Honeywell DACT-E3 Technisches Handbuch

DACT-E3

Digital Alarm Communicator Transmitter

Product Installation Document

Document 9000-0581:J6 12/16/2019 ECN 19-0648

Section 1: Description

The DACT-E3 (Digital Alarm Communicator Transmitter) sub-assembly is a digital communications circuit. It transmits and

verifies digital signals over the telephone network to a Central Station. The DACT-E3 is compatible with the following digital

signaling formats, and complies with FCC Part 8, Telecommunications Standards for DC and AC Ringer.

It is used as the communications circuit with the following modules and systems.

The DACT-E3 can be installed in a remote location via a local RS-485 interface. Figure 1.1 illustrates the DACT-E3 sub-assembly

and Figure 1.2 shows the DACT-E3 circuit board PCB.

CAUTION 1: STATIC SENSITIVE EQUIPMENT:

THIS EQUIPMENT IS SENSITIVE TO STATIC ELECTRICITY. IT MAY BE DAMAGED IF NOT PROPERLY HANDLED.

TRANSPORT AND STORE THIS UNIT IN A STATIC-SHIELDING BAG.

FAILURE TO OBSERVE THIS REQUIREMENT COULD CAUSE LATENT DAMAGE TO THE EQUIPMENT WHICH

MIGHT NOT MANIFEST ITSELF UNTIL AFTER THE EQUIPMENT IS PLACED IN SERVICE.

CAUTION 2: DISCONNECT ALL POWER:

REMOVE ALL SOURCES OF POWER BEFORE SERVICING, REMOVING OR INSTALLING ANY UNITS.

• SIA DC8 • 3+1 2300 Hz • 4+2 2300 Hz • Ademco Contact ID

• SIA DCS20 • 4+2 1400 Hz • 3+1 1400 Hz

E3 Series® Systems Retrofit Kits S3 Series System

• E3 Series Broadband/Classic Systems • IF600 Retrofit B-Slim • S3 Series (Small Addressable Panel)

• ILI-MB-E3 (Intelligent Loop Interface-

Main Board)

• 600 XL Retrofit Kit

• ILI95-MB-E3 (Intelligent Loop

Interface95-Main Board)

• 7200 Retrofit Kit

Figure 1.1 DACT-E3 Transmitter Sub-Assembly Figure 1.2 DACT-E3 Transmitter PCB

TB1

TB2

T V S2 T V S1

PTC1

PTC2

TP4

STANDBYLINE2

STAT US

LINE1

STA TUS

TP1

TP2

LED3 LED2 LED1

TP3

2DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019

Section 2: Installation

2.1 Standards

This product is intended to be installed in accordance with the following standards.

National Fire Protection Association

UL Standards UL 864 9th and 10th Edition

• Per the UL Continuing Certification Program, UL 864 9th edition fire alarm control equipment will retain certification after the

roll-out of UL 10th edition (12/2/2018).

• Installations of UL 864 10th Edition certified equipment are permitted to use UL864 9th Edition certified equipment when

approved by the local Authority Having Jurisdiction (AHJ).

For product compliance, refer to the UL/ULC listing cards located on the UL online certification directory.

https://iq.ulprospector.com

Underwriters Laboratories® Standard

• UL-2572 MNS Mass Notification, Second Edition

2.2 Installation Requirements

Components should be installed per the following requirements:

• Installations are to be indoors only, in dry locations, protected from rain, water, and rapid changes in temperature that could

cause condensation. Equipment must be securely mounted on rigid, permanent walls.

• Operating temperature shall not exceed the range of 32° to 120° F (0 to 49° C).

• Operating humidity shall not exceed 93% non-condensing at 90° F (32° C).

• There should be adequate space around the installation to allow easy access for operation and servicing.

• All sub-assemblies and components are to be located in compliance with the local, the national codes and the manufacturer’s

recommendations.

• All installation field wiring shall be in compliance with the local, the national codes and the manufacturer’s recommendations.

• Use the Architects and Engineering Specifications for detailed information on your Facility’s Configuration.

• Installers must be Gamewell-FCI Factory Certified to program this product. For additional information on this product, contact

the Gamewell-FCI Customer Support to schedule the Factory Certified Training.

