

Performance

Filtering / Forwarding Rate:

Ethernet(10Mb):14,880 pps

Fast Ethernet(100Mb): 148,800 pps

Gigabit Ethernet(1000Mb): 1, 488,000 pps

Switching Processing Type: Store and Forward with IEEE 802.3x full-

duplex flow -control, non-blocking

Data Rate: 10Mbps,100Mbps and 1000Mbps

Address Table Capacity: 4K node, self-learning with address aging

Packet buffer size : 240KB for 10/100 and 120KB for 1000Mb

Latency: 5 s + packet time (100 to 100Mbps)

15 s + packet time (10 to 10 Mbps, and 10 to 100Mbps)

Network Standards and Compliance, hardware

Ethernet V1.0/V2.0 IEEE 802.3: 10BASE-T,

IEEE 802.3u: 100Base-TX, 100BASE-FX

IEEE 802.3z: 1000BASE-TX Ethernet (Auto-Negotiation)

IEEE 802.3ab: 1000BASE-TX Ethernet

IEEE 802.1p: Priority protocol

IEEE 802.1d: Spanning tree protocol

IEEE 802.1q: VLAN Tagging

IEEE 802.3x: Flow Control

Maximum 10 Mbps Ethernet Segment Lengths

Unshielded twisted pair - 100 m (328 ft)

Shielded twisted pair - 150 m (492 ft)

10BASE-FL multi-mode fiber optic - 2 km (6,562 ft)

10BASE-FL single-mode fiber optic - 10 km (32,810 ft)

Maximum Standard Fast Ethernet Segment Lengths:

10BASE-T (CAT 3, 4, 5 UTP) - 100 m (328 ft)

100BASE-TX (CAT 5 UTP) - 100 m (328 ft)

Shielded twisted pair - 150 m (492 ft)

100BASE-FX, half-duplex, multi-mode - 412 m (1350 ft)

100BASE-FX, full-duplex, multi-mode - 2.0 km (6,562 ft)

100BASE-FX, half-duplex, single-mode - 412 m (1350 ft)

100BASE-FX, full-duplex, single-mode - 20.0 km (66K8-Series ft)

100BASE-FX, full-duplex, Long Reach - 40.0 km (122K ft)

Maximum Standard Gigabit Ethernet Segment Lengths:

1000BASE-T (CAT5e or higher is recommended) - 100 m (328 ft)

1000BASE-SX, full-duplex, multi-mode(62.5m cable) - 220m

1000BASE-SX, full-duplex, multi-mode(50m cable) - 550m

1000BASE-LX, full-duplex, single-mode(62.5m cable) -5Km

Fiber Multi-mode connector types supported:

Fiber Port, ST-type (twist-lock):Fiber multi-mode, 10Mb 10BASE-FL

Fiber Port, MTRJ-type (plug-in):SFF Fiber multi-mode100BASE-FX

Fiber Port, SC-type (snap-in):Fiber optic multi-mode, 100BASE-FX

Fiber Port, ST-type (twist-lock): Fiber optic m.-mode, 100BASE-FX

Fiber Port, 1000BASE-FX, GBIC modules

Magnum 6K8-Series Industrial Field Switch Installation and User Guide 03/06)

www GarrettCom com

Fiber Single-mode connector types:

Fiber Port, SC-type: Fiber optic single-mode, 100BASE-FX

Fiber Port, LC-type Fiber optic SFF single-mode, 100BASE-FX

Fiber Port, 1000BASE-FX, GBIC modules

LEDs: Per Port (one set at the port, one set on rear top)

LK: Steady ON when media link is operational

ACT: ON with receiver port activity

FDX/HDX: ON = Full-Duplex Mode

OFF = Half-Duplex Mode

100/10: ON = 100Mbps speed

OFF = 10 Mbps

Operating Environment

Ambient Temperature:

-40to 140F (-40to 60C) for UL60950 and Component Parts rating

-60to 205F (-50to 95C) for IEC 60068 Type Test short term rating

Storage Temperature: -60to 210F (-50to 100C)

Ambient Relative Humidity: 5% to 95% (non-condensing)

Altitude: -200 to 13,000 ft. (-60 to 4000m)

Conformal Coating (humidity protection) option: Request quote

Alarm Relay Contacts

One NC indicating internal power, one NC software controllable

Packaging

Enclosure: Rugged High strength sheet metal.

Dimensions: 9.8 in. H x 5.90 in. W x 3.70 in. D

24.9 cm H x 15.0 cm W x 9.4 cm D

Cooling method: Convection, fully –enclosed elongated dual-cavity case

used as heat-sink. designed for vertical mounting, no fans

Weight: 2.1 lbs. (0.95 kg)

Management Console connector

DB-9 for RS-232 “null-modem” cable (sometimes called an X-modem cable)

Power Supply (Internal)

AC Power Connector: IEC-type, male recessed at rear of chassis,

Input Voltage: 100 to 240 VAC (auto-ranging)

Input Frequency: 47 to 63 Hz (auto-ranging)

Power Consumption:

25 watts typical (for a fully loaded fiber model)

15 watts typical (for a 8-port copper only model)

Magnum 6K8-Series Industrial Field Switch Installation and User Guide 03/06)

www GarrettCom com

DC Power Supply (Options)

-48VDC Power Input Voltage : -36 to -70 VDC

24VDC Power Input Voltage : 18 to 36VDC

125VDC Power Input Voltage : 88 to 300VDC

5VDC Power Input Voltage : (+) or (-) 5%

Std. Terminal Block : “ -, GND, + ”

Power Consumption: same as for AC models, see above

For DC internal power supplies at –48VDC, 24VDC and 125VDC,

including Dual Source options (

for continuity of operation when either of the

DC input sources are interrupted)

, see Appendices B and C.

