Clarkston

in Ceiling Fan

Owner’s Manual

Clarkston

Ventilador de Techo de 1.12m

Manual del Propietario

822 744

The retailer warrants the fan motor to be free from defects in workmanship and

material present at time of shipment from the factory for a lifetime after the date of

purchase by the original purchaser. The retailer also warrants that all other fan

parts, excluding any glass or plexiglass blades, to be free from defects in

workmanship and material at the time of shipment from the factory for a period of

one year after the date of purchase by the original purchaser. We agree to correct

such defects without charge or at our option replace with a comparable or superior

model if the product is returned to the retailer. To obtain warranty service, you must

present a copy of the receipt as proof of purchase. All costs of removing and

reinstalling the product are your responsibility. Damage to any part such as by

accident or misuse or improper installation or by affixing any accessories, is not

covered by this warranty. Because of varying climatic conditions in the United

States this warranty does not cover any changes in brass finish, including rusting,

pitting, corroding, tarnishing or peeling. Brass finishes of this type give their

longest useful life when protected from varying weather conditions. A certain

amount of wobble is normal and should not be considered a defect. Servicing

performed by unauthorized persons shall render the warranty invalid. There is no

other express warranty. The retailer hereby disclaims any and all

warranties, including but not limited to. Those of merchantability and

fitness for a particular purpose to the extent permitted by law. The duration

of any implied warranty which cannot be disclaimed is limited to the time period as

specified in the express warranty. Some states do not allow limitation on how long

an implied warranty lasts, so the above limitation may not apply to you. The

retailer shall not be liable for incidental, consequential, or special damages

arising out of or in connection with product use or performance except as

may otherwise be accorded by law. Some states do not allow the exclusion of

incidental or consequential damages, so the above exclusion or limitation may not

apply to you. This warranty gives specific legal rights, and you may also have other

rights which vary from state to state. This warranty supersedes all prior warranties.

Lifetime Limited Warranty

Hampton Bay Lifetime Limited Warranty

Date purchased

Store Purchased

UL Model No. CF544H-PEH

Serial No.

Vendor No. 82598

UPC 845952000049

Safety Rules

Unpacking Your Fan

Installing Your Fan

Hanging the Fan

Making the Electrical connections

Finishing the Installation

Attaching the Fan Blades

Installing the Light Kit

Operating Your Fan

Troubleshooting

Specifications

Table of Contents

Safety Rules 1.

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL

INJURY, MOUNT FAN TO OUTLET BOX MARKED ACCEPTABLE FOR

FAN SUPPORT.

1.To reduce the risk of electric shock, ensure electricity has been turned off

at the circuit breaker or fuse box before beginning.

2. All wiring must be in accordance with the National Electrical Code and

local electrical codes. Electrical installation should be performed by a

qualified licensed electrician.

3. WARNING: To reduce the risk of electrical shock and fire, do not use

this fan with any solid-state fan speed control device.

4. WARNING: To reduce the risk of personal injury, use only the two steel

screws ( and lock washers ) provided with the outlet box for mounting to

the outle t box . Most outlet boxe s commonly used fo r the support of lighting

fixtures are not acceptable for fan support and may need to be replaced,

consult a qualified electrician if in doubt.

5. The outlet box and support structure must be securely mounted and capable

o f reliably supporting a minimum of 35 pounds. Use only UL Listed outlet

boxes marked FOR FAN SUPPORT.

6. The fan must be mounted with a minimum of 7 feet clearance from

the trailing edge of the blades to the floor.

7. Do not operate reversing switch while fan blades are in motion. Fan

must be turned off and blades stopped before reversing blade

direction.

8. Avoid placing objects in the path of the blades.

9. To avoid personal injury or damage to the fan and other items, be

cautious when working around or cleaning the fan.

10. Do not use water or detergents when cleaning the fan or fan blades. A

dry dust cloth or lightly dampened cloth will be suitable for most

cleaning.

11. After marking electrical connections, spliced conductors should be

turned upward and pushed carefully up into outlet box. The wires

should be spread apart with the grounded conductor and the equipment-

grounding conductor on one side of the outlet box.

