Gefen EXT-COMPAUD-CAT5-142 Bedienungsanleitung

www.gefen.com

1:2 Component

Audio Over CAT5

EXT-COMPAUD-CAT5-142

User Manual

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

1:2 Component Audio Over CAT5 is a trademark of Gefen Inc.

All trademarks are the property of their respective companies

ASKING FOR ASSISTANCE

CONTENTS

1 Introduction

2 Operation Notes

3 Features

4 Sender Panel Layout

5 Sender Panel Descriptions

6 Receiver Panel Layout

7 Receiver Panel Descriptions

8 Connecting And Operating The 1:2 Component Audio Over CAT5

9 Adjusting The Video Quality

10 Network Cable Wiring Diagram

11 Speciﬁcations

12 Warranty

Congratulations on your purchase of the 1:2 Component Audio Over CAT5. Your

complete satisfaction is very important to us.

Gefen

Gefen delivers innovative, progressive computer and electronics add-on solutions

that harness integration, extension, distribution and conversion technologies.

Gefen’s reliable, plug-and-play products supplement cross-platform computer

systems, professional audio/video environments and HDTV systems of all sizes

with hard-working solutions that are easy to implement and simple to operate.

The Gefen 1:2 Component Audio Over CAT5

The 1:2 Component Audio over CAT5 extends and duplicates your audio and

component video signals at distances of up to 1000 feet away. Remote AV

signals are received from the 1:2 Component Audio over CAT5 Sender unit, via

industry-standard CAT5 network cables.

The 1:2 Component Audio over CAT5 will extend Analog Component as well as

Analog Audio or Digital Audio via S/PDIF or TOSlink and provide two full sets

of AV signal output on the receiving end. Audio is transmitted digitally over the

CAT-5 cable and both the analog and digital audio outputs are active on the

receiver side.

How It Works

The 1:2 Component Audio CAT5 Distribution Ampliﬁer Sender unit is placed at

the source location. A standard CAT5 cable is run from the 1:2 Component Audio

over CAT5 Sender to the 1:2 Component Audio over CAT5 Receiver unit. The

1:2 Component Audio over CAT5 Receiver unit connects to your remote HDTV

component video displays, and audio inputs.

Note: Both analog and digital audio outputs are active on the receiver side when

two-channel analog audio is used. If multi-channel digital audio is used, then the

analog audio outputs will be inactive.

INTRODUCTION

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE 1:2 COMPONENT AUDIO OVER CAT5

Use only industry standard Category-5 Enhanced (CAT-5e) cable to operate• the 1:2 Component Audio Over CAT5. Cat-6 cables can also be used.

Unitwillconvertdigital audioto analogaudio andanalog audioto digitalaudio. It• willnothoweverdown-mixmultichanneldigitalaudio tracksto analog2 channel.

Please see page 8 for additional information.

Boththesending and receivingunitsmust be poweredwiththe suppliedpower• adapters for proper operation.

Field termination of CAT5e cabling must adhere to the TIA/EIA-568-B• speciﬁcation. Please see page 10 for additional information.

OPERATION NOTES

Features

Supports up to 1080p component video•

Supports analog L+R audio and multichannel digital audio via optical Toslink• or S/PDIF jacks

Simple plug-and-play installation•

Equalizations for different CAT-5 skews•

No loss of quality over long distances•

Package Includes

(1) Component Audio Over CAT5 Sender

(1) 1:2 Component Audio Over CAT5 Receiver

(1) 6 Foot 5 RCA Component Video Cable

(2) 5V DC Power Supply

(1) User’s Manual

FEATURES

Front Panel

Back Panel

4 5 62 3

SENDER PANEL LAYOUT

SENDER PANEL DESCRIPTIONS

5V DC Power Input1 Connect the included 5V DC power supply input this port. Once this has been

properly connected the power LED will become active.

3 RCA Component Input2 Connect the component source device to this input.

2 RCAAnalog Stereo Input3 Connect the source’s analog audio to this input.

SPDIF Digital Audio Input4 Connect the source’s SPDIF digital audio to this input.

Optical Digital Audio Input5 Connect the source’s optical digital audio to this input.

Power LED Indicator6 This LED will become active once the included 5V DC power supply is properly

connected.

RJ-45 Jack7 Connect the sending and receiving units together using a TIA/EIA-568-B

terminated CAT-5, CAT-5e or CAT-6 cable. See page 10.

NOTE: Only one audio input type, digital or analog, should be connected at one time.

Front Panel

Back Panel

12 3

4 5 6 7 8 9 1110 12 13

RECEIVER PANEL LAYOUT

RECEIVER PANEL DESCRIPTIONS

Brightness Trim Pot1 Use this adjustment Trim Pot to brighten/darken the output video signal. See

page 9.

Focus Trim Pot2 Use this adjustment Trim Pot to focus/blur the output video signal. See page 9.

Power LED Indicator3 This LED will become active once the included 5V DC power supply is properly

connected.

5V DC Power Input4 Connect the included 5V DC power supply input this port. Once this has been

properly connected the power LED will become active.

3 RCA Component Output 15 Connect one component display device to this output.

3 RCA Component Output 26 Connect one component display device to this output.

2 RCAAnalog Stereo Output 17 Connect this output to either the display or audio receiver.

2 RCAAnalog Stereo Output 28 Connect this output to either the display or audio receiver.

SPDIF Digital Audio Output 19 Connect this output to either the display or audio receiver.

SPDIF Digital Audio Output 210 Connect this output to either the display or audio receiver.

Optical Digital Audio Output 111 Connect this output to either the display or audio receiver.

Optical Digital Audio Output 212 Connect this output to either the display or audio receiver.

RJ-45 Jack13 Connect the sending and receiving units together using a TIA/EIA-568-B

terminated CAT-5, CAT-5e or CAT-6 cable. See page 10.
