Gestetner 5499 Bedienungsanleitung

Operating Instructions

For safety, please read this manual carefully before you use this product and keep it

handy for future reference.

Note to users in the United States of America

Notice:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursu-

ant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio or television re-

ception, which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio /TV technician for help.

Warning

Changes or modifications not expressly approved by the party responsible for compliance could void

the user's authority to operate the equipment.

Note to users in Canada

Note:

This Class B digital apparatus complies with Canadian ICES-003.

Remarque concernant les utilisateurs au Canada

Avertissement:

Cet appareil numérique de la classe B est conforme àla norme NMB-003 du Canada.

In accordance with IEC 60417, this machine uses the following symbols for the main switch:

ameans POWER ON.

bmeans POWER OFF.

Introduction

This manual describes detailed instructions on the operation and notes about the use of this machine.

To get maximum versatility from this machine all operators are requested to read this manual carefully

and follow the instructions. Please keep this manual in a handy place near the machine.

Notes:

Some illustrations in this manual might be slightly different from the machine.

Certain options might not be available in some countries. For details, please contact your local dealer.

Two kinds of size notation are employed in this manual. With this machine refer to the inch version.

For good print quality, Standard recommends that you use genuine Standard masters and inks.

Standard shall not be responsible for any damage or expense that might result from the use of parts

other than genuine Standard parts in your Standard office product.

Power Source

120V, 60Hz, 2.4A or more

Please be sure to connect the power cord to a power source as above. For details about power source,

⇒p.200 “Power Connection”.

Safety Information

When using this machine, the following safety precautions should always be fol-

lowed.

Safety During Operation

In this manual, the following important symbols are used:

RWARNING:

WARNING:

Indicates a potentially hazardous situation which, if instructions

are not followed, could result in death or serious injury.

CAUTION:

Indicates a potentially hazardous situation which, if instructions are not

followed, may result in minor or moderate injury or damage to property.

•Connect the power cord directly into a wall outlet and never use an ex-

tension cord.

•Disconnect the power plug (by pulling the plug, not the cable) if the

power cable or plug becomes frayed or otherwise damaged.

•To avoid hazardous electric shock, do not remove any covers or

screws other than those specified in this manual.

•Turn off the power and disconnect the power plug (by pulling the plug,

not the cable) if any of the following occurs:

•You spill something into the machine.

•You suspect that your machine needs service or repair.

•The external housing of your machine has been damaged.

RCAUTION:

•Protect the machine from dampness or wet weather, such as rain, snow.

•Unplug the power cord from the wall outlet before you move the machine.

While moving the machine, you should take care that the power cord will not

be damaged under the machine.

•When you disconnect the power plug from the wall outlet, always pull the

plug (not the cable).

•Do not allow paper clips, staples, or other small metallic objects to fall inside

the machine.

•For environmental reasons, do not dispose of the machine or expended

supply waste at household waste collection points. Disposal can take place

at an authorized dealer.

•Be careful not to cut yourself on any sharp edges when you reach inside the

machine to remove misfed sheets of paper or masters.

•Our products are engineered to meet high standards of quality and function-

ality, and we recommend that you use only the expendable supplies avail-

able at an authorized dealer.

iii

How to Read This Manual

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation that might result in

death or serious injury when you misuse the machine without following the in-

structions under this symbol. Be sure to read the instructions, all of which are de-

scribed in the Safety Information section.

CAUTION:

This symbol indicates a potentially hazardous situation that might result in mi-

nor or moderate injury or property damage that does not involve personal injury

when you misuse the machine without following the instructions under this

symbol. Be sure to read the instructions, all of which are described in the Safety

Information section.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed, originals might be

damaged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates the prior knowledge or preparations required before op-

erating the machine.

Note

This symbol indicates precautions for operation, or actions to take after misop-

eration.

Limitation

This symbol indicates numerical limits, functions that cannot be used together,

or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[]

Keys that appear on the machine's display panel.

{}

Keys built into the machine's operation panel.

Making Prints

Before making prints using this ma-

chine, you have to make a master by

pressing the {

{{

{Start}

}}

}key. When you

press the {

{{

{Start}

}}

}key, the machine

scans the original image and makes a

master. This procedure describes

how to make basic prints.

APlace your originals in one of the

following two ways:

Placing originals on the exposure

glass

APlace a single page face down.

Inserting originals in the optional

document feeder

AInsert a stack of originals face

up.

Note

❒To avoid jamming, fan the

originals before placing them

in the document feeder.

BPress the {

{{

{Start}

}}

}key.

CPress the {

{{

{Proof}

}}

}key.

Check the print image.

Reference

For changing the image posi-

tion, see p.24 “Adjusting the Po-

sition of Printed Images”.

To increase the image density,

press the {

{{

}}

}key. See p.25 “Ad-

justing the Image Density of

Prints”.

ZDCH110E

ZDCH120E

To decrease the image density,

press the {

{{

}}

}key. See p.25 “Ad-

justing the Image Density of

Prints”.

DEnter the desired number of

prints with the number keys.

EPress the {

{{

{Print}

}}

}key.

When the print job has finished,

press the {

{{

{Clear Modes/Energy Sav-

er}

}}

}key. Previously entered job set-

tings will be cleared.

What You Can do with this Machine

Below is a quick summary of this ma-

chine's features and where to look in

this manual for more information.

❖

❖❖

❖Standard Printing

See p.19 “Standard Printing”.

❖

❖❖

❖Energy Saver Mode

See p.22 “Energy Saver Mode”

❖

❖❖

❖Adjusting the Print Image Position

See p.24 “Adjusting the Position of

Printed Images”.

* Paper feed direction

❖

❖❖

❖Adjusting the Print Image Density

See p.25 “Adjusting the Image

Density of Prints”.

❖

❖❖

❖Tint Mode

See p.26 “Tint Mode”.

❖

❖❖

❖Changing the Printing Speed

See p.27 “Changing the Printing

Speed”.

❖

❖❖

❖Reducing and Enlarging Using Preset

Ratios

See p.29 “Reducing and Enlarging

Using Preset Ratios”.

❖

❖❖

❖Auto Magnification

See p.31 “Auto Magnification”.

❖

❖❖

❖Zoom

See p.34 “Zoom”.

GRPOSI0E

GRTINT0E

GRRATI0E

GRAUTO0E

GRZOOM0E

vii

❖

❖❖

❖Directional Magnification (%)

See p.36 “Directional Magnifica-

tion (%)”.

❖

❖❖

❖Directional Magnification (Size)

See p.38 “Directional Magnifica-

tion (Size)”.

❖

❖❖

❖Erasing Center and Edge Margins

See p.40 “Erasing Center and Edge

Margins”.

❖

❖❖

❖Edge Erase

See p.41 “Edge Erase”.

❖

❖❖

❖Printing on Various Kinds of Paper

See p.43 “Printing onto Various

Kinds of Paper”.

❖

❖❖

❖Selecting Original Modes

See p.46 “Selecting Original

Modes”.

❖

❖❖

❖Economy Mode

See p.50 “Economy Mode”.

❖

❖❖

❖Auto Cycle

See p.51 “Auto Cycle”.

❖

❖❖

❖All Class Mode

See p.52 “All Class Mode”.

❖

❖❖

❖Auto Class Mode

See p.54 “Auto Class Mode”.

❖

❖❖

❖Manual Class Mode

See p.57 “Manual Class Mode with

One Original”.

CP2P01EE

CP2M01EE

GRERAS0E

AB AB

GRCLAS2E
