Harper 14A01 Programmierhandbuch
Turbo Vac TV60R
TURBO VAC 60RH
1-2024
OPERATOR’S & PARTS
MANUAL
Serial Number: 14A01 +
Part # 301026
Turbo Vac TV60R
Turbo Vac TV60R
Thank you for purchasing a Harper Turbo Vac.
TO THE OWNER OR OPERATOR:
As with all Harper products, the Harper Turbo Vac has been developed through tough design and
testing procedures to produce a machine that can be relied on. This manual gives assembly, op-
erating, and service information for models TV60RE and TV60RH. Please read and understand
all instructional material included with the Turbo Vac and its components before assembling and
operating the equipment.
A Turbo Vac can present hazards to an operator who follows unsafe procedures in either the opera-
tion or maintenance of the unit. Therefore, SAFETY WARNINGS are presented at certain locations
in the text.
SYMBOL: SAFETY WARNING!
MEANING: Failure to understand and obey this warning may result in injury to you or others.
Whenever this symbol is used, please pay very close attention to the information presented, and
make sure you fully understand. If you do not, contact your dealer or Harper Industries for clarifica-
tion.
SAFETY WARNING!
All shields and guards must be in place for proper and safe operation of this equipment.
Where they are shown removed in this manual, it is for purposes of illustration and instruc-
tion only. Do not operate this equipment unless all shields and guards are in place.
Harper Industries, Inc. is continually striving to improve the design and performance of its products.
We reserve the right to make changes in specifications and design without thereby incurring any
obligation relative to previously manufactured products.
© 2022 Harper Industries, Inc.
The Harper and Goossen names are registered trademarks of Harper Industries, Inc. All other brand and productnames are trade-
marks or registered trademarks of their respective companies.
1
Turbo Vac TV60R
2
LIMITED WARRANTY
Harper Industries, Inc. (HII) warrants to each purchaser of a new Harper Turbo Vac from
an authorized dealer or representative, that such equipment is free of manufacturer’s de-
fects in workmanship and materials which appear while in normal service for a period of
ONE YEAR commencing with delivery to the original user.
The obligation of HII under this warranty is expressly limited, at our option, to replacement
or repair at a service facility designated by Harper Industries or at the manufacturing plant
in Harper, KS. A part will be replaced after inspection discloses it to have been defective.
This warranty does not apply to defects caused by damage or unreasonable use (includ-
ing failure to provide reasonable and necessary maintenance, or by performing functions
without genuine Harper Turbo Vac accessories) while in the possession of the consumer.
Warranty is limited to parts, labor and ground freight delivery of replacement parts. HII
shall not be liable for the consequential damages of any kind, including but not limited to
consequential labor costs or transportation charges in connection with replacement or
repair of defective parts.
This warranty does not apply to parts subjected to misuse, abuse, alteration, improper or
inadequate maintenance, or normal wear (including belts, battery, chains, filters, knives,
brush and broom).
Engines are not covered under this warranty. Refer to manufacturer’s warranty for specific
warranty information. Harper Industries, its agents or representatives, make or imply no
other warranties.
Harper Industries makes no warranty with respect to trade accessories. They are subject
to the warranties of their respective manufacturers.
ANY IMPLIED OR STATUTORY WARRANTIES, INCLUDING ANY WARRANTY OR
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY
LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. HII makes no other ex-
press warranty, nor is anyone authorized to make any on behalf of HII.
For further information please contact your nearest Harper Turbo Vac dealer.
RECORDS
Date of Purchase ______ / ______ / ______
Dealer’s Name _________________________________
Dealer’s Phone _________________________________
Serial Number Machine __________________________
Serial Number Engine ___________________________
Turbo Vac TV60R
Table of Contents
OPERATOR SECTION
To the Owner or Operator...............................................
Warranty Statement........................................................
Table of Contents............................................................
Specifications..................................................................
Feature Introduction
TV60RE............................................................
TV60RH............................................................
General Safety Guidelines
Equipment & Controls......................................
Guards & Shields.............................................
Before Operation..............................................
During Operation..............................................
During Service & Maintenance.........................
Safety Decals...................................................
Replacement Parts...........................................
Gasoline...........................................................
Hydraulics........................................................
Specific Safety Guidelines
TV60RE............................................................
TV60RH............................................................
Set-up and Operation
TV60RE............................................................
TV60RH............................................................
Starting Operation............................................
Stopping Operation..........................................
Unloading Hopper............................................
Towing..............................................................
