GarrettCom Magnum 6K16-Series Bedienungsanleitung

www GarrettCom com

Corporate Headquarters

GarrettCom, Inc.

47823 Westinghouse Dr.

Fremont, CA 94539-7437

Phone (510) 438-9071

Fax (510) 438-9072

Website: http://www.GarrettCom.com

email support@garrettcom.com

Magnum 6K16-Series

Managed Fiber Switch

Hardware

Installation and User Guide

num 6K16V mounted verticall

Two 6K16s mounted side-

-side on Tra

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)

www GarrettCom com

Magnum



6K16-Series

Managed Fiber Switch

Hardware

Installation and User Guide

Part #: 84-00136 (Rev. B)

Trademarks

Ethernet is a trademark of Xerox Corporation

NEBS is a trademark of Telcordia Technologies

UL is a registered trademark of Underwriters Laboratories

GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a

registered trademark of GarrettCom, Inc.

Important: The Magnum 6K16-Series Managed Fiber Switch contains no

user serviceable parts. Attempted service by unauthorized personnel shall

render all warranties null and void. If problems are experienced with Magnum

6K16-Series Switch products, consult Section 6, Troubleshootings, of this User

Guide.

of this publication may be reproduced without prior written permission from

GarrettCom, Inc.

Printed in the United States of America.

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)

www GarrettCom com

Contacting GarrettCom, Inc

Please use the mailing address, phone and fax numbers and email address listed below:

GarrettCom, Inc.

47823 Westinghouse Dr.

Fremont, CA 94539-7437

Phone (510) 438-9071

Fax (510) 438-9072

Website: http://www.GarrettCom.com

email [email protected]

Federal Communications Commission

Radio Frequency Interference Statement

This equipment generates, uses and can radiate frequency energy and if not

installed and used properly, that is in strict accordance with the manufacturer's

instructions, may cause interference to radio communication. It has been tested and

found to comply with the limits for a Class A computing device in accordance with the

specifications in Subpart J of Part 15 of FCC rules, which are designed to provide

reasonable protection against such interference when operated in a commercial

environment. Operation of this equipment in a residential area is likely to cause

interference, in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Canadian Emission

This Class A digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Cet appareil respecte toutes les exigences du Réglement sur le matériel du

Canada. Cet appareil est Classe A..

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)

iii

www GarrettCom com

Table of Contents.............................................................................. Page

1.0

SPECIFICATIONS ............................................................................... 1

1.1

Technical Specifications ...................................................................... 1

1.2

Ordering Information........................................................................... 4

2.0

Introduction............................................................................................ 8

2.1

Inspecting the Package and Product .................................................... 8

2.2

Product Description - Magnum 6K16-Series (6K16/6K16V) ............. 9

2.2.1a

Magnum 6K16V, Managed Fiber Switch .................................. 10

2.2.1b

Magnum 6K16, Managed Carrier Class Switch ........................ 11

2.2.1c

Magnum 6K16-Series family (6K16 and 6K16V), At a glance. 12

2.2.2

Eight-port SFF fiber modules , 100Mb fiber ............................. 13

2.2.3

Eight-Port Copper Module, 6K8-RJ45 ...................................... 14

2.2.4 New PoE(Power Pass-through), model P6KP8-RJ45, 10/100Mb 8-port

.... 15

2.2.5

Six-Port “4 + 2” Combo Modules,100Mb fiber......................... 15

2.2.6

Four-Port 10 Mb and 100Mb mm Fiber ST Modules .............. 16

2.2.7

Gigabit (1000Mbps) port modules............................................. 17

2.2.8

Packet Prioritization, 802.1p QOS............................................. 17

2.2.9

Frame Buffering and Flow Control............................................ 18

2.2.10

Managed Network Software ( MNS-6K ) for Magnum 6K8-

Series 19

2.3

Features and Benefits......................................................................... 20

2.4

Applications ....................................................................................... 21

3.0

Installation........................................................................................... 25

3.1

Locating Magnum 6K16-Series Switches.......................................... 25

3.2

Connecting Ethernet Media ............................................................... 25

3.2.1

Connecting Fiber Optic ST-type, “twist-lock”.......................... 26

3.2.2

Connecting Fiber Optic SC-type, "Snap-In".............................. 26

3.2.3

Connecting Single-Mode Fiber Optic ........................................ 26

3.2.4

Connecting Twisted Pair ........................................................... 27

3.2.5

Connecting Twisted Pair............................................................ 27

