Basic Instructions for Your Grandstream GXP2160 IP Phone

Visual Overview of the Phone

Making a call

1. Do not pick up the phone first! This makes using the backspace function on the next step possible.

2. Dial the number using the keypad, using the 1 and area code if needed. You do not have to dial 9 first. The

system knows the difference between extensions and valid phone numbers. You may use the BackSpace

soft key if you make a mistake while dialing.

3. Either press the speaker button or lift up the handset.

4. You may alternatively pick up the handset or press speaker before you dial. If you do this, the phone will dial

the requested number immediately upon pressing the Dial soft-key or it will time out and dial after four

seconds. For this reason, it is recommended to dial the number before picking up or pressing the speaker

key on the phone.

To “Page” an extension

For intercom paging, press ** and then enter the extension or group number of the party or group you want

to page. This feature will call an extension or group of extensions, allowing you to speak immediately over

the speaker in the telephone without ringing the phone itself.

Placing a call on hold

1. While on the call, press the Hold key. This will place the call on hold on one of the Line keys.

2. If you need to place another call after you put the call on hold, you will have to hit the Line 2key to get

another line. Dial as needed and press the Dial soft key to send the digits. .

Basic Instructions for Your Grandstream GXP2160 Phone

Page 2of 5

Placing a call on hold to answer an incoming call

1. When you’re on the first call, the second Line key will blink Red. To answer the second call, press the

blinking red Line key.

2. This will automatically put the first call on hold.

3. To switch between the lines, just press the appropriate Line Key. (There is no need to put the calls on hold

as this is done automatically).

4. To drop one of the calls, be on that line and press the End Call soft key or hang up.

Picking up a call on hold

1. Press the Line button that is blinking where the call is on hold.

2. Or Press the Pickup soft key to pick up the last call you placed on hold.

Parking calls

It is best to use the Park orbits when placing a call on hold for someone else.

1. While on the call, press the Park key.

2. The status of orbits 701, 702, and 703 are usually displayed on every phone.

3. One of the Park Orbit buttons will then light up, indicating where the call is Parked. .

4. To retrieve the parked call, press the red Park 70X button.

5. If the call is on Park orbit 704 or higher, the user will then have to manually dial 7XX number to retrieve the

call.

Picking up a Call that is Ringing on another phone

1. Dial the digits 99

2. Pick up the handset or press the speaker button. You have now picked up that call.

Transferring a call

Supervised Transfer

1. While on the call, press the Transfer key .

2. Enter the extension number or outside number.

3. Press the # (pound) key.

4. Wait for the person to answer and announce the call.

5. If they want it, press the Transfer key again and hang up.

6. If the person does not want the call or does not answer, press the Split soft key.

7. Press the End soft key to end the call.

8. Press the blinking Line key which still has the original caller on hold to get the caller back.

Supervised Transfer Using a Programmable Key as the Destination

1. While on the call, press the Transfer key

2. Press the programmable DSS/BLF button of the person to whom you wish to transfer the call.

3. Announce the call.

4. If they want it, press the Transfer key again and hang up.

5. If the person does not want the call or does not answer, press the Split soft key.

6. Press the End soft key to end the call.

7. Press the blinking Line key which still has the original caller on hold to get the caller back.

Unsupervised Transfer

1. While on the call, press the Transfer key.

2. Enter the extension number, press the Transfer key again and then hang up.

3. The user still has the option to take or reject the call once it is transferred to them.

Transferring a call directly to voicemail

1. While on the call, press the Transfer key.

2. Press * and the extension number.

3. Press the Transfer key again and the call is directly routed to the user’s voicemail.

Basic Instructions for Your Grandstream GXP2160 Phone

Page 3of 5

Conference calls

1. Make the first call as usual.

2. Press the Conference key. .

3. Dial the second number.

4. Wait for the second party to answer.

5. To bring all three parties together, hit the Conf key again.

6. If you make a mistake while dialing or the second party is not there, press the Cancel soft key and press the

blinking Line key to return to the previous caller.

You can only add up to 3 parties including yourself to the Conference Call. If you need to add more, you can

use the Meet-Me-Conferencing Feature.