Adjustments
TV60RH Hydraulic Controls.............................
Level Hook-Up..................................................
Broom Height....................................................
TV60RE Blower Drive Belt................................
TV60RE Hydraulic Pump Belt...........................
Remote and Receiver.......................................
Service & Maintenance
Break-in Service...............................................
Lubrication........................................................
TV60RE Hydraulic Oil Reservoir.......................
TV60RE Hydraulic Oil Reservoir.......................
TV60RH Hydraulic Oil Cooler...........................
Remote Control................................................
Blower Liner.....................................................
Return Air Screens...........................................
TV60RE Service Schedule.............................................
TV60RH Service Schedule.............................................
Troubleshooting..............................................................
Optional Equipment........................................................
PARTS SECTION
Hydraulics
TV60RH Hydraulic Schematic..........................
Machine Hydraulics..........................................
Hydraulic Res., Valve, and Drive-TV60RH.......
Hydraulic Valve.................................................
Remote
Wiring Schematic TV60RH...............................
Remote and Receiver.......................................
Broom
Broom Wheel....................................................
Broom Lift.........................................................
Broom...............................................................
Finger Rotor Kit.................................................
Finger Rotor Assembly......................................
Air Return.........................................................
Air Return Screens...........................................
Fan Housing.....................................................
Structure
Hopper and Door..............................................
Frame...............................................................
Wheel Assembly...............................................
Decal Layout.....................................................
Dual Spacer Kit-Optional..................................
Edge Brush Kit-Optional...................................
1
2
3
4
5
7
9
9
9
9
10
10
11
11
11
12
12
13
13
14
14
14
15
16
16
16
17
17
18
20
20
21
21
22
22
22
23
24
25
26
27
1.1
1.2
1.3
1.4
2.1
2.2
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
4.1
4.2
4.3
4.4
4.5
4.6
3
Turbo Vac TV60R
Specifications
4
Safety Features Locking safety latches on all cylinders for service functions
Power Tractor PTO
Hydraulic System PTO-driven pump powers blower, broom and cylinders
Hydraulic Reservoir 20 gallons - Crown AW 46 hydrualic oil
Blower Drive Hydraulic motor - direct drive from PTO gear pump
Blower Fan • 25” diameter fan of abrasion-resistant steel
• 1½” shaft with self-aligned bearings supporting both ends
Housing Liner • Easy access to housing liner* for inspection and replacement
*UHMW poly-liner - Ultra High Molecular Weight Polyethylene
Broom Drive Hydraulic motor - direct drive
Broom 17” diameter X 60” wide pick-up broom with heavy-duty polyeth-
ylene bristles and adjustable gauge wheels
Bearings Greasable sealed bearings
Hopper 7 yard capacity
Wheels/Tires 6 - bolt steel wheels
Tires - 225 X 60R15 steel belted radials
Optional Duals Optional dual wheels are available for soft terrain
Controls Wireless RF (radio frequency) remote controls
Discharge Hydraulic dump with automatic latch mechanism
Hitch Adjustable height tongue with ball hitch and adjustable jackstand
Paint Durable 2-part polyurethane
Dimensions 164” long X 85” wide X 85” high
Weight 2250 lbs – 1023 kg
NOTE: Following publication of this manual certain changes in standard equipment and/or options may have occurred that would
not be included in these pages. Your Harper/Goossen dealer is the best source for up-to-date informaion.
Turbo Vac TV60R
Feature Identification
5
BALL
HITCH BROOM
Hydraulic Pump – The hydraulic pump on
the TV60RH is directly attached to the tractor
PTO. Always connect torque chain to tractor.
Torque Chain – The torque chain keeps the
hydraulic pump from moving when it is
hooked up to the tractor PTO.
Broom Motor – The broom motor turns the
broom clock-wise, throwing material forward
and upward into the air stream.
Broom – The broom rotates to rake up the
material from the turf.
Oil Cooler – The oil cooler prevents the
hydraulic oil from over-heating. Always keep
the fins free of debris.
Hydraulic Reservoir – The hydraulic reser-
voir on a TV60RH has a 20 gallon capacity.
Air Return – The air return allows air to be
recirculated, significantly reducing dust.
Hopper – The hopper stores up to seven
yards of collected material.
Ball Hitch – The TV60R is towed with a ball
hitch. Unit is not approved highway towing.
Manual & Remote Controls – All of the func-
tions on the Turbo Vac can be operated with
the manual controls or the remote controls.
