Gefen EXT-DVIKA-HBT2 Bedienungsanleitung

EXT-DVIKA-HBT2

User Manual

Release A2

*Preferred

DVI KVM

HDBaseT Extender

w/ USB, RS-232, 2-way Audio, and POH

™

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install or place this product near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. To reduce the risk of electric shock and/or damage to this product, never handle or

touch this unit or power cord if your hands are wet or damp. Do not expose this

product to rain or moisture.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Batteries that may be included with this product and/or accessories should never be

exposed to open ame or excessive heat. Always dispose of used batteries

according to the instructions.

Important Safety Instructions

Gefen warrants the equipment it manufactures to be free from defects in material and

workmanship.

If equipment fails because of such defects and Gefen is notied within two (2) years from

the date of shipment, Gefen will, at its option, repair or replace the equipment, provided

that the equipment has not been subjected to mechanical, electrical, or other abuse or

modications. Equipment that fails under conditions other than those covered will be

repaired at the current price of parts and labor in effect at the time of repair. Such repairs

are warranted for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or tness for any particular purpose, all of

which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cables must be in their original

condition.

The information in this manual has been carefully checked and is believed to be accurate.

However, Gefen assumes no responsibility for any inaccuracies that may be contained

in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or

consequential damages resulting from any defect or omission in this manual, even if

advised of the possibility of such damages. The technical information contained herein

regarding the features and specications is subject to change without notice.

For the latest warranty coverage information, refer to the Warranty and Return Policy under

the Support section of the Gefen Web site at www.gefen.com.

iii

Warranty Information

Technical Support

(707) 283-5900 (800) 472-5555

8:00 AM to 5:00 PM Monday - Friday, Pacic Time

[email protected]

Web

http://www.gefen.com

Mailing Address

Gefen

Core Brands, LLC

c/o Customer Service

1800 S McDowell Blvd

Petaluma, CA 94954 USA

Product Registration

Contacting Gefen Technical Support

• Always make sure that this product is running the latest rmware. The Gefen

Syner-G™ Software Suite is a free downloadable application from Gefen that provides

automatic download and installation of rmware upgrades for this product.

Download the application here: http://www.gefen.com/synerg/

• This product is only compatible with Gefen Syner-G 2.1.x and later, in order to support

EDID management and rmware updates.

DVI KVM HDBaseT™ Extender w/ USB, RS-232, and POH is a trademark of Gefen, LLC.

Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation

without prior written notice.

Operating Notes

This product uses UL listed or CE-compliant power supplies.

Features and Packing List

Features

• Extends DVI, USB, RS-232, and 2-way Audio over a single CAT-5e

◦ 1080p Full HD (1920 x 1080 @ 60Hz, 4:4:4, 12-bit), up to 330 feet/100 meters

◦ 1080p Full HD (1920 x 1080 @ 60Hz, 4:4:4, 8-bit), up to 495 feet/150 meters

◦ WUXGA (1920 x 1200 @ 60Hz, 8-bit), up to 495 feet/150 meters

• Extends HDMI**, USB, RS-232, and 2-way Audio over a single CAT-5e

◦ 4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0, 8-bit), up to 330 feet/100 meters

◦ 4K Ultra HD (3840 x 2160 @ 30Hz, 4:4:4, 8-bit), up to 330 feet/100 meters

◦ 4K DCI-Cinema (4096 x 2160 @ 30Hz 4:4:4, 8-bit), up to 330 feet/100 meters

◦ 1080p Full HD (1920 x 1080 @ 60Hz, 4:4:4, 12-bit), up to 330 feet/100 meters

◦ 1080p Full HD (1920 x 1080 @ 60Hz, 4:4:4, 8-bit), up to 495 feet/150 meters

◦ WUXGA (1920 x 1200 @ 60Hz, 8-bit), up to 495 feet/150 meters

• HDMI Features Supported:

