GW Instek GSP-810 Bedienungsanleitung

Spectrum Analyzer

GSP-810

USER MANUAL

GW INSTEK PART NO. 82SP-81000MF1

ISO-9001 & ISO-14001 CERTIFIED MANUFACTURER

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

This manual contains proprietary information, which is protected by

copyrights. All rights are reserved. No part of this manual may be

photocopied, reproduced or translated to another language without

prior written consent of Good Will company.

The information in this manual was correct at the time of printing.

However, Good Will continues to improve products and reserves the

rights to change specification, equipment, and maintenance

procedures at any time without notice.

Windows is a registered trademark of Microsoft Corporation in the United States and other countries.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng City, Taipei County 236, Taiwan.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

Table of Contents

1.0 GENERAL DESCRIPTION AND FEATURES...............................................................................2

2.0 USAGE PRECAUTIONS AND RECOMMENDATIONS ...............................................................3

3.0 PANEL DESCRIPTIONS ...............................................................................................................7

4.0 SETUP AND USE ........................................................................................................................11

5.0 QUICK USE INDEX .....................................................................................................................27

6.0 SPECIFICATIONS .......................................................................................................................28

APPENDIX 1 - REMOTE OPERATION (STANDARD AND OPTION) .............................................32

Due to continuous improvements in the GSP-810 Spectrum Analyzer, information

contained in this Manual is subject to change without notice.

Contact GW, for revisions and corrections.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

Declaration of Conformity

GOOD WILL INSTRUMENT CO., LTD.

No. 7-1, Jhongsing Rd, Tucheng City, Taipei County 236. Taiwan.

GOOD WILL INSTRUMENT (SUZHOU) CO., LTD.

No. 69 Lushan Road, Suzhou New District Jiangsu, China.

declare that the below mentioned product

Type of Product: Spectrum Analyzer

Model Number : GSP-810

is herewith confirmed to comply with the requirements set out in the Council

Directive on the Approximation of the Law of Member States relating to

Electromagnetic Compatibility (2004/108/EC) and Low Voltage Equipment

Directive (73/23/EEC & 93/68/EEC).

For the evaluation regarding the Electromagnetic Compatibility and Low Voltage

Equipment Directive, the following standards were applied:

◎EMC

EN 61326-1 :

EN 61326-2-1: Electrical equipment for measurement, control and laboratory use－

EMC requirements (2006)

Conducted & Radiated Emission

CISPR 11: 2003+A1: 2004 +A2: 2006

Electrostatic Discharge

IEC 1000-4-2: 2001

Current Harmonics

EN 61000-3-2: 2006

Radiated Immunity

IEC 1000-4-3: 2006+A1: 2007

Voltage Fluctuations

EN 61000-3-3:1995+A1:2001+A2:2005

Electrical Fast Transients

IEC 1000-4-4: 2004+Corr.1: 2006+Corr.2:

2007

==================== Surge Immunity

IEC 1000-4-5: 2005

==================== Conducted Susceptibility

IEC 61000-4-6: 2003+A1: 2004+A2: 2006

==================== Power Frequency Magnetic field

IEC 61000-4-8: 1993+A1: 2001

==================== Voltage Dip/Interruption

IEC 61000-4-11: 2004

Low Voltage Equipment Directive 73/23/EEC & amended by 93/68/EEC

Safety Requirements IEC/EN 61010-1: 2001

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

1.0 General Description and Features

The GSP-810 is designed for minimal set-up and adjustment. The user interface

allows fast and accurate measurements. The fully synthesized design of the GSP-

810 permits stable operation down to 2 kHz / division.

2.0 Usage Precautions and Recommendations

The following precautions are recommended to insure your safety and to provide the

best condition of the GSP-810.

Safety Terms and Symbols

These terms may appear in this manual or on the product:

WARNING: Warning statements identify condition or practices that could

result in injury or loss of life.

CAUTION: Caution statements identify conditions or practices that could result

in damage to this product or other property.

The following symbols may appear in this manual or on the product:

DANGER ATTENTION Protective Earth (ground)

High Voltage refer to Manual Conductor Terminal

Terminal

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

FOR UNITED KINGDOM ONLY

NOTE: This lead / appliance must only be wired by competent persons

WARNING: THIS APPLIANCE MUST BE EARTHED

IMPORTANT: The wires in this lead are coloured in accordance with the following code:

Green/ Yellow: Earth

Blue: Neutral

Brown: Live (Phase)

As the colours of the wires in main leads may not correspond with the colours

marking identified in your plug/appliance, proceed as follows:

The wire which is coloured Green & Yellow must be connected to the Earth

terminal marked with the letter E or by the earth symbol or coloured Green or

Green & Yellow.