3.2.6

Connecting Gigabit Media Using GBICs .................................. 28

3.3

DIN-Rail Mounting (Magnum 6K16V)............................................. 28

3.3.1

Mounting Dimensions for 6K16Vwith metal brackets .............. 30

3.3.2

Rack-mounting optionS for Telco and ETSI Standard .............. 31

3.4

Powering the Magnum 6K16-Series Managed Fiber Switch............. 32

3.5 Alarm Contacts for monitoring internal power, and Software Traps.... 32

3.6

6K16-Series Port Module (6KPM) Installation ................................. 33

3.6.1 Preparation for Installing and Removing 6KPMs............................ 33

3.6.2

Installing 6KPM Cards in the Magnum 6K16-Series ................ 35

3.6.3

Removing 6KPM Cards ............................................................. 38

3.7

Connecting a Management Console Terminal to Magnum 6K16-

Series 39

3.7.1

RS-232 (DB-9) Console Com port (Serial port) pin assignments.39

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)

www GarrettCom com

4.0

OPERATION....................................................................................... 40

4.1

Switching Functionality ..................................................................... 40

4.2

Status LEDs ....................................................................................... 41

4.3

Up-link Manual Switches set as (=) , for RJ-45 port only ................. 41

4.4

Auto-Cross(MDIX) and Auto-negotiation, for RJ-45 ports............... 41

4.5

Flow-control, IEEE 802.3x standard ................................................. 43

4.6

Power Budget Calculations for Magnum 6K16 PM’s with Fiber Media

5.0

Intro - Magnum 6K16/6K16V Managed Fiber Switch Port Modules45

5.1

Inspecting the Package and Product .................................................. 45

5.2

6KPM Module Description................................................................ 45

5.2.1

6KP6-RJMST, Combo Module.................................................. 46

5.2.1a

6KP6-RJ10ST, Combo Module ................................................. 46

5.2.1b

6KP4-F10ST, 4@10Mb multi-mode FX-ST “twist lock” Module47

5.2.1c

6KP4-FLSTFX, Module ........................................................... 47

5.2.2. 6KP6-RJMSC Fiber connector ....................................................... 48

5.2.3

6KP6-RJSSC connector ............................................................ 48

5.2.4

6KP6-RJSSCL connector.......................................................... 49

5.2.4a

6KP6-RJ10ST connector .......................................................... 49

5.2.5 6KP8-MTRJ, Small-Form-factor.................................................... 50

5.2.5a 6KP6-MT10ST, ST-Fiber port..................................................... 50

5.2.6

6KP8-45MT, FX , MTRJ Small-Form-Factor .......................... 51

5.2.7

6KP8-MLC, LC connector Small-Form Factor ......................... 51

5.2.8

6KP8-45LC, Combo factor ....................................................... 52

5.2.9

6KP8-RJ45 (Twisted Pair), 10/100Mb 8-Port .......................... 52

5.2.10

New PoE(Power Pass-through), P6KP8V-RJ45 (MDIX), 8-port

........ 53

5.2.11

6KP8-45-2MT, FX , MTRJ Small-Form-Factor........................ 54

5.2.12a

6KP8-45-2LC, single-mode FX , LC Small-Form-Factor ..... 54

5.2.13

GBIC-SXSC Gigabit fiber(1000Mb), multi-mode SC Connector55

5.2.13a

GBIC-LXSC Gigabit fiber (1000Mb), SC Connector ........... 55

5.2.14

6KM-BLNK............................................................................... 56

6.0

TROUBLESHOOTING...................................................................... 57

6.1

Before Calling for Assistance ............................................................ 57

6.2

When Calling for Assistance ............................................................. 58

6.3

Return Material Authorization (RMA) Procedure ............................. 58

6.4

Shipping and Packaging Information................................................. 59

APPENDIX A: WARRANTY INFORMATION......................................... 59

APPENDIX B : Internal DC Power Supply Options.................................... 59

APPENDIX C: Internal DC Dual-Source Power Option............................. 62

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)

www GarrettCom com

Revisions

04/06: minor updates as PoE modules option added on Sec 5.2.10/11

10/05: minor updates as MDIX support added on all RJ-45 port modules

02/05: minor updates and tweaks on LC port module

07/04 : 6K16 carrier class managed switch has been added with 6K16V

01/04 : Added Section 3.5 (Alarm Contacts) and 3.7.1 (Console Port pins)

12/03: Updated Section 3.3 “DIN-Rail”, and Appendix B “DC Power” 10/03 :

Initial Release with Rev A

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide

04/06)

www GarrettCom com

THE MAGNUM LINE

Ethernet connectivity products

"Designed and Manufactured in the USA"

Overview

GARRETTCOM, INC. OFFERS THE PREMIUM-QUALITY MAGNUM

LINE OF ETHERNET LAN CONNECTIVITY PRODUCTS WITH

INDUSTRY-STANDARD FUNCTIONALITY AND BUILT-IN FIBER

CONFIGURABILITY. MAGNUM PRODUCTS ARE DESIGNED FOR USE

IN DEMANDING CARRIER CLASS, INDUSTRIAL GRADE AND OEM

APPLICATIONS WHERE RELIABILITY IS A PRIMARY

CONSIDERATION.

