Chartwell

52 in Ceiling Fan

Owner’s Manual

Chartwell

Ventilador de Techo de 1,32 m

Manual del Propietario

AK410-CB

120 V~ 60 Hz 78 W

Read and follow all the instructions

before using this product.

Chartwell by Home Decorators Collection

ongratulations on your

purchase of a Home

Decorators Collection

ceiling fan, Your new fan will be a

beautiful addition to your home,

and will keep you comfortable

throughout the year.

The Home Decorators Collection

Fan Company offers a wide variety

of ceiling fans. We offer combinations

of wood and brass finishes, solid

designer colors, and our unique

glass and crystal designs.

A large selection of light fixtures

and light kits is also available. Ask

your dealer about other accessories

that will allow you to further customize

your fan.

We’re certain that your Home

Decorators Collection fan will

provide you with many years of

comfort, energy savings and

satisfaction. To ensure your

personal safety and to maximize

the performance of your fan, please

read this manual thoroughly.

VENTILADOR DE TECHO / CEILING FAN

Marca / Brand: Home Decorators Collection

Modelo / Model: 170 842 (AK410-CB)

120 V ~ 60 Hz 78 W

Consumo de energía por unidad de tiempo en operación

(Energy Consumption): 87.3Wh

Importador / Importer: SERVICIOS HOME DEPOT, S. DE R.L. DE C.V.

Ricardo Margain 605, Santa Engracia, San Pedro Garza García, Nuevo León, C.P.

66267 Tel. / Phone: 800 004 6633

Lea y siga todas las instrucciones de seguridad y operación antes de usar este

aparato / Read and follow all the instructions of security and operation before using

this product

Cont. 1 Ventilador / Fan Hecho en / Made in: China

Requiere ensamblaje / Assembly required

52” CHARTWELL

Ceiling Fan by HDC

Date Purchased

Store Purchased

Model No.

Serial No.

Vendor No.

UPC

Table of Contents

Safety Rules . . . . . . . . . . . . . . . . . . . . 1

Unpacking Your Fan . . . . . . . . . . . . . . 2

Installing Your Fan . . . . . . . . . . . . . . . 3

Operation . . . . . . . . . . . . . . . . . . . . 11

Care of Your Fan . . . . . . . . . . . . . . . . 13

Troubleshooting . . . . . . . . . . . . . . . . . 13

Specifications . . . . . . . . . . . . . . . . . . 15

170 842 (AK410-CB)

548810

840059610078

Thank you for purchasing our ceiling fan. This product has been

manufactured with the highest standards of safety and quality.

Safety Rules - Read and Save These Instructions

To reduce the risk of electric shock, insure electricity has been turned

off at the circuit breaker or fuse box before beginning.

All wiring must be in accordance with the National Electrical Code

“ANSI/NFPA 70” and local electrical codes. Electrical installation should

be performed by a qualified licensed electrician.

The outlet box and support structure must be securely mounted and

capable of reliably supporting a minimum of 35 lbs (15.9 kg) or less.

Use only UL-listed outlet boxes marked “FOR FAN SUPPORT”.

The fan must be mounted with a minimum of 7.55 ft (2.3m) clearance

from the trailing edge of the blades to the floor.

Avoid placing objects in the path of the blades.

To avoid personal injury or damage to the fan and other items, be cautious

when working around or cleaning the fan.

Do not use water or detergents when cleaning the fan or fan blades. A dry

dust cloth or lightly dampened cloth will be suitable for most cleaning.

After making electrical connections, spliced conductors should be turned

upward and pushed carefully up into outlet box. The wires should be spread

apart with the grounded conductor and the equipment-grounding conductor

on one side of the outlet box and ungrounded conductor on the other side of

the outlet box.

All set screws must be checked and retightened where necessary before

installation.

The appliance is not to be used by persons (including children) with reduced

physical, sensory or metal capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction. Children should be

supervised to ensure that they do not play with the appliance.

Instructions for the use of the apparatus according with NOM-024-SCFI, are

provided with the apparatus.

10.

11.

TO REDUCE THE RISK OF PERSONALL INJURY, DO NOT BEND THE BLADE

ARMS (ALSO REFERRED TO AS FLANGES), WHEN INSTALLING THE

BRACKETS, BALANCING THE BLADES OR CLEANING THE FAN. DO NOT

INSERT FOREIGN OBJECTS IN – BETWEEN ROTATING FAN BLADES.

WARNING

TO REDUCE THE RISK OF ELECTRIC SHOCK, THIS FAN MUST BE INSTALLED

WITH AN ISOLATING WALL CONTROL / SWITCH.

WARNING

TO REDUCE THE RISK OF PERSONAL INJURY, USE ONLY THE SCREWS

PROVIDED WITH THE OUTLET BOX.

CAUTION

CHANGE OR MAINTAIN LED LIGHT KIT SHALL BE PERFORMED BY THE

MANUFACTURER, ITS SERVICE AGENT OR DULY QUALIFIED PERSONS.