The wire which is coloured Blue must be connected to the terminal which is

marked with the letter N or coloured Blue or Black.

The wire which is coloured Brown must be connected to the terminal marked with

the letter L or P or coloured Brown or Red.

If in doubt, consult the instructions provided with the equipment or contact the

supplier.

This cable/appliance should be protected by a suitably rated and approved HBC

mains fuse: refer to the rating information on the equipment and/or user

instructions for details. As a guide, cable of 0.75mm2should be protected by a 3A

or 5A fuse. Larger conductors would normally require 13A types, depending on the

connection method used.

Any moulded mains connector that requires removal /replacement must be

destroyed by removal of any fuse & fuse carrier and disposed of immediately, as a

plug with bared wires is hazardous if a engaged in live socket. Any re-wiring must

be carried out in accordance with the information detailed on this lable.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

Use and Wear

CAUTION

•Do not exceed +30 dBm into the RF INPUT or +30 dBm reverse power into the

TG OUTPUT.

•Do not place any heavy object on the instrument.

•Avoid severe impacts or rough handling that could damage the GSP-810.

•Use electrostatic discharge precautions while handling and making

connections to the GSP-810.

•Do not place wires into the connectors of the GSP-810, only mating connectors

and adapters.

•Do not block or obstruct cooling fan vent opening on side panels or on the rear

panel of unit.

1) Disassembly of the Instrument

•Do not disassemble the instrument; refer the instrument to a factory approved

service facility only.

2) AC Power Input

CAUTION

•AC input should be within the range of selected line voltage +/- 10%.

•Insure the correct fuse is installed prior to applying voltage for the first time -

90 V ~ 132 VAC input : T 1A / 250V

198 ~ 250 VAC input : T0.5A / 250V

•Check the line voltage setting on the rear panel. If the line voltage does not

match input voltage, change as follows:

a) Remove AC Power Cord;

b) Open cover of AC socket with flat blade screwdriver;

c) Remove selector Cam Drum and rotate to the correct voltage selection

d) Replace Cam Drum.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

3) Grounding

WARNING

•To avoid electrical shock, the power cord protective grounding conductor must

be connected to earth ground.

4) Fuse Replacement

WARNING

•For continued fire protection, replace the fuse with the specified type and rating

only.

•Disconnect power cord before replacing fuse.

•If the fuse is blown, there is something wrong with the instrument. Repair the

cause of fault before replacing fuse.

5) Cleaning

•Disconnect AC Power Cord from the instrument before cleaning.

•Use a soft cloth dampened in a solution of mild detergent and water. Do not

spray any liquid into the unit.

•Do not use chemicals or cleaners containing benzene, toluene, xylene,

acetone or other harsh chemicals.

6) Operating Environment

•The following conditions are recommended for optimum use of the instrument -

Indoor Use Altitude < 2000 m Temperature 18° to 28° C Relative Humidity < 90%

Dust Free No direct sunlight No strong magnetic fields

•Installation Category: II

CAT ⅣFor measurements performed at the source of the low-voltage installation.

CAT ⅢFor measurements performed in the building installation.

CAT ⅡFor measurements performed on circuits directly connected to the low-

voltage installation.

CAT ⅠFor measurements performed on circuits not directly connected to Mains.

•Pollution degree: 2

7) Storage Environment

•The following conditions are recommended for optimum storage of the instrument -

Indoor Temperature 0° to 40° C Relative Humidity < 85%

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

3.0 Panel Descriptions

Front Panel

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GSP-810 User Manual

Item Description

1 Cathode Ray Tube (CRT) Display, 8 x 10 graticule, 5 inch

2 Liquid Crystal Display (LCD), 4 line x 20 character

3 Keypad, field selection and data entry

4 Spinner, field selection and data change

5 RF Input, Coaxial, Type N Female

6 Tracking Generator Output, Coaxial, Type N Female (optional)

7 Switch, Power ON / OFF

8 Adjustment, CRT Trace Rotation, potentiometer

9 Control Knob, Volume (optional demod receiver)

10 Phone Jack, head set output, (optional demod receiver)

11 Control Knob, CRT Focus

12 Adjustment, CRT Y-axis position, potentiometer

13 Control Knob, CRT Intensity