• AHJ Authority Having Jurisdiction • NFPA 72 National Fire Alarm Code

• NFPA 70 National Electrical Code • NFPA 101 Life Safety Code

DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019 3

2.3 DACT-E3 Installation

1. Remove the DACT-E3 sub-assembly from its static-shield bag, observing proper static protection measures

2. Visually inspect the unit for damage.

If any components are damaged, notify the shipping carrier immediately. Report missing components to the Gamewell-FCI

Customer Service.

3. Use the Hardware Kit provided with the unit.

4. The DACT-E3 sub-assembly can be installed in several types of configurations in the E3 Series and SLP-BB cabinets.

For additional information on the DACT-E3 installation, refer to the following documents:

– E3 Series Fire System (Expandable Emergency Evacuation System) UL Listing Document, P/N:LS10080-051GF-E

– S3 Series System (Small Addressable Fire Alarm Control Panel) UL Listing Document, P/N: LS10005-051GF-E

– E3 Series Cabinets B, C, D, Retrofits, DR-C4/DR-D4, and EQ Cabinets Installation Instructions, P/N:LS10082-000GF-E

– E3 Series Remote Annunciator Display Cabinets, P/N:LS10083-000GF-E

2.3.1 DACT-E3 Installation Assembly Options

Table 2.3.1.1 lists the systems, cabinets, and mounting plates that use the DACT-E3.

E3 Series® is a registered trademark of Honeywell International Inc. Ademco® is a registered trademark of Ademco Inc.

E3 Series Fire S3 Series Retrofit

Cabinet A1 Backbox SLP-BB Cabinet, B Backbox (P/N:SLP-BB) IF600 Retrofit B-Slim Cabinet

Cabinet B Backbox S3 Series, B-Size Cabinet (P/N: E3BB-BB/RB) 600 XL Retrofit Cabinet C Backbox

B-Slim Cabinet Inner Door E3 Series, Cabinet A2 (P/N: E3BB-BA2/RA2) 7200 Cabinet B E3-ILI-C Plate

Cabinet C,E3-INX-C Plate E3BB-FLUSH-LCD Cabinet A2 (P/N: E3BB-FLUSH-LCD) 7200 Cabinet C E3-INCC-D Plate

Cabinet C, E3-INCC-C Plate

Cabinet C, E3-ILI-C Plate

Cabinet D, E3-INX-D Plate

Cabinet D, E3-INCC-D Plate

Cabinet D, Command Center

Cabinet D, Voice Evacuation

Note: For information on the DACT-E3 installation in the E3 Series, Fire, SLP or Retrofit Kits system cabinets and plates, refer to

the S3 Series (Small Addressable FACP) System UL Listing Document, P/N: LS10005-051GF-E.

Table 2.3.1.1 DACT-E3 Cabinet and Mounting Plate Configurations

4DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019

2.3.1 DACT-E3 Installation Configurations

2.3.1.1 DACT-E3 Installation in an E3 Series, Cabinet Configuration

In an E3 Series cabinet configuration, the PCB orientation of the DACT-E3 sub-assembly is usually installed above the ILI-MB-E3

or ILI95-MB-E3 sub-assembly as part of a backbox or a mounting plate configuration. To install the DACT-E3, refer to the

following instructions.

1. Insert and secure eight standoffs (3/16” HEX #4-40, x 1.25”) in the ILI-MB-E3/ILI95-MB-E3 as shown in Location 1 of

Figure 2.3.1.1.1.

2. Align and place the DACT-E3 on the left side and above the ILI-MB-E3/ILI95-MB-E3.

3. Insert and secure four screws (#4-40 x 1/4”) into the four standoffs as shown in Location 2 of Figure 2.3.1.1.1.

Figure 2.3.1.1.1 illustrates the DACT-E3 installed to the Cabinet C, E3-INCC-CAB-C plate.

Figure 2.3.1.1.1 DACT-E3 Circuit Board Installed to a Mounting Plate

NOTE: BACKBOX INSTALLATION:

If the DACT-E3 is installed to the backbox, use four screws (#4-40 x 3/8”) and secure the screws into the four studs on the

backbox.