MANUAL &
REMOTE
CRONTROLS
Turbo Vac TV60R
6
TV60RH - Hydraulic System
Hydraulic Reservoir Assembly
PTO Gear Pump on Tractor PTO
Blower Motor & Flow Control Valve
PTO Gear Pump (unit parked)
NOTE: The PTO gear pump should be
stored as shown in the above photograph
when the TV60RH is parked.
Turbo Vac TV60R
7
Equipment & Controls
• Before operating this equipment, read
and understand the Owner’s Manual.
• Altering the unit in any way that ad-
versely affects its safe operation, per-
formance or durability will void the
warranty and may cause hazardous
conditions.
• Know the location and function of all
controls and how to stop the equip-
ment quickly in an emergency before
you operate the Turbo Vac.
• Keep all nuts, bolts and screws tight to
ensure safe operation of equipment.
Guards & Shields
• Keep all safety devices in place and in
good operating condition.
• Replace all worn, damaged, unusable,
missing or lost safety shields and
guard before operating unit.
Before Operation
• Do not allow children near this ma-
chine.
• Make sure bolts in tongue are secure
and jack is in the transport position.
• Tire pressure should be 30-32 psi and
equal in both tires.
• Engine governor settings are preset
and should not be changed; any change
can damage moving parts and void
warranty.
• Before starting the machine, visually
inspect all nuts, bolts and other fasten-
ers to see that they are properly se-
cured.
• Nuts, bolts and other fasteners should
be checked after the first hour of op-
eration and every 8 to 10 hours there
after for proper alignment and tight-
ness.
• Make sure that all belts are in good
condition, and replace if necessary.
During Operation
• While operating the equipment, make
sure that no foreign objects such as
rocks, bottles or other hard materials
are in the path of the Turbo Vac.
• If an object should strike the broom or
blower mechanism causing an unusual
noise or vibration, shut the engine off
immediately and allow it to come to a
complete stop. Disconnect the spark
plug wire from the spark plug of the
power unit, and do the following:
1. Inspect for damage.
2. Repair or replace damaged parts.
3. Check for and tighten any loose
bolts, nuts, fasteners or parts.
• Keep the engine area clean and free
of debris and other accumulations.
• If the Turbo Vac should become
clogged, shut off the engine and allow
it to come to a complete stop. Discon-
nect the spark plug wire from the spark
plug of the power unit before attempt-
ing to remove the clog.
SAFETY WARNING!
Always keep a re extinguisher near the
Turbo Vac during operation and service.
SAFETY WARNING!
To prevent possible eye injury, always
wear SAFETY GLASSES while operating
or servicing the equipment.
General Safety Guidelines
Turbo Vac TV60R
8
During Service & Maintenance
SAFETY WARNING!
When working under the hopper the
cylinder safety lock should be engaged to
prevent the hopper from falling.
• To engage the cylinder safety lock, take
the pin out of the bracket on the hopper
and pull the handle down.
• The cylinder safety lock prevents the
hopper from being lowered so that
maintenance can be performed safely.
• When finished working under the hop-
per, disengage the safety lock, put the
handle back into the bracket on the
hopper and replace the pin.
SAFETY WARNING!
Attempting to lower the hopper while the
cylinder safety lock is engaged may cause
damage to the cylinder and/or the safety
lock mechanism.
SAFETY WARNING!
If it is necessary to get between the
hopper and the hopper door, set the door
prop to avoid being pinched.
• To set the door prop, pull the door open
and insert prop into pre-cut hole in door.
Safety Decals
• If safety related or instructional decals
become illegible or are removed, re-
place them immediately.
• If parts are replaced, make sure all
safety related or instructional decals
are present before the equipment is
operated again.
• New decals may be obtained from your
local Harper Dealer.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Harper Landwirtschaftliche Geräte Handbücher
Harper
Harper DewEze S3 Programmierhandbuch
Harper
Harper Butler Arm Bed A84X84 Bedienungsanleitung
Harper
Harper 2224P1 Bedienungsanleitung
Harper
Harper TURBO VAC 60RH Programmierhandbuch
Harper
Harper TURBO VAC 60HD Programmierhandbuch
Harper
Harper DewEze 600 Series Bedienungsanleitung
Harper
Harper Butler Beds Bedienungsanleitung
Harper
Harper TURBO VAC 60R-HD Programmierhandbuch
Harper
Harper Deweze Super Slicer Programmierhandbuch
Harper
Harper MultiLoader Produkthandbuch