12. Electrical diagrams are reference only. Light kits that are not packed

with the fan must be UL Listed and marked suitable for use with the

model fan you are installing. Switches must be UL General Use

Switches. Refer to the Instructions packaged with the light kits and

switches for proper assembly.

NOTE

READ AND SAVE ALL INSTRUCTIONS!

WARNING

TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE

BLADE BRACKETS (ALSO REFERRED TO AS FLANGES) DURING

ASSEMBLY OR AFTER INSTALLATION. DO NOT INSERT OBJECTS IN

THE PATH OF THE BLADES.

2. Unpacking Your fan

6. Glass shade (3)

7. 40 Watt A15C bulbs (3)

8. Set of blades brackets (5)

9. Balancing kit (1)

2. Mounting bracket (1)

3. Motor housing (1)

4. Fan motor assembly ( 1 )

5. Light kit ( 1 )

Set of blades (5) (MDF blades)

WARNING

DO NOT INSTALL OR USE FAN

IF ANY PART IS DAMAGED OR MISSING.

CALL TOLL FREE 888-886-1579

10. Loose parts bag containing:

a . Blade attachment hardware (

and paper washers)

b. Mounting hardware (3 plastic wire

connectors)

c. Set of blade bracket hardware (1 screw)

d. Pull chain fob (2)

16 screws

Unpack your fan and check the contents. You should have the following items:

Tools Required

Phillips screwdriver; slotted screw driver;

stepladder; wire cutters; electrical tape.

Mounting Options

If there isn't an existing mounting box, then

read the following instructions. Disconnect

the power by removing fuses or turning off

circuit breakers.

Secure the outlet box directly to the building

structure. Use appropriate fasteners and

building materials. The outlet box and its

support must be able to fully support the

moving weight of the fan (at least 50 lbs).

Use a UL Listed metal outlet box. Do not use

a plastic outlet box.

Figures 1 and 2 are examples of different

ways to mount the outlet box.

Installing Your Fan 3.

Outl et bo x

Figure 2

Outlet Box

Figure 1

Ceiling Joist

Cross Brace

Ceiling Joist

Or Cross Brace Parallel

Wood Brace

Outlet box

Mounting bracket

Figure 4

Motor

Figure 5

4.Hanging the Fan

REMEMBER to turn off the power. Follow the

steps below to hang your fan properly:

Step 1. Attach the mounting bracket to the

outlet box with two screws and washers

provided with the outlet box. Make sure the

bracket is tight and secured. (Figure 4)

Step 2. Lift fan into position by hanging the

motor assembly onto the hook from the ceiling

mounting bracket allowing it to hang freely.

(Figure 5)

5.Making the Electrical

Connections

WARNING: To avoid possible electrical shock, be

sure electricity is turned off at the circuit breaker

or main fuse box before wiring.

Follow the steps below to connect the fan to your

house supply wires. Secure the wire nuts supplied

with your fan by wrapping the connections with

electrical tape.

Step 1. Connect the Black (hot) wire from the

ceiling to the black and blue wires from the fan.

Connect the white (neutral) wire from the ceiling

to the white wire from the fan. (Figure 6)

Step 2. If your outlet box has a ground wire (green

or bare copper) connect the fan ground wire to it.

If your outlet box does not have a ground wire, the

connect the fans and mounting bracket wire

together. Secure wire connection with the plastic

wire nuts provided.

Step 3. Figures 7 and 8 illustrate the wiring

connections for optional wall control (available at

your Hampton Bay Retailer, the wire color out of

wall control’s installation manual for correct

wire connections).

Washer

Screw

SUPPLY CIRCUIT

Ground

Conductor

Outlet Box

Green

Ground

Lead

Ground to

Downrod

BLACK

WHITE

BLACK

BLUE

GREEN

Figure 8

Diagram indicates optional light kit wiring.

Light

Fan

WHITE

BLUE

BLACK WHITE

SUPPLY CIRCUIT

Ground

Conductor

Outlet Box

Green

Ground

Lead

Ground to

Downrod

BLACK

WHITE

BLACK

BLUE

GREEN

Figure 7

Diagram indicates optional light kit wiring.

