Gefen USB-MINI Bedienungsanleitung

Mini USB

Extender

USER MANUAL

www.gefen.com

ASKING FOR ASSISTANCE

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

c/o Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

[email protected]

www.gefen.com

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

Mini USB Extender is a trademark of Gefen Inc.

ExtremeUSB is a trademark of Gefen Inc.

Macintosh is a trademark of Apple Computer Inc.

TABLE OF CONTENTS

Introduction

Operation Notes

USB Series Installation

Mini USB Extender Panel Layout

Troubleshooting

Link Cable Diagram

Warranty

Thank you for purchasing the ex•tend•it Mini USB Extender Series. Incorporating

ExtremeUSB, the new Mini USB Extender model allows users the beneﬁts of USB

technology beyond the desktop, extending your computer keyboard, mouse, trackball,

and any USB device up to 150 feet away from the location of your Macintosh or PC.

The Mini USB Extender system consists of two units: the Mini USB Extender Sender

resides next to the host computer, and the Mini USB Extender Receiver resides next to

the extended USB devices.

The Mini USB Extender signal controls the keyboard, mouse, trackball and all other

USB devices by buffering the USB signal through the send and receive line drivers and

the signal is extended by using standard Category 5 (CAT-5) cabling.

You can connect additional Mini USB Extenders to the same computer, allowing you to

access the computer from multiple locations up to 150 feet apart.

There are two versions of the Mini USB Extender, one is the Mini USB-2 and the other

is the Mini USB-1. The Mini USB-2 has a two port USB hub built in. The Mini USB-1 has

a single port USB hub built in.

Product Contents

(1) Mini USB Sender

(1) Mini USB Receiver

(1) Manual

(1) USB cable 6ft (A-B)

INTRODUCTION

OPERATION NOTES

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE MINI USB EXTENDER SYSTEM.

* The Mini USB Extender sender and receiver were designed to operate on USB type

computers. DO NOT attempt to use this equipment with any other type of device.

* Use the computer's USB port when using a local keyboard that is not extended with

the Mini USB Extender sender unit.

* Only dedicated Category 5 UTP type cable (CAT-5) is recommended for this

application (pin to pin).

* The length of cable used to connect the Mini USB Extender sender unit to the Mini

USB Extender receiver unit MUST NOT EXCEED 150 feet.

MINI USB EXTENDER SERIES INSTALLATION

1. Place the Mini USB Extender receiver unit close to the USB devices at the remote

end.

2. Connect the USB devices to the Mini USB Extender receiver unit

3. Place the Mini USB Extender sender unit close to the host computer.

4. Connect the Mini USB Extender sender unit to the Mini USB Extender receiver unit

using the desired length of CAT5 cable

6. Connect the Mini USB Extender sender unit to the host computer using the USB

cable supplied with the unit .

This connection should be made last.

MINI USB EXTENDER PANELS LAYOUT

MINI USB EXTENDER SENDER

USB In from computer

2 port USB Hub connects to USB devices

MINI USB-2 RECEIVER

MINI USB-1 RECEIVER

1 port USB Hub connects to USB devices

Device LED (green) Link LED (yellow)

Symptoms/Cause Remedy

All LEDs on Sender are off.

Cause:

The Sender unit is not receiving

power from the computer

1. Ensure that the Sender unit is connected to

a USB port on the computer

2. Check that the computer is switched on and

that the OS is running (not in Sleep mode).

Host LED on Sender is on;

Link LED on Sender is off.

Cause:

There is no connection

between the Sender and

Receiver units.

1. Ensure that a Category 5 UTP cable with

straight-through conductors is connected be-

tween the Sender and Receiver units.

2. Ensure that Category 5 cables and connec-

tors are used throughout the entire link be-

tween Sender and Receiver.

3. Check that Category 3 cable has not been

substituted.

4. Check that the cable length between Sender

and

Receiver does not exceed 50 metres.

5. Connect a short Category 5 patch cord

between the Sender and Receiver units. Re-

check the

operation of the system.

Link LED on Sender is on;

Host LED on Sender is on.

Link LED on Receiver is on;

Device LED on Receiver is off.

Cause:

a) The USB device is not connected

to Receiver.

b) The USB device is malfunctioning.

c) The computer does not recognise

the USB device.

d) The computer does not support

USB hubs.

e) The extender is malfunctioning.

1. Check that the USB device is securely con-

nected to the USB port on the Receiver unit.

2. Disconnect the Sender unit from the com-

puter.

3. Connect the USB device directly to the USB

port on the computer.

4. If the device does not operate properly, con-

sult the user documentation for the device.

5. If the device operates properly when directly

connected to the computer, connect another

full speed device (of a different type) to the

Receiver unit. Connect the Sender unit to the

computer.

6. If the second device does not operate, the

extender may be malfunctioning. Contact Ge-

fen technical support for assistance.

7. If the second device does operate properly,

the ﬁrst device may not be compatible with the

extender. Contact Gefen technical support for

assistance.

TROUBLESHOOTING

Symptom/Cause Remedies

All LEDs on both Sender and Receiver

are on but the device does not operate

correctly

Cause:

a) The USB device is malfunctioning.

b) The computer does not recognise the

USB device.

c) The extender is malfunctioning.

1. Disconnect the Sender unit from the

computer.

2. Connect the USB device directly to the

USB port on the computer.

3. If the device does not operate properly,

consult the user documentation for the

device.

4. If the device operates properly when

directly connected to the computer, con-

nect another full speed device (of a differ-

ent type) to the Receiver unit. Connect the

Sender unit to the computer.

5. If the second device does not oper-

ate, the extender may be malfunctioning.

Contact Gefen technical support for assis-

tance.

6. If the second device does operate prop-

erly, the ﬁrst device may not be compatible

with the extender. Contact Gefen technical

support for assistance.

TROUBLESHOOTING

LINK CABLE - WIRING DIAGRAM

White/Blue

Blue

White/Green

Brown

White/Brown

Green

White/Orange

Orange

RJ-45 Jack

1818