CABINET C,

E3-INCC-C PLATE

SCREW,

#4-40 x ¼”

8 PLACES

ILI-MB-E3/

ILI95-MB-E3

DACT-E3

STANDOFF,

3/16" HEX

#4-40 x 1.25”

8 PLACES

DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019 5

2.3.1.2 DACT-E3 Installation in an S3 Series, Cabinet Configuration

In an S3 Series, SLP-BB cabinet configuration, the PCB orientation of the DACT-E3 sub-assembly is usually installed above the

SLP-E3 sub-assembly as part of a backbox configuration. To install the DACT-E3, refer to the following instructions.

1. Insert and secure four standoffs (3/16” HEX #4-40, x 1 1/) to the SLP-E3 as shown in Location 1 of Figure 2.3.1.2.1.

2. Align and place the DACT-E3 on top of the SLP-E3.

3. To mount the DACT-E3 to the SLP-E3, insert and secure four screws (#4-40 x 1/4”) into the four standoffs as shown in

Location 2 of Figure 2.3.1.2.1.

Figure 2.3.1.2.1 DACT-E3 to S3 Mounting Plate Installation

Figure 2.3.1.2.2 illustrates the DACT-E3 installed in the SLP-BB cabinet.

Figure 2.3.1.2.2 DACT-E3 Installed in the SLP-BB Cabinet

SLC-PM/

SLC95-PM

SLC-PM/

SLC95-PM

DACT-E3

SLP-E3

STANDOFF, M/F,

(#4-40 x 1-½” (38.10 mm))LG

(4 PLACES)

SCREW,

(#4-40 x ¼” (6.35 mm))

LG, PHPD SEMS

(4 PLACES) DACT TO

STANDOFF MOUNTING

S3 MOUNTING PLATE

DACT-E3

SLP-E3

AUXILIARY RS485

FROM DACT-E3 TB2

(CLASS 2

POWER-LIMITED)

TELEPHONE LINES

FROM DACT-E3 TB2

(CLASS 2

NON POWER-LIMITED)

TB1

TB2

TB1

FLPS-7

SLC-PM#2

SLC-PM#1

6DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019

2.4 Specifications

The following list the electrical specifications for the DACT-E3 sub-assembly.

Section 3: Wiring Connections

Table 3.1 lists the field wiring connections for the DACT-E3.

Operating Voltage: 24 VDC non-resettable

Operating Current: 0.018 amp

Alarm Current: 0.018 amp

Operating Temperature: 32° to 120° F (0° to 49° C)

Relative Humidity: 0 to 93%, non-condensing at 90° F (32° C)

Supervised

Class 2 Power-Limited

Designation Description Comments

TB1-1 COM A IN COM A from ILI-MB-E3/ILI95-MB-E3 TB3-1 or SLP-E3 TB3-1

TB1-2 COM B IN COM B from ILI-MB-E3/ILI95-MB-E3 TB3-2 or SLP-E3 TB3-2

TB1-3 COM A OUT COM A OUT to other devices

TB1-4 COM B OUT COM B OUT to other devices

TB1-5 +24 V IN + 24 VDC from PM-9/PM-9G TB4-1, TB4-3, TB4-5 or SLP-E3 TB2-3

TB1-6 GND GND from PM-9/PM-9G TB4-2, TB4-4, TB4-6 or SLP-E3 TB2-4

TB2-1 T1 Tip Line 1 Tip IN from street Non power-limited*

TB2-2 T1 Ring Line 1 Ring IN from street Non power-limited*

TB2-3 P1 Tip Line 1 Tip OUT to phone Non power-limited*

TB2-4 P1 Ring Line 1 Ring OUT to phone Non power-limited*

TB2-5 T2 Tip Line 2 Tip IN from street Non power-limited*

TB2-6 T2 Ring Line 2 Ring IN from street Non power-limited*

TB2-7 P2 Tip Line 2 Tip OUT to phone Non power-limited*

TB2-8 P2 Ring Line 2 Ring OUT to phone Non power-limited*

*Non power-limited

Table 3.1 DACT-E3 Installation Wiring Terminals

NOTE: For additional information on the DACT-E3, refer to the following document:

- E3 Series®(Expandable Emergency Evacuation System) Control Panel UL Listing Document, P/N: LS10080-051GF-E

DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019 7

Section 3: Wiring Connections (Continued)

Figure 3.1 illustrates the wiring connections for the DACT-E3 sub-assembly.

