Home Decorators Collection 23422 Bedienungsanleitung

Page

2 Lights Exterior Wall Lantern

Home Depot SKU XXX-XXX (UPC XXXXXXXXXXXX)

(Dark Rubbed Bronze)

INSTRUCTION MANUAL

Page

Thank you for purchasing this Home Decorators Collection exterior wall

lantern. This product has been manufactured with the highest standards of

safety and quality. The finish of this lantern is weather resistant but over time

will naturally weather and fade.

FEATURES:

1. Easy and Economic Maintenance.

2. Weather Resistant Body.

3. ETL listed for Wet Location.

4. Easy to Install.

QUESTIONS, PROBLEMS, MISSING PARTS:

Before returning to your local Home Depot, please call our Customer Service

Team at 1-800-986-3460 or visit www.homedepot.com. Please reference your

SKU XXX-XXX Dark Rubbed Bronze fixture or UPC XXXXXXXXXXXX

Dark Rubbed Bronze fixture.

Page

CAUTION:

1. Before starting installation of this fixture or removal of a previous fixture,

disconnect the power by turning off the circuit breaker or by removing the

fuse at the fuse box.

2. CONSULT A QUALIFIED ELECTRICIAN IF YOU HAVE ANY

ELECTRICAL QUESTIONS.

3. If you have any non-electrical questions about this fixture, please contact

our Customer Service Team at 1-800-986-3460 or visit

www.homedepot.com. Please reference your SKU XXX-XXX Dark

Rubbed Bronze fixture or UPC XXXXXXXXXXXX Dark Rubbed

Bronze fixture.

4. Keep your receipt and these Instructions for Proof of Purchase.

TOOLS REQUIRED FOR ASSEMBLY & INSTALLATION

(Not included):

Light Bulb Safety goggles Silicon Rubber Sealant Wire strippers

2*60 Watt maximum for exterior use

Flathead screwdriver Phillips screwdriver Electrical tape Wire cutters

Page

PARTS INCLUDED FOR ASSEMBLY (parts are not to scale):

1 Finial (#6) 1 Metal Ring (#1) 1 Bottom Holder (#5) 2 Cap Nut (#7)

ASSEMBLY INSTRUCTIONS:

1. Shut off power at the fuse box or circuit breaker box, if necessary remove old

fixture and all mounting hardware from outlet box.

2. Carefully unpack your new fixture and lay out all the parts on a clear area, Take

care not to lose any small parts necessary for installation.

3. Install light bulbs in accordance with the fixtures specifications. (DO NOT

EXCEED THE MAXIMUM WATTAGE RATING!!)

4. Put the Metal Ring (#1), Glass Shade (#4), Bottom Holder (#5) over the bulb

cluster and screw the Finial (6) with nipple into the Extended Nut (#3).

Page

ASSEMBLY:

1.Metal Ring

2.Light Bulb

3.Extended Nut

4.Glass Shade

5.Bottom Cover

6.Finial

7.Cap Nut

8.Back Plate

Page

PARTS INCLUDED FOR INSTALLATION (parts are not to scale):

1 Ground Screw (#13) 2 Outlet Box Screws (#9) 2 Mounting Screws (#11)

1 Circular Strap (#10) 3 Wire Connectors (#14)

INSTALLATION INSTRUCTIONS:

1. Screw the two Mounting Screws (#11) into the circular strap (#10). Mount the circular

strap (#10) to the Outlet Box (#12) using the two provided Outlet Box Screws (#9). [Make

sure the threads of the Mounting Screws (#11) are facing outside when the circular strap

(#10) is attached to the Outlet Box (#12).]

2. Connect the white wire from the fixture to the white wire from the Outlet Box (#12), and

the black wire from the fixture to the black wire from the Outlet Box (#12). Cover the two

wire connections using the two provided Wire Connectors (#14). Wrap the two wire

connections with electrical tape for a more secure connection. If your outlet box has a

ground wire (green or bare copper), connect fixture s ground wire to it using the wire

connector (#14). Otherwise connect the copper ground wire from the fixture to Ground

screw (#13) on the circular strap (#10). Note: If you have electrical questions, consult

your local electrical code for approved grounding methods.