6K-SERIES MANAGED FIBER SWITCHES, GIGABIT, 100 AND 10

MBPS, FIBER AND COPPER PORTS, MIX-AND MATCH. FEATURES

SFF FIBER AND DC POWER IN 1U UNITS.

4K-SERIES SWITCHES, 100 AND 10 MBPS, COPPER PORTS WITH

OPTIONAL FIBER PORT, WITH AUTO-NEGOTIATING FULL

SWITCHING PERFORMANCE.

QUAD-SERIES FIBER SWITCHES, 100 & 10MBPS, FIBER AND

COPPER PORTS, MIXED-SPEED AND MIXED-MEDIA TYPES, FULL

SWITCHING PERFORMANCE.

“OUTDOOR” ETHERNET SWITCH, FOR TEMPERATURE

UNCONTROLLED LOCATIONS

6 10/100 AND 2 100MB FIBER PORTS, CAN BE CONNECTED IN

STRINGS

MIXED-MEDIA FIBER HUB, 16-PORT STACKABLE,10/100 AUTO-

SENSING

DUAL SPEED 8-PORT AND 16-PORT STACKABLES, 10/100 AUTO-

SENSING

STACKABLE HUBS, SNMP OPTIONAL

10MB SERIES AND 100MB SERIES, BOTH W/ OPTIONAL PORT

MODULES

PERSONAL SWITCHES, 10/100MB

8 PORT DUAL SPEED, AUTO-NEGOTIABLE WITH FIBER OPTION

PERSONAL HUBS, 100MB OR 10/100MB

8-PORT, WITH TWO SWITCHED PORTS (1 FIBER BUILT IN)

PERSONAL HUBS, 10MB SERIES

8-PORT + AUI, STACKABLE TO 5 HIGH, + OPTIONAL BNC OF FIBER

PORT

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide

04/06)

www GarrettCom com

8 OR 9-PORT AND 4 OR 5-PORT PERSONAL HUBS, W/ MAN. UP-LINK

SW.

MEDIA CONVERTERS, 10MB AND 100MB SERIES

ALL MEDIA COMBINATIONS, INCL. FIBER ST, SC, MM., SINGLE

MODE

THE “X-LINE” OF CONFIGURABLE MIXED MEDIA PRODUCTS:

STACKABLE CONCENTRATORS, SNMP OPTIONAL, 13-PORTS

MINI-CONCENTRATORS, 7 PORTS, REPEATERS, 2-PORTS

REPEATER PORT MODULES (RPMS),6 TYPES FOR ETHERNET

MEDIA

BRIDGE PORT MODULES (BPMS), 4 TYPES, FOR SEGMENT

ISOLATION

TRANSCEIVERS, 10MB SERIES MINI-TRANSCEIVERS AND COAX

MODELS FEB, 05

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)

www GarrettCom com

1.0 SPECIFICATIONS

1.1 Technical Specifications

Performance

Filtering / Forwarding Rate:

Ethernet(10Mb):14,880 pps

Fast Ethernet(100Mb): 148,800 pps

Gigabit Ethernet(1000Mb): 1, 488,000 pps

Switching Processing Type: Store and Forward with IEEE 802.3x full-

duplex flow -control, non-blocking

Data Rate: 10Mbps,100Mbps and 1000Mbps

Address Table Capacity: 4K node, self-learning with address aging

Packet buffer size : 240KB for 10/100 and 120KB for 1000Mb

Latency: 5 s + packet time (100 to 100Mbps)

15 s + packet time (10 to 10 Mbps, and 10 to 100Mbps)

Network Standards and Compliance, hardware

Ethernet V1.0/V2.0 IEEE 802.3: 10BASE-T,

IEEE 802.3u: 100Base-TX, 100BASE-FX

IEEE 802.3z: 1000BASE-TX Ethernet (Auto-Negotiation)

