HID OMNIKEY 2061 Bedienungsanleitung
15370 Barranca Parkway
Irvine, CA 92618-2215
OMNIKEY®
2061 Bluetooth Reader
USER MANUAL
© 2010 HID Global Corporation. All rights reserved.
Firmware Version 1.30
March 23, 2010
2061-905, Rev A.1
2061-905_A.1 OMNIKEY 2061 Bluetooth Reader
User Manual, Firmware V1.27
Read Me First
About This Guide
This manual describes the OMNIKEY 2061 Bluetooth reader. This user manual describes the
reader configuration, operation and software installation.
See www.hidglobal.com/omnikey for additional information like a technical FAQ.
Cont a ct s
Europe, Middle East and Africa
HID Global Corporation, Ltd. (Haverhill, UK)
email: [email protected]
main: +44 (0) 1440 714 850
support: +44 (0) 1440 711 822
fax: +44 (0) 1440 714 840
HID GLOBAL, HID, the HID logo, OMNIKEY are the trademarks or registered trademarks of HID Global
Corporation, or its licensors, in the U.S. and other countries.
Con t ent s
Read Me First..........................................................................................................................................2
1Overview ....................................................................................................................................3
2Operation ...................................................................................................................................4
3Getting Started ..........................................................................................................................4
4Bluetooth Configuration Software ..........................................................................................6
5Conditions ...............................................................................................................................13
6Manual Installation..................................................................................................................15
Page 2 of 17 March 24, 2010
© 2010 HID Global Corporation. All rights reserved.
OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1
User Manual, Firmware V1.27
1 Overview
The OMNIKEY®2061 Bluetooth Reader is a Bluetooth connected reader that provides a contact
interface, which reads/writes to virtually any ISO7816-3 compatible contact smart card.
1 .1 Pa r t s List
Verify the OMNIKEY 2061Bluetooth Reader contents.
1 OMNIKEY 2061 Bluetooth reader
1 USB cable
1 Software CD
2 Belt Clips
1 Safety and Product Information Manual
Contact the dealer if your OMNIKEY 2061 Bluetooth reader package is incomplete.
1 .2 Sy st em Re qu ir e m e nt s
Operating System Windows®Vista®- 32-bit (x86)
- 64-bit (x64)
Windows 7 - 32-bit (x86)
- 64-bit (x64)
Windows XP®- 32-bit
- 64-bit
Hard Disk Space 50 MB
Video Adapter SXGA (1024 x 768) or higher-resolution recommended
Bluetooth Interface Microsoft®Bluetooth Stack
Toshiba®Bluetooth Stack
March 24, 2010 Page 3 of 17
© 2010 HID Global Corporation. All rights reserved.
2061-905_A.1 OMNIKEY 2061 Bluetooth Reader
User Manual, Firmware V1.27
2 Operat ion
The following describes the OMNIKEY 2061 Bluetooth reader operation.
3 Ge t t ing St art ed
3 .1 Soft w a r e I n st a lla t ion
Insert the software Installation CD. Click Install Bluetooth Reader Configuration. For new
software versions, go to http://www.hidglobal.com/omnikey.
3 .2 Ba t t e ry Ch a rging
Ensure the battery is fully charged before use. For a discharged battery, it takes approximately
four hours to charge.
To charge the battery, connect the OMNIKEY 2061 Bluetooth reader to a computer through the
enclosed USB cable.
3 .3 Re a de r Se t up
Define a common name for the reader before installation. See 4.2.3 Installation Properties, page 8
for details.
1. Connect the reader to the computer using the enclosed USB cable.
2. Switch on the reader by pressing the Power button.
3. Start the Bluetooth Reader Configuration Software. See Section 4 Bluetooth
Configuration Software, page 6for additional details.
Click Start > Programs > OMNIKEY > Bluetooth Reader Configuration.
4. From the Reader menu, click Select Reader…
Page 4 of 17 March 24, 2010
© 2010 HID Global Corporation. All rights reserved.
OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1
User Manual, Firmware V1.27
5. From the drop-down list, select the USB connected reader, click OK.
6. From the Reader menu, select Install Reader…
7. From the Installation dialog, click Start. Clicking Start pairs the reader and installs the
Bluetooth device driver.
8. If successful, the Bluetooth LED displays constant illumination.
March 24, 2010 Page 5 of 17
© 2010 HID Global Corporation. All rights reserved.
2061-905_A.1 OMNIKEY 2061 Bluetooth Reader
User Manual, Firmware V1.27
4 Bluet oot h Configu rat ion Soft w a re
The Bluetooth Configuration Software installs and manages your OMNIKEY 2061 Bluetooth
readers.
4 .1 Pr ofile M a nage m e n t
Using the Profile menu, setup the reader settings. Options include defining, storing and loading
different profiles.
The Profile concept maintains a mechanism for easily configuring a large number of OMNIKEY
2061 Bluetooth readers with one single Profile.
A Profile stores the configuration parameters of Parameter Sets. Manage the values of a
Parameter Set with the Installation Properties and Energy Saving Parameters dialogs.