3. Mount the body of the fixture on the wall by aligning the protruding Mounting Screws

(#11) all the way through the holes on the Back Plate (#8). Be careful not to pinch any of

the wires between the fixture and the Outlet Box (#12). Tighten the fixture to the wall by

screwing the two cap nut (#7) onto the two protruding Mounting Screws (#11).

4. Once the fixture is mounted on the wall, caulk the space between the wall and the upper

3/4 area of the Back Plate to prevent water seeping into the Outlet Box (#12). Leave the

bottom 1/4 area un-caulked for drainage of any water which might leak into the enclosure.

5. Installation is complete. Turn on the power at the circuit breaker or fuse box. Turn the

light switch on to activate the fixture.

Page

INSTALLATION:

13.Ground Screw

12.Outlet Box

11.Mounting Screw

10.Circular Strap

9.Outlet Box Screw

8.Back Plate

14.Wire Connector

7.Cap Nut

Page

TROUBLESHOOTING:

PRODUCT MAINTENANCE:

To clean the outside of the fixture, use a dry or slightly dampened clean cloth (use clean

water, never a solvent) to wipe the glass and surface of the fixture.

2. To clean the inside of the fixture, first disconnect

power to the fixture by turning off the

circuit breaker or by removing the fuse at the fuse box. Next, use a dry or slightly

dampened clean cloth (use clean water, never a solvent) to wipe the inside glass and interior

surface of the fixture.

3. Do not use

any cleaners with chemicals, solvents or harsh abrasives. Use only a dry soft

cloth to dust or wipe carefully.

LIMITED WARRANTY

The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship for a period

of three (3)

years from date of purchase. This warranty applies only to the original consumer purchaser and only to

products used in normal use and service. If this product is found to be defective, the manufacturer s only

obligation, and your exclusive remedy, is the

repair or replacement of the product at the manufacturer s discretion,

provided that the product has not been damaged through misuse, abuse, accident, modifications, alterations,

neglect or mishandling. This warranty shall not apply to any product that is

found to have been improperly

installed, set-

up, or used in any way not in accordance with the instructions supplied with the product. This

warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence, alterat

ion,

or faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not

apply to the finish on any portion of the product, such as surface and/or weathering, as this is considered normal

wear and tear. The

manufacturer does not warrant and specially disclaims any warranty, whether express or

implied, of fitness for a particular purpose, other than the warranty contained herein. The manufacturer

specifically disclaims any liability and shall not be liable for

any consequential or incidental loss or damage,

including but not limited to any labor / expense costs involved in the replacement or repair of said product.

Possible Cause Corrective Action

1. Bulb is burned out. 1. Replace light bulb.

2. Power is off. 2. Make sure power

supply is on.

3. Faulty wire connection. 3. Check wiring.

4. Faulty switch. 4. Test or replace switch.

Bulb will not light.

Fuse blows or circuit

breaker trips when light

is turned on.

Crossed wires or power wire

is grounding out. Check wire connections.

Page

2 Luz Exterior de pared

Home Depot SKU XXX-XXX (UPC XXXXXXXXXXX)

(Negro Frotado Bronce)

MANUAL DE INSTRUCCIONES

Page

Gracias por la compra de este accesorio Home Decorators Collection Linterna

de pared para el exterior Este producto ha sido fabricado con los más altos

niveles de seguridad y calidad. El acabado de esta linterna es resistente a la

intemperie, pero con el tiempo se va ir desvaneciendo naturalmente.

CARACTER STICAS:

1. Fácil y económico mantenimiento.

2. Resistente a la intemperie.

3. ETL para lugares mojados.

4. Fácil de instalar.

Preguntas, problemas, piezas faltantes:

Antes de regresar a su oficina local de Home Depot, llame a nuestro Servicio

de Atenci ón al 1-800-986-3460 o visite www.homedepot.com. Por favor,

referir a SKU XXX-XXX Negro Frotado Bronce fixture or UPC

XXXXXXXXXXXX Negro Frotado Bronce fixture.
