Graco EM5 Series Bedienungsanleitung

Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441

Copyright 2007, Graco Inc. is registered to I.S. EN ISO 9001

Before you start

Be sure that you have the following items available:

• 9 in. crescent or open end wrench - 7/8 in.

• 9 in. crescent or open end wrench - 1

1/

8in.

• Waste container

• Thread tape

These instructions are provided as a quick maintenance guide. They are not meant to replace the

Instruction Manual. See Instruction Manual for Warnings and information on the safe and proper

operation of this equipment. It is important that you read and understand all instructions and

hazards before operating this equipment.

PRESSURIZED EQUIPMENT HAZARD

This equipment stays pressurized until pressure is

manually relieved. To reduce the risk of serious injury from

pressurized fluid, accidental spray from dispense valve or

splashing fluid, follow steps 2-3 on page 2.

312354A

Quick Reference Guide

Replacing the EM5™Meter

Replacing the EM5™Meter

2

1. Pull down enough hose so that the meter can be

supported on the floor or other flat work surface.

2. Set air regulator pressure to zero psi and/or turn off

main air supply.

3. Trigger the dispense valve into a waste fluid

container to relieve fluid pressure.

4. Slide the swivel cover off the swivel.

5. Use 2 wrenches to separate the meter swivel from

the hose.

6. Wrap hose thread with thread tape as shown above.

Replacing the EM5™Meter

3

7. Connect the new meter swivel to the hose. 8. Using two wrenches, connect the swivel to the hose.

Do not over tighten.

9. Slide the swivel cover over the swivel. 10. Turn on main air supply and/or set air regulator pres-

sure to 60 psi.

11. Test meter. Dispense about 1/3 gallon of fluid to

purge air from hose.

Replacing the EM5™Meter

4

All written and visual data contained in this document reflects the latest product information available at the time of publication.

Graco reserves the right to make changes at any time without notice.

This manual contains English. MM 312354

Graco Headquarters: Minneapolis

International Offices: Belgium, China, Japan, Korea

GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441

www.graco.com

5/2007