Light Switch

WHITE

BLUE

BLACK WHITE

Outlet Box

Green

Ground

Lead

Ground to

Downrod

BLACK

WHITE

BLUE

BLACK

Figure 6

Diagram indicates optional light kit wiring.

SUPPLY CIRCUIT

WHITE

BLACK

BLUE

GREEN

6.Finishing the Installation

Step 1. Remove motor assembly from "J" hook and lift

motor assembly to mounting plate. Align slotted holes

on plate at top of motor assembly with loosened motor

assembly mounting screws in mounting plate. Twist

motor assembly to lock and re-insert motor assembly

mounting screw, along with lock washer, that were

pre v i o usly r e move d . T i g h ten m o t or a s s embly

mounting screw securely. (Figure 9)

Step 2. Align large screwheads at motor housing

rounded with rounded part of long, slotted holes in

mounting plate. Turn motor housing clockwise, to the

LEFT, until it no longer turns. (Figure 10)

NOTE: You may think that you have turned the motor

housing enough upon feeling it stop when turning it the

first time, but that is probably only the halfway point

and it is extremely important that you make sure that

you turn the motor housing all the way to ensure that

the motor housing is completely secure. To do this,

when you begin turning the motor housing two more

inches (to the left) so that the screwheads reach the end

of each slotted hole, thereby remaining secure.

7.Blade Installation

Step 1. Attach the fan blades to the blade

holders using the screws and rubber washer

provided, tighten screws securely. (Figure

11)

Step 2. Remove rubber stops from motor.

Align motor holes to blade holders and

secure with screws provided, tighten screws

securely. Repeat procedure with remaining

blades. (Figure 11)

Mounting

Figure 10

Studs

Housing

Large Screwheads

Figure 9

Washers

Screw

Blades

Screw

Blade Bracket

Figure 11

Screws

Andere Handbücher für Clarkston

Inhaltsverzeichnis

Andere HAMPTON BAY Lüfter Handbücher

HAMPTON BAY

HAMPTON BAY Rapallo 110-083 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Gazebo 473-131 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY PALMARIA EF200S(X)-52 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Lyndhurst Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY GLENDALE AG524PR-ORB Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Larson Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY CLARET Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY HARPER AM214-WH Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 553-295 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Victoria Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY CLARKSTON CF544H-PEH Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY CARROLTON II Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Springview Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY MENA 92404 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Lodge 285 313 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY WELLTON AM588-BN Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Marlston N375B-BN Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY GLENDALE AG524-FB Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 54" Tropics Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Isolabella Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY MINNA HE-12026 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY TX-604D Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY LOWRY 52-LOWRY Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY Campbell II Bedienungsanleitung

Beliebte Lüfter Handbücher anderer Marken

ELTA FANS

ELTA FANS H03VV-F Bedienungsanleitung

Hunter

Hunter 20714 Gebrauchsanweisung

Emerson

Emerson CARRERA VERANDA CF542ORB00 Bedienungsanleitung

Hunter

Hunter Caraway Gebrauchsanweisung

Panasonic

Panasonic FV-15NLFS1 Bedienungsanleitung

Kompernass

Kompernass KH 1150 Bedienungsanleitung

VES

VES FALA100/12V/TR Bedienungsanleitung

Vertiv

Vertiv Liebert DCD Bedienungsanleitung

Westinghouse

Westinghouse GFP Series Bedienungsanleitung

Venmar

Venmar KUBIX HRV PLUS Series Bedienungsanleitung

Maico

Maico ECR 31 Bedienungsanleitung

Sonnenkonig

Sonnenkonig Dinky Bedienungsanleitung

S&P

S&P ECOWATT HXBR Bedienungsanleitung

Wider

Wider IMP03369BH Bedienungsanleitung

Panasonic

Panasonic F-60DHN Bedienungsanleitung

Hinkley

Hinkley HIGHLAND Bedienungsanleitung

Broan

Broan 766BN Bedienungsanleitung

Premium

Premium PFS16022 Montageanleitung
