RS-232 Extender

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

C/O Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

RS232 Extender is a trademark of Gefen Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Features

Panel Descriptions

Connecting and Operating the RS232 Extender

Speciﬁcations

Warranty

Congratulations on your purchase of the Gefen RS232 extender.

Your complete satisfaction is very important to us. Gefen’s line of KVM (Keyboard Video

& Mouse), ADC, DVI, USB, switches, extenders, converters and splitters is designed

to make computer use more comfortable, more productive and less expensive. KVM

switches allow access to multiple computers from a single keyboard,while the extenders

give the user control over a computer up to 330 feet away from the work area.

Gefen products offer solutions for noise, space and security concerns,data center con-

trol, information distribution, conference room presentation, and school and corporate

training environments.

Our Commitment

Gefen will always offer the ﬁnest quality product at the best possible price. Included in

that price is a lifetime of free support from a team of outstanding engineers.

The Gefen RS232 extender allows RS232 devices to be extended up to 1000 feet using

a CAT-5 cable. The RS232 extender send unit is connected directly to the computer with

the supplied RS232 cable. A CAT-5 cable is used to connect the RS232 extender send

unit to the RS232 extender receive unit. The RS232 extender keeps your desk clutter-

free, allowing the relocation of your computer to a safe and secure area, while allowing

you to work in a quieter environment.

INTRODUCTION

FEATURES

Features

• Extends any RS232 compliant device up to 1000 feet (300 meters) from the computer

• One CAT-5e cable extension

• Perfect for digital signage applications

• Conforms to RS-232C standards

Includes:

(1) RS232 Extender S Sender Unit

(1) RS232 Extender R Receive Unit

(1) 6 foot serial cable

(1) 5V external power supply

Wacom Tablet

RS-232 Extender

Receiver

RS-232 Extender

Sender

CPU

PANEL DESCRIPTIONS

CONNECTING AND OPERATING THE RS232 EXTENDER

How to Connect the RS232 Extender

1- Connect the supplied RS232 cables from the computers RS232 port into the RS232

extender send unit.

2- Connect the CAT5 cable from the send unit to the receive unit.

3- Connect your RS232 devices into the RS232 extender receiver unit.

4- Plug the 5 volt power supply into the RS232 extender send unit.

5- Restart your computer only after you’ve made all the connections.

SPECIFICATIONS

RS232 Input Connector ................................................................................ DB-9 female

RS232 Output Connector ................................................................................. DB-9 male

Link Connector ......................................................................................... RJ-45 Shielded

Power Consumption .................................................................................. 5 Watts (max.)

Power Supply ......................................................................................................... 5V DC

Dimensions ..................................................................................... 1.4”W x 1”H x 3.75”D

Shipping Weight ....................................................................................................... 3 Lbs

Gefen Inc. warrants the equipment it manufactures to be free from defects in material

and workmanship.

If equipment fails because of such defects and Gefen Inc. is notiﬁed within two (2) year

from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment,

provided that the equipment has not been subjected to mechanical, electrical, or other

abuse or modiﬁcations.

Equipment that fails under conditions other than those covered will be repaired at the

current price of parts and labor in effect at the of repair. Such repairs are warranted for

ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or ﬁtness for any particular purpose,

all of which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cable must be free from any

scratches, markings, and neatly coiled.

The information in this manual has been carefully checked and is believed to be

accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that may

be contained in this manual. In no event will Gefen Inc., be liable for direct, indirect,

special, incidental, or consequential damages resulting from any defect or omission

in this manual, even if advised of the possibility of such damages. The technical

information contained herein regarding RS232 Extender features and speciﬁcations is

subject to change without notice.

WARRANTY
