INSTRUCTIONS MANUAL

EXTERIOR WALL LANTERN WITH

MOTION SENSOR AND SIX-HOUR TIMER

HOME DEPOT SKU# 561-352 (UPC# 046335840324)

Page 1

Page 2

FEATURES:

Before returning to your local Home Depot, please call our Customer Service Team at 1-877-

527-0313 or visit www.homedepot.com. Please reference your SKU (561-352) or UPC

(046335840324).

QUESTIONS, PROBLEMS, MISSING PARTS:

1. Easy to install.

2. Handsome white finish with clear hammered glass.

3. Solid cast aluminum resists elements.

4. MOTION SENSOR FUNCTION – At dusk the motion sensor will activate and

automatically turn the light on when moving heat sources (such as people or motor

vehicles) are detected within its coverage area. The motion sensor will remain active

throughout the night and deactivate at dawn. The motion sensor has a detection range up

to 30 feet and a detection angle of 180º.

5. SIX HOUR TIMER FUNCTION – At dusk the light will automatically turn on. After six

hours the light will turn off and the motion detector will activate. The motion sensor will

remain active throughout the night and deactivate at dawn.

6. MANUAL OVERRIDE – The user may manually turn on the light from inside his home

using its wall switch.

7. For energy savings this fixture has been engineered to safely use a Self Ballasted Compact

Fluorescent Lamp in place of an incandescent lamp.

8. ENERGY STAR®qualified

Thank you for purchasing this Hampton Bay exterior wall lantern. This product has been

manufactured with the highest standards of safety and quality. The finish of this lantern is

weather resistant but over time will naturally weather and fade. This fixture is equipped with

motion sensor and six-hour timer features, providing convenience and security against

unwanted criminal element.

Page 3

TOOLS REQUIRED FOR INSTALLATION AND ASSEMBLY

(not included):

CAUTION:

1. Before starting installation of this fixture or removal of a previous fixture, disconnect the

power by turning off the circuit breaker or by removing the fuse at the fuse box.

2. There are no serviceable parts inside the motion sensor. DO NOT try to repair or

disassemble the unit. Doing so could damage the unit and cause possible electrical shock.

Consult a qualified electrician if needed.

3. CONSULT A QUALIFIED ELECTRICIAN IF YOU HAVE ANY ELECTRICAL

QUESTIONS. If you have any non-electrical questions about this fixture, please call our

Customer Service Team at 1-877-527-0313 or visit www.homedepot.com. Please

reference your SKU (561-352) or UPC (046335840324).

4. KEEP your receipt and these Instructions for Proof of Purchase.

Safety

goggles

Wire

strippers

Phillips

screwdriver

Electrical

tape

Wire

cutters

Silicon Rubber

Sealant

for exterior use

Flathead

screwdriver

Light Bulb (100

watt maximum or

CFL equivalent)

When selecting a location, be aware of the motion sensor’s maximum range of

30 ft and 180º detection angle.

SELECTING AN INSTALLATION LOCATION:

Select locations away from heat sources, such as heating vents, air

conditioners, and heated swimming pools.

When selecting a location, be aware that the motion sensor is more sensitive to

movement across its coverage area and less sensitive to movement toward or

away from the motion sensor.

Select locations away from nighttime light sources, such as street lamps or

other light fixtures. They may shine light onto photocell sensor (located at the

bottom of the back plate, between the two switches). This light might cause

the photocell sensor to “think” that it is daytime and not allow the light to turn

on during the nighttime.

Be aware that shade from a porch or an eave may not allow enough daylight to

shine onto the photocell sensor and may cause it to “think” that it is nighttime,

and subsequently cause the light to remain on during the daytime.

Page 4

180º

PARTS INCLUDED FOR ASSEMBLY (parts are not to scale):

1 ea Thumb

Screw (#6)

2 ea Hood

Screws (#7)

4 ea Glass

Panels (#3)

1 ea Main Fixture Body (#5)

4 ea Glass

Panel Screw (#1) 4 ea Glass

Panel Clip (#2)

ASSEMBLY INSTRUCTIONS:

1. Carefully unpack the fixture. Lay out all parts on a clean surface.

2. Before continuing Assembly please proceed to the Installation Instructions.

3. Slide Glass Panels (#3) into the Main Fixture Body (#5). Secure each Glass

Panel (#3) using a Glass Panel Screw (#1) and a Glass Panel Clip (#2), as

shown.

4. Install up to a 100 watt Light Bulb (#4) or Listed SBCFL (Self-Ballasted

Compact Fluorescent Lamp [not provided]) in the socket of the Main Fixture

Body (#5). Do not exceed a 100 watt incandescent light bulb, or a 26 watt

SBCFL.

5. Attach the Hood (#7) to the Main Fixture Body (#5) using the provided Hood

Screws (#8), as shown.