Per-port MDI or MDIX on RJ-45

The copper daughter board has MDI-MDIX Auto-crossover on all the RJ-45

ports., and eliminate the use of cross-over cable between the devices. Also

port-specific user settings (such as FDX or HDX, copper 10/100 speed) can

be fixed using software commands.

Mountings:

Vertical mounting only Suitable for wall or DIN-Rail mounting

Agency Approvals

Magnum 6K8

UL listed (UL60950), cU, CE

Emissions meet FCC Part 15 Class A

IEEE P1613 Environmental Standard for Electric Power Substations

IEEE 61850 EMC and Operating Conditions, class C for Electric Power

Substations

NEMA TS-2 and TEES for traffic control equipment

Note: These products are tested and approved under IEC61850 for use in Class

C sheltered locations where neither temperature nor humidity are controlled.

The equipment needs to be protected against solar radiation, rainfall, other

precipitations and wind. UL has not approved these products for Annex-T

outdoor use.

Warranty: Three years, per UL 60950 temperature rating Made in USA

[email protected]

for details.

Magnum 6K8-Series Industrial Field Switch Installation and User Guide 03/06)

www GarrettCom com

1.2 Ordering Information

Magnum Industrial Field Switch (8 ports max)

MODEL DESCRIPTION

Magnum 6K8 -Managed Industrial Field Switch, base unit for vertical mounting.

Worldwide AC power. May be configured with a selection of 10/100/1000 fiber and

copper port connector types, 8 total ports max. for 10/100Mbps or 2 ports maxm for

Gigabit ports. Two metal brackets for vertical wall or panel mounting. Wire speed

filtering and forwarding across all ports, 802.3x flow control, 802.1p priority packet

processing, self-learning 4K-node address table, large 240KB packet buffers for 10/100

and 120KB for 1000Mb. For licensed managed networks software (MNS-6K and S-ring),

See separate data sheets.

Magnum 6K8 -24VDC: Same as 6K8 except the power input is 24VDC

Magnum 6K8 -5VDC: Same as 6K8 except the power input is regulated 5VDC & fused

Magnum 6K8-48VDC: Same as 6K8 except the power input is –48VDC

Magnum 6K8-125VDC: Same as 6K8 except the power input is 125VDC

Configuration Options:

Each Magnum 6K8 base unit has one port module slot which can be equipped with

one of the following single or multi-mode fiber, copper, 1000, 100 or 10Mbps modules.

Magnum 6K8 Port Modules

6KP8V-RJ45 TP Module, with 8x10/100Mbps auto-negotiating RJ-45 ports

6KP8V-MTRJ SFF Fiber module, with 8x100Mb mm FX MT-RJ connectors

6KP8V-MLC SFF Fiber module, with 8x100Mbps mm FX LC connectors

6KP8V-SLC SFF Fiber module, with 8x100Mbps single-mode FX LC connectors

6KP4V-FXSC “2+2” 100Mb Fiber module, with 4x100Mb 2km FX SC connectors

6KP4V-FXST “2+2” 100Mb Fiber module, with 4x100Mb 2km FX ST connectors

6KP4V-F10ST “2+2” 10Mb Fiber module, with 4x10Mb 2km FL ST connectors

6KP4V-FLSTFX “2+2” ST Fiber module, with 2x100Mb & 2x10Mb ports, 2km

6KP8V-45-2MT “6+2” module, with 6xRJ-45 ports and 2x100Mb 2km FX MTRJ

6KP8V-45-2SLC “6+2” module, with 6xRJ-45 ports and 2x100Mb s.m 15km FX LC

6KP8V-45MT “4+4” module, with 4xRJ-45 ports and 4x2km mm FX MTRJ

6KP8V-45MLC “4+4” module, with 4xRJ-45 ports and 4x2km mm LC connectors

6KP8V-45SLC “4+4” module, with 4xRJ-45 ports and 4x2km single mode LC

6KP6V-RJMST “4+2” module, with 4xRJ-45 ports and 2x2km mm FX SC

6KP6V-RJMSC “4+2” module, with 4xRJ-45 ports and 2x2km mm FX ST

6KP6V-RJSSC “4+2” module, with 4xRJ-45 ports and 2x20km single.mode FX SC

6KP6V-RJSSCL “4+2” module, with 4xRJ-45 ports and 2x40km single mode FX SC

6KP6V-MT10ST “4+2” module, with 4xMTRJports and 2x10Mb 2km FL ST

6KP6V-RJ10ST “4+2” module, with 4xRJ-45 ports and 2x10Mb 2km FL ST