Figure 3.1 DACT-E3 Installation Wiring Diagram

TB2

TB1

LED1 LINE 1 STATUS:

OFF = LINE 1 INACTIVE

ON = LINE 1 TRANSMITTING DATA

FLASHING = LINE 1 FAULT

LED2 LINE 2 STATUS:

OFF = LINE 2 INACTIVE

ON = LINE 2 TRANSMITTING DATA

FLASHING = LINE 2 FAULT

LED3 STANDBY:

OFF = NORMAL STANDBY MODE

ON = TRANSMITTING OR IN TROUBLE

LED1LED2LED3

STANDBY LINE2

STATUS

LINE1

STATUS

DACT-E3 MUST BE THE FIRST

DEVICE TO THE TELCO LINES

IMPORTANT

FROM ILI-MB-E3 OR ILI95-MB-E3 TB3-1 OR FROM SLP-E3 TB3-1

FROM ILI-MB-E3 OR ILI95-MB-E3 TB3-2 OR FROM SLP-E3 TB3-2

RS485 COM A OUT TO NEXT DEVICE

RS485 COM B OUT TO NEXT DEVICE

FROM ILI-MB-E3 OR ILI95-MB-E3 TB3-6 OR FROM SLP-E3 TB2-3

FROM ILI-MB-E3 OR ILI95-MB-E3 TB3-7 OR FROM SLP-E3 TB2-4

TELCO LINE 1 TIP IN FROM STREET

TELCO LINE 1 RING IN FROM STREET

LINE 1 TIP OUT TO PREMISES PHONE(S)

LINE 1 RING OUT TO PREMISES PHONE(S)

TELCO LINE 2 TIP IN FROM STREET

TELCO LINE 2 RING IN FROM STREET

LINE 2 TIP OUT TO PREMISES PHONE(S)

LINE 2 RING OUT TO PREMISES PHONE(S)

RS485 COM A IN

RS485 COM B IN

RS485 COM A OUT

RS485 COM B OUT

24 VDC (+)

SYS NET (-)

8DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019

Section 4: Formats and Codes

4.1 Formats

The DACT-E3 Digital Alarm Communicator Transmitter offers several formats that can be configured in CAMWorks. The DACT-

E3 uses the Ademco Contact ID format to transmit information to a Central Station. Table 4.1.1 lists the following DACT-E3

functions:

4.2 DACT-E3 Contact ID Event Reporting Codes in CAMWorks

In the CAMWorks program, there are two types of formats used to configure the DACT-E3 Contact ID Event Reporting Codes.

4.2.1 Standard Formats

The DACT-E3 can be configured to allow each SLC device to report an event by selecting the DACT Reporting Feature. To

define the Standard format for the ILI-E3/ILI95-E3 Series panel or SLP-E3 panel, enable the Standard Reporting Codes in

the DACT Report Format Section of the DACT Settings screen in CAMWorks. The Custom DACT Reporting Feature is

usually disabled by default. If you disable the Custom DACT Reporting Feature, the system uses the Standard Codes. For

information on the DACT-E3 Contact ID Event Reporting Codes for Standard Formats, refer to Table 4.2.1.1. Figure 4.2.1.1

illustrates an example of the DACT-E3 Contact ID Reporting Codes for Standard formats used to configure the following

types of systems.

Figure 4.2.1.1 Example of the DACT-E3 Contact ID Event Reporting Codes for Standard Formats

Function Description

Line seizure Takes control of the phone lines, disconnecting any premises phones using the same

lines.

Off/On-Hook Performs on and off-hook status to phone lines

Listen for dial tone - 440 Hz tone typical in most networks.

Dialing the Central Station phone number Programmable.

‘ACK’ and “Kiss-off” Tone Discern proper Central Station "ACK" and "Kiss-off" tone

Transmits data Transmit data to the Central Station.

Data verification Verify that data has been accepted by the Central Station

Phone line options Hang-up and release phone lines.

Communication Formats Communicate in a variety of formats

Table 4.1.1 DACT-E3 Functions

• Standard Format • Custom Format

STANDALONE SYSTEMS CONTACT ID FORMAT

EXAMPLE

NOTE: Group Num bers are

truncated to range [00-99].

