1. Grasp clear tube firmly and turn handle counterclockwise to unscrew.
Remove piston from clear outer tube. NOTE: If paint is on the piston
remove paint with a damp rag.
2. Take off and discard old quad-rings. Install new quad-rings and
lubricate with petroleum jelly.
3. Insert inner handle into outer handle and push together. Be careful not
to pinch o-rings. To reassemble, hold the tube securely and turn the
handle clockwise until secure.
PaintStick EZ-Twist Piston
1. Separate inner and outer handles by quickly pulling apart. If you
cannot separate, set PaintStick on floor, put your foot on collar and
roll to loosen.
2. Take off and discard old o-rings. Install new o-rings and lubricate with
petroleum jelly.
3. Insert inner handle into outer handle and push together. Be careful not
to pinch o-rings.
PaintStick Piston
1. Pop out retainer with a screwdriver. Remove foam wiper and pry out
valve.
2. Discard old parts. Clean area. Install new valve and wiper. Press in
retainer.
3. Put a small amount of petroleum jelly into the fill port to lubricate the
foam wiper.
PaintStick & PaintStick EZ-Twist Valve Body
PaintStick®& PaintStick®EZ-Twist®
Tune-up Kit Instruction Sheet
DO NOT REMOVE END CAPS WITH A
SCREWDRIVER!
For Snap Cap End Caps
For Standard End Caps
3. Remove inner end cap by inserting the frame at an angle into the inner end cap about 1".
Pull gently towards you to remove. Remove spacer.
1. Remove roller from frame. Pull frame out from inner end cap until a snap is heard, or lightly tap outside rim
of end cap with hammer. Use extreme caution - do not hit black ring on frame.
2. Remove roller cover from frame. Remove spacer
from frame.
First Determine if your PAINTSTICK or
PAINTSTICK EZ-TWIST came with or without
a snap cap frame:
A. WITHOUT snap cap frame – Standard
B. WITH snap cap frame
4. Remove outer end cap by inserting the frame inside the roller cover at a slight angle. Gently push to snap
off the outer end cap from the frame.
5. Discard old end caps. Using petroleum jelly,
lubricate outer and inner end caps. Assemble
roller cover.
6. If the fit is loose apply tape to the circumference
of the end caps to prevent paint from leaking
during operation. See picture for the correct
placement of the tape. Masking tape or plumbers
tape work well.
7. Put roller cover back onto frame until a snap
is heard.
Consult PaintStick or PaintStick EZ-Twist
instruction manual for further information.
A
B
