HIK VISION DS-2CC1282P(N)-IT3 Bedienungsanleitung

IR Bullet Camera

User Manual

UD.6L0201D0089A01

IR Bullet Camera·User Manual

Thank you for purchasing our product. If there are any questions,

or requests, please do not hesitate to contact the dealer.

This manual applies to

Type

Model

Ⅰ

DS-2CC1282P(N)-IT3

DS-2CC12A2P(N)-IT3

Ⅱ

DS-2CC1282P(N)-IT5

DS-2CC12A2P(N)-IT5

This manual may contain several technical incorrect places or

printing errors, and the content is subject to change without notice.

The updates will be added to the new version of this manual. We

will readily improve or update the products or procedures

described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested for fire, shock or casualty hazards

as outlined in UL’s Standard(s) for Safety, UL60950-1. UL

Certification does not cover the performance or reliability of the

security or signaling aspects of this product. UL MAKES NO

REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS

WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS

PRODUCT.

0100001021208

IR Bullet Camera·User Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies w ith part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized

European standards listed under the Low Voltage Directive

2006/95/EC, the EMC Directive 2004/108/EC.

IR Bullet Camera·User Manual

2002/96/EC (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked w ith this

symbol, which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return the battery

to your supplier or to a designated collection point. For more

information see: www.recyclethis.info.

IR Bullet Camera·User Manual

Table of Contents

1 Introduction ........................................................................5

1.1 Product Features ......................................................5

1.2 Overview .................................................................6

2 Installation..........................................................................8

2.1 Wall Mounting ..........................................................8

2.2 Wiring .................................................................... 11

Appendix...............................................................................12

1 Glossary ................................................................... 12

2 Troubleshooting......................................................... 16

3 Technical Maintenances ............................................. 19

IR Bullet Camera·User Manual

1Introduction

1.1 Product Features

This series of camera adopts a new generation sensor with high

sensitivity and advanced circuit design technology. It features high

resolution, low image distortion and low noise, etc., which makes it

suitable for surveillance system and image processing system.

High-performance sensor and high resolution bring

high-quality image

IR LED enables the day/night surveillance

Day/Night auto switch

ATW, which brings high color rendition

Auto electronic shutter control to adapt to the different

surveillance environments

Auto gain control, adaptive brightness

High SNR brings high-quality image

Ingress protection: IP66

IR Bullet Camera·User Manual

1.2 Overview

Figure 1-1 Overview of Type ⅠBullet Camera

Table 1-1 Description

No.

Description

No.

Description

Sun Shield

Adjustable Screw

Lens

Power Cable

IR LED

Video Cable

IR Bullet Camera·User Manual

Figure 1-2 Overview of Type ⅡBullet Camera

Table 1-2 Description

No.

Description

No.

Description

Sun Shield

Adjustable Screw

Lens

Power Cable

IR LED

Video Cable

IR Bullet Camera·User Manual

2Installation

Before you start:

Please make sure that the device in the package is in good

condition and all the assembly parts are included.

Make sure that all the related equipment is power-off during

the installation.

Check the specification of the products for the installation

environment.

Check whether the power supply is matched w ith your AC

outlet to avoid damage.

If the product does not function properly, please contact your

dealer or the nearest service center. Do not disassemble the

camera for repair or maintenance by yourself.

2.1 Wall Mounting

IR bullet camera is w idely used in the low luminance indoor

environment, and wall mounting is recommended. We will take the

wall mounting as an example to explain the installation steps.

Note:Please make sure that the wall is strong enough to

withstand 3 times the weight of the camera and the bracket.

Steps:

1. Adjust the Sun Shield

IR Bullet Camera·User Manual

Push the sun shield to the outermost position and tighten the

adjustable screw.

Figure 2-1 Adjust the Sun Shield

2. Secure the Mount

Secure the wall mount to the wall with the screws.

Notes:

The wall mount you select should be at least 1.5 times longer

than the bullet camera.

If the wall is the cement wall, you need to insert the expansion

screws before you install the wall mount. If the wall is the

wooden wall, you can use self-tapping screw to secure the

wall mount.

Push