Hood (#7)

Page 5

ASSEMBLY:

1. Glass Panel Screw

2. Glass Panel Clip

3. Glass Panel

4. Light Bulb

5. Main Fixture Body

6. Lock Nut

7. Hood

8. Hood Screw

Page 6

3 ea Wire

Nuts (#18)

2 ea Bracket Mounting

Screws (#13)

INSTALLATION INSTRUCTIONS:

PARTS INCLUDED FOR INSTALLATION (parts are not to

scale):

1. Thread the Hex Nut (#12) onto the Nipple (#14). Thread the Nipple (#14) into the center hole of the

Mounting Bracket (#11). Do not tighten the Hex Nut (#12) at this time.

2. Pull the power supply wires out from the Outlet Box (#9), and mount the Mounting Bracket (#11) to the

Outlet Box (#9), using the Bracket Mounting Screws (#13).

3. Attach the Black Supply Wire (#10) to the Black Fixture Wire (#17) and the White Supply Wire (#21) to

the White Fixture Wire (#18) using Wire Nuts (#19). Connect the Fixture Ground Wire (#16) and the

Supply Ground Wire (#20) together using a Wire Nut (#19). Wrap all wire connections with electrical

tape for a more secure connection. Note: If you have electrical questions, consult your local electrical

code for approved grounding methods.

4. Carefully tuck all Wires and Wire Nuts (#19) into the Outlet Box (#9). Place the Wall Plate (#15) (of the

Main Fixture Body (#5)) over the Outlet Box (#9), flush against the wall surface, making sure the Nipple

(#14) feeds through the hole of the Wall Plate (#15). Adjust the Nipple (#14) so that it protrudes about

¼ inch from the surface of the Wall Plate (#15). Remover the Wall Plate from the wall and tighten the

Hex Nut (#12) against the Mounting Bracket (#11). Replace the Wall Plate (#15) over the Outlet Box

(#9) and thread the Thumb Screw (#6) onto the Nipple (#14) to secure the Wall Plate (#15) against the

wall.

5. After installing the fixture, caulk upper 2/3 of the Wall Plate (#15) to mounting surface. Leave bottom

1/3 un-caulked for drainage of any water that might leak into the enclosure. The manufacturer

recommends a non-drying exterior caulking material. A good example is a clear silicone rubber sealant

for exterior use.

6. Installation is complete. Turn on power at the circuit breaker or fuse box. Turn the light switch on to

activate the fixture.

1 ea Mounting

Bracket (#11) 1 ea Nipple (#14)

1 ea Hex

Nut (#12)

1 ea Thumb

Screw (#6)

1 ea Main Fixture

Body (#5)

Page 7

INSTALLATION:

15. Wall Plate

6. Lock

Nut

18. White

Fixture

Wire

16. Fixture

Ground

Wire

19. Wire Nut

21. White

Supply

Wire

10. Black Supply

Wire

20. Supply

Ground

Wire

9. Outlet

Box

11. Mounting

Bracket

13. Bracket

Mounting

Screw 12. Hex

Nut

17. Black

Fixture

Wire

14. Nipple

Page 8

OPERATION INSTRUCTIONS:

SETTING MOTION SENSOR SENSITIVITY IN TEST MODE: (Note: Sensitivity directly correlates to

the sensor’s detection range.) In TEST mode, slide the “SENSITIVITY” switch to a desired level: “L” for

low, “M” for medium, or “H” for high. From a distance, walk through the coverage area. When the sensor

detects you and the light turns on, note your distance from the fixture. Move away from the fixture and wait

4 to 5 seconds for the light to turn off. Walk through the coverage area again, this time trying a different

approach toward the fixture at different angle. Again, make note of your distance from the fixture when the

light turns on. Repeat these steps, approaching the fixtures down different pathways. Especially, walk

through pathways where you expect high traffic, such as walkways and driveways. After testing various

pathways, decide to increase or decrease the detection range, or to keep it the same. To increase the

detection range, slide the “SENSITIVITY” switch to the next highest level. To decrease the detection range,

slide the “SENSITIVITY” switch to next lowest level. Repeat the steps above. Continue to adjust the

sensitivity level until optimum results are attained.

SELECTING FUNCTION: After setting the sensitivity to the desired level, select the function by sliding to

“TIMER” switch to one of the following positions:

GETTING STARTED: After installing the fixture, slide the “TIMER” switch to “TEST”. Restore power at

the circuit breaker and turn on your wall switch (if applicable). The light will turn on and remain on for

approximately 45 seconds. Then the light will flash 3 times and then turn off. (Note: TEST mode allows you

to conveniently set the motion sensor sensitivity. In TEST mode, the motion sensor will turn on the light

when it senses movement. Four to five seconds after movement has stopped, the light will turn off.)

SENSITIVITY

H M L

TIMER

10 4 TEST

HOUR

"TIMER"

Switch

Position Function Description

6 HOUR SixHour

Timer

At dusk, the light willturn on and remain on for6hours. At this time, the light

willturn offand the motion sensorbecomes active. Any movement within the

coverage area, will cause the light to turn on. After movement has stopped,

the light will remain on for 10 minutes, at which time the light will turn off.