[1]=New Event

[3]=Restoral Event Type

New Event

[R] [EEE] [00]

Fire Alarm

11 0 00

Not Used

CONTACT ID FORMAT

Group

Number Response

Type

Group 95 Smoke Alarm

SINGLE-RING

NETWORKED SYSTEMS CONTACT ID FORMAT

EXAMPLE 1

Fire Alarm

11 0 00

New Event

CONTACT ID FORMAT

Node 25

MULTI-RING

NETWORKED SYSTEMS CONTACT ID FORMAT

EXAMPLE

[1]=New Event

[3]=Restoral Event Type

New Event

[R] [EEE] [0N]

Fire Alarm

11 0 01

Node

Number 100s

CONTACT ID FORMAT Node

Number

10s & 1s

Response

Type

Node 103

[1]=New Event

[3]=Restoral

[R] [EEE] [00]

Event Type Node

Number Response

Type

Not Used

Smoke Alarm

NOTE: The 100s digit of the node

n u m b e r is re p o rted in the [O N ] field.

Not Used

[N N T]

03 6

[N N T]

[G G T]

95 6

25 6

DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019 9

Table 4.2.1.1 lists the DACT-E3 Contact ID Event Reporting Codes for the Standard Formats.

Event SIA C o n t a ct I D 4/2 3 /1

(Standard DACT Reporting Formats)

