Holux GR-239 Bedienungsanleitung

Packing List

Standard

•Holux GR-239 Wireless GPS

Receiver x 1

•Tool CD x 1

•Warranty Card x 1

Optional

•USB data cable

(Data cable can be used for data

transfer between GR-239 and

Notebook / PC.)

•MMCX active antenna .

Main Features

•20 parallel satellite-tracking

channels for fast acquisition and

reacquisition. *c

•Supports NMEA0183 v2.2 data

protocol or SiRF binary code.

•100% compatible with

Bluetooth™ Serial Port Profile

(SPP).

•Bluetooth™ version 1.2

compliant.

•Draws power from car battery;

no power adapter required.

*c：Cit. SiRF’s onginal chipset spec.

uick Guide

English

GR-239

Bluetooth GPS Receiver

Instructions for First Use

1. Adjust the Receiver Head

2. Insert the Receiver

3. Switch on the Power

•

Slide the power switch to the ON

position.

•

Carefully unscrew the locking screw

on the side of the receiver.

•Move the receiver head to the

required position.

•Screw the locking screw back

tightly.

•

Insert the GPS Receiver into your

car’s lighter slot.

•Adjust the receiver head vertically by

90 degrees.

4. Establish Bluetooth Link

Note about Bluetooth Connection

When you power on the GR-239, you must wait five seconds for Bluetooth to self-test

before a connection is established. Wait until the Bluetooth light begins to flash (once

every second). A Bluetooth link can now be established between a PDA and the GR-239.

5. Install and Open the GPS Viewer

Warning

Do not place the GR-239 under strong sunlight for a long time. Do not place

it in a high-temperature environment, or near heat radiating devices such

as a stove or radiator. Doing so will cause the device to malfunction. For

further information, refer to the user manual that comes on the supplied CD.

[Notes]

1. It is prohibited to operate this system while driving your car.

2. GPS signals are unable to go through non-transparent objects, such as

tall buildings, tunnels, underpasses, and forests. Bad weather may also

effect the signal reception. If your car window heat shield contains metal,

the receiver will not be able to pick up GPS signals.

•You can install the GPS viewer program from

the supplied CD to check current positioning

and satellite signal reception.

•Activate the GPS Viewer, set the Baud Rate

to 38400, and press Scan for automatic

scanning. Once you find the correct COM

port, choose GPS status to start viewing.

•Refer to the “Software Installation” section for

details if you have any problems with

installation and use.

To link the receiver with a PDA (Personal Digital

Assistant), follow these steps:

•Activate the Bluetooth Manager, select

Search and then link.

•Select the HOLUX GR-239 icon and choose

SPP slave to establish the Bluetooth link.

•Refer to the “Software Installation” section in

the user manual for further details if you have

any problems establishing the link.

3. All wireless communication products, such as mobile phones and speed

limit warning systems will interfere with the communication satellite and

will affect signal reception.

4.Before you setting, while the car is stationary, ensure that you have

searched for and fixed your position using the positioning function.

5. For further information, please read the user’s manual in the supplied CD.

6.GR-239 PASSKEY – 0000

(For security, some PDAs will prompt users for the GR-239 Passkey)