NOTE

Unpacking Your Fan Unpack your fan and check the contents. You should have the following items:

A B

Set of blades (5)

Canopy assembly

Ball/downrod assembly

Coupling cover

Fan motor assembly

Blade arms (5)

20 watt LED Light kit

Glass shade

Receiver

Remote control

23A 12V battery

10.

11.

WARNING

DO NOT INSTALL OR USE FAN IF ANY

PART IS DAMAGED OR MISSING.

CALL TOLL FREE 800-004-6633.

This fan includes a 20W LED light. The purchaser should return the fan to the original

store of purchase during the warranty period in case of the light not working.

Blade Attachment Hardware

(7 Screws, 7 Lock Washers)

Electrical Hardware

(3 Plastic Wire Nuts)

Blade Attachment Hardware

(16 Screws, 16 Fiber Washers)

Blade Attachment Hardware

(11 Screws with Lock Washers)

Electrical Hardware

(3 Plastic Wire Nuts)

Extension cord

10 11

23A 12V

C D

3 41 2

DIP

Figures 1~3 are examples of different ways to

mount the outlet box.

Outlet box

Figure 2

Figure 1

NOTE: You may need a longer downrod to

maintain proper blade clearance when installing on

a steep, sloped ceiling. The maximum angle

allowable is 18 °.If the canopy touches downrod,

remove the decorative canopy bottom cover and

turn the canopy 180 °before attaching the canopy

to the mounting plate.

To hang your fan where there is an existing fixture

but no ceiling joist, you may need an installation

hanger bar as shown in Figure 4 (available at any

Home Depot store).

Ceiling

mounting

plate

Provide strong support

Recessed

outlet box

Figure 3

Figure 4

Installing Your Fan

If there isn't an existing NOM listed mounting

box, then read the following instructions.

Disconnect the power by removing fuses or

turning off circuit breakers.

Secure the outlet box directly to the building

structure. Use appropriate fasteners and building

materials. The outlet box and its support must be

able to fully support the moving weight of the fan

(at least 35 lbs). Do not use plastic outlet boxes.

Tools Required

Mounting Options

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR PERSONAL INJURY, MOUNT FAN

ONLY TO AN OULET BOX MARKED ACCEPTABLE

FOR FAN SUPPORT AND USE THE MOUNTING

SCREWS PROVIDED WITH THE OULET BOX.

OUTLET BOX COMMONLY USED FOR THE

SUPPORT OF LIGHTING FIXTURE MAY NOT BE

ACCEPTABLE FOR FAN SUPPORT AND MAY NEED

TO BE REPLACED. CONSULT A QUALIFIED

ELECTRICIAN IF IN DOUBT.

Phillips screwdriver, straight slot screwdriver, step

ladder and wire cutters.

Figure 6

REMEMBER to turn off the power. Follow the

steps below to hang your fan properly.

Hanging the Fan

Remove the canopy bottom cover from the

canopy by turning the cover counterclockwise.

(Figure 5)

Remove the mounting bracket from the canopy

by loosening canopy mounting screws a half

turn from the screw head. Next, turn the canopy

counterclockwise to remove the mounting

bracket from the canopy. (Figure 5)

Remove the cotter pin and clevis pin, and loosen

the two collar set screws from the fan motor

assembly collar. (Figure 6)

Take out the setscrew located in the hanger ball,

lower the hanger ball and remove the cross pin.

Remove the hanger ball from the hanger

ball/downrod assembly. (Figure 6)

Remove the ground lead from the downrod

assembly. (Figure 6)

NOTE:If a longer downrod is needed, take

out the screw located in the hanger ball, lower

the hanger ball and remove the pin, remove all

3 pieces from the downrod and assemble them

onto the new longer downrod before proceeding

step 3. (The longer downrod is available at

any Home Depot store)

Carefully feed the motor wires up through the

downrod. Thread the downrod into the collar.

Align the holes and replace the clevis pin and

cotter pin. Tighten the two collar setscrews.

(Figure 8)

Slip coupling cover, canopy bottom cover, and

canopy onto the downrod. Carefully reinstall

the hanger ball onto the downrod and reinstall

the ground lead onto the downrod, being sure

that the cross pin is in the correct position, the

setscrew is tightened and wires are not twisted.

(Figure 8)

Figure 5

WARNING

FAILURE TO PROPERLY INSTALL COTTER

PIN AS NOTED IN STEP 6 COULD RESULT IN

FAN LOOSENING AND POSSIBLY FALLING.

Clevis pin

Downrod

Ground lead

Set screws

Hanger ball

Cotter pin

Cross pin

Set screw

Motor collar

Mounting

Bracket

Ceiling Canopy

Canopy Bottom

Cover

Installing Fan to the

Electrical Box

WARNING

THE TAB IN THE RING MUST REST IN THE

GROOVE OF THE HANGER BALL AS FIGURE 10.

FAILURE TO PROPERLY SEAT THE TAB IN THE

GROOVE COULD CAUSE DAMAGE TO WIRING.