Fire Alarm (Smoke or Manual Station) FA [GGT] 1 110 [0G] [GGT] 0 [T] 0

Fire Alarm Restored FH [GGT] 3 110 [0G] [GGT] 2 [T] 2

Waterflow Alarm Silenceable FA [GGT] 1 110 [0G] [GGT] 0 [T] 0

Waterflow Alarm Non-Silenceable SA [GGT] 1 113 [0G] [GGT] 0 [T] 0

Waterflow Alarm Restored Silenceable FH [GGT] 3 110 [0G] [GGT] 2 [T] 2

Waterflow Alarm Restored Non-Silenceable SH [GGT] 3 113 [0G] [GGT] 2 [T] 2

CO/Gas Alarm GA [GGT] 1 151 [0G] [GGT] 2 [T] 0

CO/Gas Alarm GH [GGT] 3 151 [0G] [GGT] 2 [T] 2

Trouble (except Waterflow or Special AMM/PID) FT [GGT] 1 373 [0G] [GG0] 8 [T] 8

Trouble Restored FJ [GGT] 3 373 [0G] [GG0] 7 [T] 7

Trouble (Waterflow AMM/PID) ST [GGT] 1 370 [0G] [GG0] 8 [T] 8

Trouble Restored (Waterflow AMM/PID) SJ [GGT] 3 203 [0G] [GG0] 7 [T] 7

Trouble (Special AMM/PID) UT [GGT] 1 370 [0G] [GG0] 8 [T] 8

Trouble Restored (Special AMM/PID) UJ [GGT] 3 370 [0G] [GG0] 7 [T] 7

Supervisory / Tamper (Module) SS [GGT] 1 203 [0G] [GGT] 6 [T] 6

Supervisory Restored (Module) SR [GGT] 3 203 [0G] [GGT] 7 [T] 7

PAS/Action/Supervisory (Sensor) FS [GGT] 1 200 [0G] [GGT] 6 [T] 6

PAS/Action/Supervisory Restored (Sensor) FR [GGT] 3 110 [0G] [GGT] 7 [T] 7

Disable (except Waterflow or Special AMM/PID) FB [GGT] 1 571 [0G] [GGT] 8 [T] 8

Disable Restored FU [GGT] 3 571 [0G] [GGT] 7 [T] 7

Disable (Waterflow AMM/PID) SB [GGT] 1 570 [0G] [GGT] 8 [T] 8

Disable Restored (Waterflow AMM/PID) SU [GGT] 3 570 [0G] [GGT] 7 [T] 7

Disable (Special AMM/PID) UB [GGT] 1 570 [0G] [GGT] 8 [T] 8

Disable Restored (Special AMM/PID) UU [GGT] 3 570 [0G] [GGT] 7 [T] 7

AC Fail AT 0 1 301 [0G] [000] 80 8

AC Fail Restored AR 0 3 301 [0G] [000] 70 7

Phone Line 1 Fault LT 1 1 351 [0G] [000] 81 8

Phone Line 1 Fault Restored LR 1 3 351 [0G] [000] 71 7

Phone Line 2 Fault LT 2 1 352 [0G] [000] 82 8

Phone Line 2 Fault Restored LR 2 3 352 [0G] [000] 72 7

Automatic Test (NORMAL) RP 0 1 602 [0G] [000] 90 9

Automatic Test (With Exception) RP 991 1 602 [0G] [991] 91 9

Begin Programming LB [GG3] 1 627 [0G] [GG3] 93 9

End Programming LX [GG3] 3 628 [0G] [GG3] 73 7

E3 Series Releasing (Standard DACT Reporting Formats)

Trouble (Releasing Device) (Supervisory) FS [GG3] 1 200 [0G] [GG3] 6 [3] 6

Trouble (Releasing Device) (Supervisory Restoral) FR [GG3] 3 200 [0G] [GG3] 7 [3] 7

Pre-Alarm (Action Supervisory) FS [GG3] 1 200 [0G] [GGZ] 6 [3] 6

Pre-Alarm (Action Restoral) FR [GG3] 3 200 [0G] [GGZ] 7 [3] 7

Pre-Release (Alarm) FA [GG1] 1 110 [0G] [GG1] 0 [1] 0

Pre-Release (Alarm Restoral) FR [GG1] 3 110 [0G] [GG1] 2 [1] 2

Release (Alarm) FA [GG1] 1 110 [0G] [GG1] 0 [1] 0

Release (Alarm Restoral) FR [GG1] 3 110 [0G] [GG1] 2 [1] 2

Abort (Supervisory) FS [GG3] 1 200 [0G] [GG3] 6 [3] 6

Abort (Supervisory Restoral) FR [GG3] 3 200 [0G] [GG3] 7 [3] 7

Manual Dump (Alarm) FA [GG1] 1 110 [0G] [GG1] 0 [1] 0

Manual Dump (Alarm Restoral) FR [GG1] 3 110 [0G] [GG1] 2 [1] 2

Table 4.2.1.1 DACT-E3 Contact ID Event Reporting Codes for Standard Formats

10 DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019

4.2.2 Custom Formats

The DACT-E3 can be configured to allow each SLC device to report a unique 3-digit code by selecting the Custom DACT

Reporting Feature. The user must specifically enable this feature through configuration programming by using

CAMWorks™. If you enable the Custom DACT Reporting feature, the system uses the Custom codes or optional fields. The

system substitutes the custom formats or optional fields in place of the standard codes. To enable this feature, each ILI-MB-

E3, ILI-S-E3 or SLP-E3 must have V1.3-806 or higher ILI Firmware installed. This feature is also available for the ILI95-

MB-E3, ILI95-S-E3 or SLP-E3. For information on the DACT-E3 Contact ID Event Reporting Codes for Custom Formats,

refer to Table 4.2.2.1. Figure 4.2.2.1 illustrates an example of the DACT Contact ID Reporting Codes for Custom formats

used to configure the following types of systems.

Figure 4.2.2.1 Example of the DACT-E3 Contact ID Event Reporting Codes for Custom Formats

For Contact ID and SIA Formats:

GG = In standalone systems, the group number assigned to the device, 00-99.

= In networked systems, the node number where the device is located, 00-64 (000-122 in multi-ring networks).

0G = In only multi-ring systems, represents the 100s digit of the node address.

For Contact ID and SIA Formats: (Continued)

T = Type of device or event causing the event to be reported.

0 = Any Device not listed below

1 = General Alarm Device

2 = Manual Station Alarm

3 = Supervisory Device (Non-latching)

4 = Supervisory Device (Latching)

5 = Waterflow (Non-silenceable)

6 = Smoke Alarm

7 = Non-reporting Device

8 = Multi-level Device

9 = CO/Gas Alarm Device

Note: Special AMM/PIDs include the following functions: Reset Switch, Silence Switch, Drill Switch, Alarm Acknowledge Switch,

Trouble Acknowledge Switch.