Using the speakerphone

1. Dial the number and then press the Speakerphone/Headset button.

2. To hang up, press the Speaker button.

3. You may also pick up the handset to take the phone out of speakerphone mode.

Volume controls

The volume keys change the volume of the ringer, the handset, and the speakerphone. To change the

volume of the ringer, press up or down when the phone is not off-hook.

Whisper (When Allowed by Administrator)

1. Park the original call.

2. Dial * 8 * (star 8 star) and the extension number. (Remember to press Send to make the call go through

quicker).

3. You will hear a beep and automatically be connected to that extension’s call.

4. Announce that the person has a call on Park.

5. Hang up.

Voicemail System

Setting Up Your Voicemail

The first time you access your mailbox, the system will walk you through setting up your password, name

recordings, and greetings. Please follow this all the way through and it will not play the tutorial again. The

following instructions are for when you need to change something after the initial setup.

Recording greetings

1. Press the Message key .

2. Enter your password, which by default is your extension number, followed by the #key.

3. Press 0for Mailbox Options.

4. You have the option of recording up to three greetings. At the very least, record an Unavailable Message.

Press 1to record the Unavailable Message.

5. Record the message after the tone and press pound.

6. To keep the message, press 1to accept the message. If not satisfied, press 3to re-record and repeat steps

5 and 6.

Recording name

1. Press the Message key.

2. Enter your password, followed by the #key.

3. Press 0for Mailbox Options.

4. Press 3to record your name.

5. Record the name after the tone and press pound.

6. To keep the message, press 1to accept the message. If not satisfied, press 3to re-record and repeat steps

5 and 6.

Basic Instructions for Your Grandstream GXP2160 Phone

Page 4of 5

Setting your mailbox password

We strongly recommend you change your voicemail password as soon as possible. By default, it is your extension

number. Anyone who knows this can access your mailbox through the web and listen to and delete your messages,

see your call logs, and modify settings on your extension.

1. Press the Message key.

2. Enter your password, followed by the #key.

3. Press 0 for Mailbox Options.

4. Press 5 to change your password.

5. Please enter your new password, followed by the pound key.

6. Re-enter your password followed by the pound key for confirmation.

7. If everything is correct, the system will tell you your password has been changed.

Recording a Temporary Greeting

Use the Temporary Greeting when you want to record a greeting that you are only going to be using for a, uh,

temporary time (for example an out-of-office greeting).

1. Press the Message Key.

2. Enter your password, followed by the #key.

3. Press 0for Mailbox Options.

4. Press 4to record your Temporary Greeting

5. After the tone, record your temporary greeting.

6. Press #when finished.

7. Follow the prompts to confirm or record the greeting again.

Deleting Temporary Greeting

When you come back from, hopefully, your vacation, you will need to delete your temporary greeting in order for your

regular unavailable greeting to start playing again. To do this:

1. Press the Message Key.

2. Enter your password, followed by the #key.

3. Press 0for Mailbox Options

4. Press 4to record your Temporary greeting.

5. Press 2to delete your Temporary Greeting.

6. Hang up

Listening To Messages

New messages

1. Press the Message key.

2. Enter your password, followed by the #key.

3. Press 1to listen to new messages.

4. Follow the prompts to save, delete, etc.

Old messages

1. Press the Message key. .

2. Enter your password, followed by the #key.

3. Press 2to change folders.

4. Press 1for old messages (or listen to the prompts to select another folder).

5. Follow the prompts.

To Retrieve messages from another extension (on-site)

1. Dial 924 for the Voicemail Gateway.

2. Enter your extension or mailbox number.

3. Enter your password.

Basic Instructions for Your Grandstream GXP2160 Phone

Page 5of 5

To retrieve messages remotely (Off-Site)

If your system is answered by an auto-attendant or a Voicemail “Backdoor” number:

1. Dial the main number or backdoor number.

2. Press # for the Voicemail Gateway.

3. You will be prompted to enter your mailbox number, then your password.

4. Follow the prompts to listen to messages.

If you call your own direct-dial number:

1. Dial your direct-dial (private number)

2. Wait for the voicemail to pick up with your personal greeting.

3. Press * (star) for the voicemail gateway.

4. You will be prompted to enter your mailbox number and then your password.

5. Follow the prompts to listen to your messages.

Further on-line help:

Visit our website at http://www.advnetwork.com/support.html