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR OTHER PERSONAL INJURY. MOUNT

FAN ONLY TO AN OUTLET BOX OR SUPPORTING

SYSTEM MARKED ACCEPTABLE FOR FAN

SUPPORT AND USE THE MOUNTING SCREWS

PROVIDED WITH THE OUTLET BOX.

Pass the 120-volt supply wires through the

center hole in the ceiling mounting bracket as

shown in Figure 9.

Attach the mounting bracket on the outlet box

by sliding the mounting bracket over the screws

provided with the outlet box. (Figure 9)

Securely tighten the two mounting screws.

(Figure 9)

Carefully lift the fan assembly up to the

ceiling mounting bracket and seat the hanger

ball in the mounting bracket socket. Make

sure the tab on the mounting bracket socket is

properly seated in the groove in the hanger

ball (Figure 10). This will help to balance the

ceiling fan.

Figure 10

Figure 9

Figure 8

Pin in locked

position

Clevis pin

Ceiling canopy

Hanger ball

Set screw

Cross pin

Downrod

Ground lead

Coupling cover

Canopy Bottom

Cover

Motor wires

Motor

collar

Tighten

screws

firmly

Cotter pin

Extension cord

120V

Wires

Ceiling mounting

bracket

NOM listed

outlet box

Mounting

screws (Supplied

with outlet box)

Groove

Tab

3 41 2

DIP

Figure 12

Making the Electrical

Connections

Remove the battery cover on the back of the

remote control by pressing firmly on the arrow

and sliding the cover off.

Slide the code switches to your choice of either

up or down. The factory setting is up.

Install one 23A 12V batteries (included).

Setting the Code on the Remote: (Figure 11)

Setting the Code on the Receiver: (Figure 11)

After checking the switches, insert the receiver

into the mounting bracket with the flat side of

the receiver facing the ceiling. (Figure 12)

Slide the code switches on the receiver to the

same positions as set on the remote control.

Figure 11

NOTE

THE FREQUENCIES ON YOUR RECEIVER AND

REMOTE CONTROL HAVE BEEN PRESET AT THE

FACTORY. BEFORE INSTALLING THE RECEIVER,

MAKE SURE THE DIP SWITCHES ON THE

RECEIVER AND REMOTE CONTROL ARE SET TO

THE SAME FREQUENCY. THE DIP SWITCHES ON

THE REMOTE CONTROL ARE LOCATED INSIDE

THE BATTERY COMPARTMENT.

NOTE

THE BATTERY WILL WEAKEN WITH AGE AND

SHOULD BE REPLACED BEFORE LEAKING TAKES

PLACE AS THIS WILL DAMAGE THE REMOTE

CONTROL. DISPOSE OF THE USED BATTERY

PROPERLY AND KEEP THE BATTERY OUT OF

THE REACH OF CHILDREN.

Replace the battery cover on the remote

control.

Remote control

Receiver

23A 12V

Receiver Ceiling

Mounting

Bracket

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Home Decorators Collection Lüfter Handbücher

Home Decorators Collection

Home Decorators Collection FOLSOM YG523-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection DELMORE 56054 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 56047 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection EMSWELL 52-INCH Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 59201 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection EASTON N381B-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection DANIEL 52179 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection N383B-MBK Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 52111 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection STONEMILL LED Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection GAMALI 60-FORY Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection HANLON YG533-SST-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 1009HDCGLDI Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 56006 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection SHERIDAN 54-SHAN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection WINDWARD IV Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection VIRGINIA HIGHLAND YG588-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection ALTURA 60-ATO Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection WESLEY 1008624855 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 56072 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 52170 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection BANNERET Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection CHASEWOOD 59724 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection KENSGROVE II N608A-BN Bedienungsanleitung

Beliebte Lüfter Handbücher anderer Marken

ELTA FANS

ELTA FANS H03VV-F Bedienungsanleitung

Hunter

Hunter 20714 Gebrauchsanweisung

Emerson

Emerson CARRERA VERANDA CF542ORB00 Bedienungsanleitung

Hunter

Hunter Caraway Gebrauchsanweisung

Panasonic

Panasonic FV-15NLFS1 Bedienungsanleitung

Kompernass

Kompernass KH 1150 Bedienungsanleitung

VES

VES FALA100/12V/TR Bedienungsanleitung

Vertiv

Vertiv Liebert DCD Bedienungsanleitung

Westinghouse

Westinghouse GFP Series Bedienungsanleitung

Venmar

Venmar KUBIX HRV PLUS Series Bedienungsanleitung

Maico

Maico ECR 31 Bedienungsanleitung

Sonnenkonig

Sonnenkonig Dinky Bedienungsanleitung

S&P

S&P ECOWATT HXBR Bedienungsanleitung

Wider

Wider IMP03369BH Bedienungsanleitung

Panasonic

Panasonic F-60DHN Bedienungsanleitung

Hinkley

Hinkley HIGHLAND Bedienungsanleitung

Broan

Broan 766BN Bedienungsanleitung

Premium

Premium PFS16022 Montageanleitung
