User's Manual

GV-IPCam H.264

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use. ICH264TGV101-A

Under the copyright laws, this manual may not be copied, in whole or in

part, without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any

kind and assumes no responsibility for errors or omissions. No liability is

assumed for incidental or consequential damages arising from the use of

the information or products contained herein. Features and specifications

are subject to change without notice. Note: no memory card slot or local

storage function for Argentina.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows and Windows

XP are registered trademarks of Microsoft Corporation.

September 2014

Safety Notice

FCC Compliance for GV-CBW120/220

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference and (2) this device must accept any interference

received, including interference that may cause undesired operation of

the device.

UL Certification for GV-MFD120/130/220/320/520

The GV-IPCAM H.264 uses a 3.0V CR2032 Lithium battery as the

power supply for its internal real-time clock (RTC). The battery should

not be replaced unless required!

If the battery does need replacing, please observe the following:

•Danger of Explosion if battery is incorrectly replaced

•Replace only with the same or equivalent battery, as

recommended by the manufacturer

•Dispose of used batteries according to the manufacturer's

instructions

Preface

Welcome to the GV-IPCAM H.264 User’s Manual.

The GV-IPCAM H.264 has a series of models designed to meet different

needs. This Manual is designed for the following models and firmware

versions:

Note: To upgrade the camera firmware from V2.07 or earlier to the

latest version, back up the files in the camera’s storage device first

before the upgrade and it is required to re-format the memory card

after the upgrade.

Model Model Number Firmware

Version

GV-BX120D Varifocal Lens

GV-BX130D-0 Varifocal Lens

GV-BX130D-1 Fixed Lens

GV-BX140DW

GV-BX220D-2

GV-BX220D-3

GV-BX320D-0

GV-BX320D-1

Box Camera

GV-BX520D

Varifocal Lens

V2.11

Model Model Number Firmware

Version

GV-BX1200-0F ~ 2F

GV-BX1300-0F ~ 2F

GV-BX1500-0F ~ 2F

GV-BX2400-0F ~ 2F

GV-BX2500-0F ~ 2F

GV-BX3400-0F ~ 2F

Fixed Lens

GV-BX1200-3V

GV-BX1300-3V

GV-BX1500-3V

GV-BX2400-3V

GV-BX2500-3V

GV-BX2400-4V

GV-BX3400-4V

GV-BX3400-5V

GV-BX5300-6V

Varifocal Lens

Box Camera

GV-BX1500-8F

GV-BX2400-8F

GV-BX2500-8F

GV-BX3400-8F

GV-BX5300-8F

Fixed Lens

V2.11

Ultra Box

Camera

GV-UBX1301 Series

GV-UBX2301 Series

GV-UBX3301 Series

Fixed Lens V2.11

III

Model Model Number Firmware

Version

Target Box

Camera

GV-EBX1100-0F

GV-EBX1100-2F Fixed Lens V1.01

GV-BX120D-E

GV-BX220D-E

GV-BX320D-E

GV-BX520D-E

GV-BX1500-E

IR Arctic Box

Camera

GV-BX2400-E

GV-BX3400-E

GV-BX5300-E

Varifocal Lens V2.11

GV-MFD120

GV-MFD130

GV-MFD220

GV-MFD320

GV-MFD520

Mini Fixed

Dome GV-MFD1501 Series

GV-MFD2401 Series

GV-MFD2501 Series

GV-MFD3401 Series

GV-MFD5301 Series

Fixed Lens V2.11

Model Model Number Firmware

Version

GV-MDR120

GV-MDR220

GV-MDR320

GV-MDR520

V2.11

Mini Fixed

Rugged Dome GV-MDR1500 Series

GV-MDR2400 Series

GV-MDR2500 Series

GV-MDR3400 Series

GV-MDR5300 Series

Fixed Lens

V2.12

GV-EFD1100-0F

Target Mini

Fixed Dome

GV-EFD1100-2F

GV-EFD2100-0F

GV-EFD2100-2F

Fixed Lens V1.01

Target Bullet

Camera

GV-EBL1100-1F

GV-EBL1100-2F

GV-EBL2100-1F

GV-EBL2100-2F

Fixed Lens V1.01

GV-UBL1211

GV-UBL1511

GV-UBL2411

GV-UBL2511

GV-UBL3411

Motorized

Varifocal Lens V2.11

Ultra Bullet

Camera

GV-UBL1301 Series

GV-UBL2401 Series

GV-UBL3401 Series

Fixed Lens

Model Model Number Firmware

Version

GV-BL120D

GV-BL130D

GV-BL220D

GV-BL320D

GV-BL1200

GV-BL1300

GV-BL1500

GV-BL2400

GV-BL2500

GV-BL3400

Varifocal Lens

GV-BL1210

GV-BL1510

GV-BL2410

GV-BL2510

GV-BL3410

V2.11

Bullet Camera

GV-BL5310

Motorized

Varifocal Lens

V2.12

NTSC

PTZ Camera GV-PTZ010D

PAL

V1.09

PT Camera

GV-PT130D

GV-PT220D

GV-PT320D

Fixed Lens V2.11

Model Model Number Firmware

Version

GV-VD120D

(IK10+, Transparent Cover)

GV-VD121D

(IK10+, Smoked Cover)

GV-VD122D

(IK7, Transparent Cover)

GV-VD123D

(IK7, Smoked Cover)

GV-VD220D

(IK10+, Transparent Cover)

GV-VD221D

(IK10+, Smoked Cover)

GV-VD222D

(IK7, Transparent Cover)

GV-VD223D

(IK7, Smoked Cover)

GV-VD320D

(IK10+, Transparent Cover)

GV-VD321D

(IK10+, Smoked Cover)

GV-VD322D

(IK7, Transparent Cover)

GV-VD323D

(IK7, Smoked Cover)

Vandal Proof

IP Dome

GV-VD1500

GV-VD2400

GV-VD2500

GV-VD3400

Varifocal Lens V2.11

VII

Model Model Number Firmware

Version

GV-VD1530

GV-VD2430

GV-VD2530

GV-VD3430

Varifocal Lens,

high power IR

LEDs

GV-VD1540

GV-VD2440

GV-VD2540

GV-VD3440

V2.11

GV-VD5340

Motorized

Varifocal Lens,

high power IR

LEDs

V2.12

GV-VD2540-E V2.11

Vandal Proof

IP Dome

GV-VD5340-E

Motorized

Varifocal Lens,

high power IR

LEDs, extreme

temperatures V2.12

Advanced

Cube

Camera

GV-CA120

GV-CA220

GV-CAW120

GV-CAW220

Fixed Lens V2.11

Cube Camera

GV-CB120

GV-CB220

GV-CBW120

GV-CBW220

Fixed Lens V2.11

VIII