If a Profile is not opened and no reader is selected the current Parameter Set is initiated with the
default parameters as defined in the default.ini file, stored in the installation directory.
Create a new profile by clicking Profile > New. The current Parameter Set is initiated with the
default parameters from default.ini. Save the new Profile by clicking Profile > Save or Profile >
Save As.
If opening an existing profile (click Profile > Open), the configuration parameters from the Profile
are read and stored in the current Parameter Set. Click Update Profile to modify the configuration
parameters of the opened Profile using Installation Properties and Energy Saving Parameters.
You cannot change a Profile when selecting a Profile and a Reader.
If simultaneously selecting a Profile and Reader the current Parameter Set always contains the
parameters from the Profile File. Therefore, it is possible to transfer the configuration parameters
from the current Parameter Set to the currently connected OMNIKEY 2061 Bluetooth reader.
From Installation Properties and Energy Saving Parameters, click Update Reader.
Page 6 of 17 March 24, 2010
© 2010 HID Global Corporation. All rights reserved.
OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1
User Manual, Firmware V1.27
4 .2 Rea der Ma na gem ent
Using the Reader menu you can install, select and configure a USB connected OMNIKEY 2061
Bluetooth reader.
4 .2 .1 Re a de r Se le ct io n
With the Select Reader dialog, select USB connected OMNIKEY 2061 Bluetooth reader. The list
box lists connected readers. The dialog shows also the vendor (VID), the product id (PID) and the
firmware version (FW) of the selected reader.
The USB path of the selected reader is shown as a suffix to the reader name. In the following
example, the USB path 0:2 indicates this reader is connected on the second USB port on the first
USB hub.
Reset Selection Deselects the currently selected reader.
Reset Reader Resets the currently selected reader.
Update List Updates the list of USB connected readers.
OK Approves the selected reader and loads the reader settings.
March 24, 2010 Page 7 of 17
© 2010 HID Global Corporation. All rights reserved.
2061-905_A.1 OMNIKEY 2061 Bluetooth Reader
User Manual, Firmware V1.27
4 .2 .2 Re a de r I n st a lla t ion
Install the OMNIKEY 2061 Bluetooth reader with the Installation dialog.
Note: Connect the reader using the USB cable and switch on.
Clicking Start pairs the reader and installs the Bluetooth device driver. After finishing the
installation process the reader is ready to use.
4 .2 .3 I n st a lla t io n Pr op er t ie s
The Installation Properties dialog configures the installation behaviour of the reader.
The default option, Accept Bluetooth Pairing from any host indicates that the reader accepts
pairing requests from computers which are currently not paired with the reader.
If the option Accept Bluetooth pairing from paired host only is set, it is impossible to pair the
reader with new computers.
Define the reader a friendly name using the friendly name field. The friendly name displays in the
Bluetooth Devices dialog of the Bluetooth stack currently in use.
Page 8 of 17 March 24, 2010
© 2010 HID Global Corporation. All rights reserved.
OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1
User Manual, Firmware V1.27
4 .2 .4 En e rg y Sa vin g Pa r am e t e rs
The Energy Saving Parameters dialog configures the reader settings affecting the power
consumption.
Timeouts are defined in seconds. If a timeout is set to zero, the timeout is deactivated. The
timeouts are deactivated while the reader is connected to a computer with a USB cable.
4 .2 .5 Re se t Re a de r Se t t in gs
Reset Reader Settings resets the active reader settings to default values. The default values are
stored in the file default.ini in the installation directory of the Bluetooth Configuration Software.
4 .2 .6 Set Re ader PI N
Set Reader PIN sets the OMNIKEY 2061 Bluetooth reader PIN. The PIN is required for pairing
your reader manually.
March 24, 2010 Page 9 of 17
© 2010 HID Global Corporation. All rights reserved.
2061-905_A.1 OMNIKEY 2061 Bluetooth Reader
User Manual, Firmware V1.27
4 .2 .7 Firm w ar e Upda t e
The Firmware Update dialog updates the reader firmware. New firmware images are available at
www.hidglobal.com/omnikey.
Select a firmware image by clicking Browse and going to the firmware file location. Select the
firmware file, click Download. The Firmware Update dialog shows the vendor ID (VID), the
product ID (PID) and the firmware build number of the selected firmware image.
4 .2 .8 Pair ed H ost s I nform a t ion
Paired Hosts Information displays information about the hosts paired with the reader. The left
column displays the index of the paired host. The right column displays the Bluetooth address of
the connected host radio.
Clear the list of paired hosts by clicking Reset.
CAUTION: When resetting the paired host information, the reader is no longer usable with
all hosts where it is installed.
4 .2 .9 Ba t t e ry St a t us
The Battery Status indicates the current battery status. 100% means the battery is fully charged.
Page 10 of 17 March 24, 2010
© 2010 HID Global Corporation. All rights reserved.