IEEE 802.3ab: 1000BASE-TX Ethernet

IEEE 802.1p: Priority protocol

IEEE 802.1d: Spanning tree protocol

IEEE 802.1q: VLAN Tagging

IEEE 802.3x: Flow Control

Maximum 10 Mbps Ethernet Segment Lengths

Unshielded twisted pair - 100 m (328 ft)

Shielded twisted pair - 150 m (492 ft)

10BASE-FL multi-mode fiber optic - 2 km (6,562 ft)

10BASE-FL single-mode fiber optic - 10 km (32,810 ft)

Maximum Standard Fast Ethernet Segment Lengths:

10BASE-T (CAT 3, 4, 5 UTP) - 100 m (328 ft)

100BASE-TX (CAT 5 UTP) - 100 m (328 ft)

Shielded twisted pair - 150 m (492 ft)

100BASE-FX, half-duplex, multi-mode - 412 m (1350 ft)

100BASE-FX, full-duplex, multi-mode - 2.0 km (6,562 ft)

100BASE-FX, half-duplex, single-mode - 412 m (1350 ft)

100BASE-FX, full-duplex, single-mode - 20.0 km (66K16-Series ft)

100BASE-FX, full-duplex, Long Reach - 40.0 km (122K ft)

Maximum Standard Gigabit Ethernet Segment Lengths:

1000BASE-T (CAT5e or higher is recommended) - 100 m (328 ft)

1000BASE-SX, full-duplex, multi-mode(62.5m cable) - 220m

1000BASE-SX, full-duplex, multi-mode(50m cable) - 550m

1000BASE-LX, full-duplex, single-mode(62.5m cable) -5Km

Fiber Multi-mode connector types supported:

Fiber Port, ST-type (twist-lock):Fiber multi-mode, 10Mb 10BASE-FL

Fiber Port, MTRJ-type (plug-in):SFF Fiber multi-mode100BASE-FX

Fiber Port, SC-type (snap-in):Fiber optic multi-mode, 100BASE-FX

Fiber Port, ST-type (twist-lock): Fiber optic m.-mode, 100BASE-FX

Fiber Port, 1000BASE-FX, GBIC modules

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)

www GarrettCom com

Fiber Single-mode connector types:

Fiber Port, SC-type: Fiber optic single-mode, 100BASE-FX

Fiber Port, LC-type Fiber SFF single-mode, 100BASE-FX

Fiber Port, 1000BASE-FX, GBIC modules

LEDs: Per Port (one set at the port, one set on rear top) 6K16V only

Per Port (one set at the port) 6K16

LK: Steady ON when media link is operational

ACT: ON with receiver port activity

FDX/HDX: ON = Full-Duplex Mode

OFF = Half-Duplex Mode

100/10: ON = 100Mbps speed

OFF = 10 Mbps

Operating Environment

Ambient Temperature:

-40to 140F (-40to 60C) for UL60950 and Component Parts rating

-60to 205F (-50to 95C) for IEC 60068 Type Test short term rating

Storage Temperature: -60to 210F (-50to 100C)

Ambient Relative Humidity: 5% to 95% (non-condensing)

Altitude: -200 to 13,000 ft. (-60 to 4000m)

Conformal Coating (humidity protection) option: Request quote

Alarm Relay Contacts

One NC indicating internal power, one NC software controllable

Packaging

Enclosure: Rugged High strength sheet metal.

Dimensions: 9.5 in. H x 8.75 in. W x 1.75 in. D

24.1 cm H x 22.2 cm W x 4.4 cm D

Cooling method: Convection, designed for vertical mounting, no fans (6K16V)

Cooling method: fan cooling, three rear fans (6K16)

Weight: 4.21 lbs. (1.9 kg)

Management Console connector

DB-9 for RS-232 “null-modem” cable (sometimes called an X-modem cable)

Power Supply (Internal)

AC Power Connector: IEC-type, male recessed at rear of chassis,

Input Voltage: 100 to 240 VAC (auto-ranging)

Input Frequency: 47 to 63 Hz (auto-ranging)

Power Consumption:

50 watts typical (for a fully loaded fiber model)

30 watts typical (for a fully-loaded copper only model)

DC Power Supply (Options)

-48VDC Power Input Voltage : -36 to -70 VDC

24VDC Power Input Voltage : 20 to 36VDC

125VDC Power Input Voltage : 115 to 150VDC

5VDC Power Input Voltage : (+) or (-) 5%

Std. Terminal Block : “ -, GND, + ”

Power Consumption: same as for AC models, see above