The motion sensor will remain active through the rest of the night. At dawn,

the motion sensor deactivates. The motion sensor will remain deactivated

throughout the day.Movement will not cause the light to turn on.

Motion

Sensor

At dusk, the motion sensor becomes active. Any movement within the

coverage area will cause the light to turn on. After movement has stopped,

the light willremain on forthe preset time limit of 4or10minutes, at which time

the light will turn off. The motion sensor will remain active throughout the

night. At dawn, the motion sensor will deactivate. The motion sensor will

remain deactivated throughout the day. Movement willnot cause the light to

turn on.

Page 9

Page 10

Problem Possible Cause Corrective Action

1. Power is off. 1. Make sure wall switch and circuit

2. Faulty switch. 2. Test or replace switch.

3. Faulty wire connection. 3. Check wiring.

4. Light bulb may be dead. Test light bulb in

a working light fixture. 4. Replace light bulb

Fuse blows or circuit breaker

trips when light is turned on. 1. Crossed wires or power wire is grounding

out. 1. Check wire connections.

Too much sunlight is shiningonto photocell

sensor in the early evening. Relocate fixture away from a western

facingwall.

Too much light is shiningonto photocell

sensor due to another light source, such as a

street lamp or other light fixture.

Eliminate or turn off other light

source.

Block other light source from shining

onto photocell sensor.

Relocate fixture.

In motion sensingmode, the

light stays on continuously.

False triggering cause by a heat source, such

as a heater or dryer vent, or heated

swimmingpool.

Eliminate heat source.

Relocate fixture.

Street or sidewal trafficis triggeringthe

motion sensor Lower the sensitivity.

False triggering cause by a heat source, such

as a heater or dryer vent, or heated

swimmingpool.

Eliminate heat source.

Relocate fixture.

The light comes on duringthe

daytime or too early in the

evening.

The fixture may be installed in a shaded area,

such as under a porch or eave, preventing

daylight from shining onto the photocell

sensor.

Relocate fixture.

In the SixHour Timer

function, the light comes on

too late in the evening.

Too much sunlight is shiningonto the

photcell sensor in the early evening. Relocate fixture away from a western

facingwall.

In the SixHour Timer

function, the light does not

come on at night.

Too much light is shiningonto the photcell

sensor due to another light source, such as a

street lamp or other light fixture. Cover the

hotocell sensor with black electrical tape, to

verify that the light will turn on when there

is enough darkness.

Eliminate or turn off other light

source.

Block other light source from shining

onto photocell sensor.

Relocate fixture.

The light never turn on.

The light does not turn on at

night.

The light comes on for no

apparent reason.

TROUBLESHOOTING:

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere HAMPTON BAY Außenleuchte Handbücher

HAMPTON BAY

HAMPTON BAY 724-739 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY KXX1501LX-01 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY HD5887F3 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY WELLINGWAY HDP06597BR Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY NXT-3149 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY HD33677 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 560-293 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 18165-000 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY HD33870 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY COLLIER KZH8903AX-01/GW Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 29608 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 29518 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY DYX1701A Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 362-713 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY HD22750 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY P5100-01-06 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY KECP10-LED Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY QTP22a-R4-AC-2 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY KIF1801LX-01/AL Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY HD29234 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY ASPENWOOD HDP00830 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY NTSW30030LBL-MS Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY HBP609-35 Bedienungsanleitung

HAMPTON BAY

HAMPTON BAY 436-243 Bedienungsanleitung

Beliebte Außenleuchte Handbücher anderer Marken

Sealey

Sealey LED37 Bedienungsanleitung

nordlux

nordlux VEJERS Benutzerhandbuch

SImx

SImx ELITE LED LHTC637 Bedienungsanleitung

GEV

GEV CAROLINE 10833 Bedienungsanleitung

NEBO

NEBO NEB-LSP-0020 Bedienungsanleitung

WE-EF

WE-EF PFL540 LED Bedienungsanleitung

Lindby

Lindby 9949029 Bedienungsanleitung

HEPER

HEPER DOGO Side LW6048.585-US Montage- und Bedienungsanleitung

HEPER

HEPER LW8034.003-US Montage- und Bedienungsanleitung

Maretti

Maretti VIBE S 14.6080.04.A Bedienungsanleitung

BEGA

BEGA 84 253 Handbuch

HEPER

HEPER MINIMO Montage- und Bedienungsanleitung

LIGMAN

LIGMAN BAMBOO 3 Bedienungsanleitung

Maretti

Maretti TUBE CUBE WALL 14.4998.04 Bedienungsanleitung

Maxim Lighting

Maxim Lighting Carriage House VX 40428WGOB Bedienungsanleitung

urban ambiance

urban ambiance UQL1273 Bedienungsanleitung

TotalPond

TotalPond 52238 Bedienungsanleitung

Donner & Blitzen

Donner & Blitzen 0-02661479-2 Bedienungsanleitung