◦HDMI 2.0 up to 4K 60Hz, 4:2:0, 8-bit color

◦HDCP 2.2 and 1.4

◦12-bit Deep Color

◦ LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, DTS:X™, and DTS-HD Master

Audio™ pass-through

◦ 3DTV pass-through

◦ CEC pass-through

◦ Lip Sync pass-through

• Analog L/R Stereo Audio extension from Sender to Receiver and from Receiver to

Sender

• Receiver audio input accommodates a microphone or a line level audio source

• POH (Power Over HDBaseT™) feature provides power to Sender unit over the link

cable - only the Receiver needs external power

• Advanced EDID Management via Gefen Syner-G™ software

• Link Quality Monitoring via Gefen Syner-G™ software

• In-eld rmware update via USB, using Gefen Syner-G™ software

• Locking power connector

• 1U tall, half-rack-width enclosures can be:

◦ Surface-mounted

◦ Installed in a standard 19-inch rack using the EXT-RACK-1U-GRY rack tray

(available separately)

◦Placed on a shelf

** Use Gefen DVI to HDMI cables

vii

Packing List

The DVI KVM HDBaseT™ Extender w/ USB, RS-232, and POH ships with the items listed

below. The packing contents of the Sender and Receiver unit are listed below. If any of

these items are not present in the box when you rst open it, immediately contact your

dealer or Gefen.

• 1 x DVI KVM HDBaseT™ Extender w/ USB, RS-232, and POH - Sender unit

• 1 x DVI KVM HDBaseT™ Extender w/ USB, RS-232, and POH - Receiver unit

• 1 x 6 ft. DVI cable (M-M)

• 2 x 6 ft. 3.5mm mini-stereo cable (M-M)

• 1 x 6 ft. Dual-Link DVI cable (M-M)

• 1 x 6 ft. USB A-B cable (M-M)

• 8 x Self-Adhesive Rubber Feet

• 4 x L-Shaped Surface-Mounting Brackets

• 8 x 6mm M3 Phillips at head machine screws, 0.5mm pitch, for use with

EXT-MP-C01

• 4 x 5mm 6-32 Phillips at head machine screws, for use with EXT-RACK-1U

• 1 x 48V/1A DC power supply with locking plug

• 1 x IEC AC power cord with interchangeable connectors (US, UK, EU, AU)

• 1 x Quick-Start Guide

Features and Packing List

1080P

™

HDCP

2.2

CINEMA

DCI, 4096 x 2160, 30Hz

CINEMA

DCI, 4096 x 2160, 30Hz

60Hz, 4:2:0

Deep Color Support

viii

Table of Contents

1 Getting Started

Introduction............................................................................................................ 2

Sender Unit ................................................................................................... 2

Receiver Unit................................................................................................. 4

Installation ............................................................................................................. 7

Connection Instructions................................................................................. 7

Application Diagram ...................................................................................... 8

2 Basic Operation

LED Status .......................................................................................................... 12

Audio Connections .............................................................................................. 13

DIP Switch Conguration .................................................................................... 15

EDID Management...................................................................................... 16

EDID Lock ................................................................................................... 17

HDCP .......................................................................................................... 17

Long-Reach Mode....................................................................................... 18

RS-232 Interface ................................................................................................. 19

RS-232 Interface ......................................................................................... 19

3 Advanced Operation

Using Syner-G™ ................................................................................................. 24

Verifying the USB Driver ............................................................................. 24

Downloading an EDID................................................................................. 26

Uploading an EDID ..................................................................................... 29

Copying an EDID ........................................................................................ 31

Viewing an EDID ......................................................................................... 33

4 Appendix

Default Settings................................................................................................... 40

Sender Unit DIP Switches........................................................................... 40

Receiver Unit DIP Switches ........................................................................ 40

Updating the Firmware........................................................................................ 41

Network Cable Diagram ...................................................................................... 47

Rack Tray Installation .......................................................................................... 48

Specications ...................................................................................................... 49

Index.................................................................................................................... 51

This page left intentionally blank.