NOTE: To use the Custom DACT Reporting Feature, all ILI-MB-E3, ILI-S-E3 and SLP-E3 nodes on the network

must have V1.3-806 ILI Firmware installed as the minimum requirement. For additional information, refer to the

CAMWorks Online Help.

Table 4.2.1.1 DACT-E3 Contact ID Event Reporting Codes for Standard Formats

STANDALONE SYSTEMS CONTACT ID FORMAT

EXAMPLE

NOTE: Group Numbers are

truncated to range [00-99].

[1]=New Event

[3]=Restoral Event Type

New Event

[R] [EEE] [GG] [UUU]

Fire Alarm

110 00

095

Group 00

Group

Number

C O N TA C T ID FO R M A T

Custom Device ID

SINGLE-RING

NETWORKED SYSTEMS CONTACT ID FORMAT

EXAMPLE 1

Fire Alarm

110 09

New Event

C O N TA C T ID FO R M A T

MULTI-RING

NETWORK SYSTEMS CONTACT ID FORMAT

EXAMPLE

[1]=New Event

[3]=Restoral Event Type

New Event

[R] [EEE] [NN]

Fire Alarm

110 09

Node

Number

C O N TA C T ID FO R M A T

Node 09

or 109

Node 09

[1]=New Event

[3]=Restoral

[R] [EEE] [NN]

Event Type Node

Number

Custom ID 095

500

Custom ID 500

[UUU]

Custom Device ID

[UUU]

Custom Device ID

880

Custom ID 880

NOTE: Node Num bers above 99

are truncated to range [00-99].

Inhaltsverzeichnis

Andere Honeywell Sender Handbücher

Honeywell

Honeywell XNX Benutzerhandbuch

Honeywell

Honeywell 5822T Bedienungsanleitung

Honeywell

Honeywell oneWireless XYR 6000 Bedienungsanleitung

Honeywell

Honeywell oneWireless XYR 6000 Bedienungsanleitung

Honeywell

Honeywell oneWireless XYR 6000 Bedienungsanleitung

Honeywell

Honeywell STT700 SmartLine Bedienungsanleitung

Honeywell

Honeywell oneWireless XYR 6000 Bedienungsanleitung

Honeywell

Honeywell 5820L - Slim Line Wireless Door/Window... Montageanleitung

Honeywell

Honeywell PEHA FU-BLS Bedienungsanleitung

Honeywell

Honeywell XYR 5000 Series Bedienungsanleitung

Honeywell

Honeywell 5800Micra - Single Door/window Transmitter Bedienungsanleitung

Honeywell

Honeywell 5800MICRA Bedienungsanleitung

Honeywell

Honeywell 5804 - Ademco Wireless Key Bedienungsanleitung

Honeywell

Honeywell Satellite XT 9602-0400 FTT Bedienungsanleitung

Honeywell

Honeywell Ademco 5811 Bedienungsanleitung

Honeywell

Honeywell 5834 Montageanleitung

Honeywell

Honeywell SMV 3000 Bedienungsanleitung

Honeywell

Honeywell XNX Benutzerhandbuch

Honeywell

Honeywell Fema Moduflex F Series Handbuch

Honeywell

Honeywell ADEMCO 5820L Montageanleitung

Honeywell

Honeywell oneWireless XYR 6000 Bedienungsanleitung

Honeywell

Honeywell APT2000 Series Bedienungsanleitung

Honeywell

Honeywell ADEMCO 5801 Montageanleitung

Honeywell

Honeywell SLN 700 Bedienungsanleitung

Beliebte Sender Handbücher anderer Marken

NIVELCO

NIVELCO EasyTREK SCA-300 Series Betriebsanleitung

Kamstrup

Kamstrup READy MTU Betriebsanleitung

Omega

Omega ZW Series Bedienungsanleitung

ABB

ABB Field 264H Leitfaden

Alinco

Alinco DJ-V17T Bedienungsanleitung

Dejero

Dejero EnGo 3x Bedienungsanleitung

Rosemount

Rosemount 4600 Bedienungsanleitung

Speaka Professional

Speaka Professional 2342740 Bedienungsanleitung

trubomat

trubomat GAB 1000 Bedienungsanleitung

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Bedienungsanleitung

Rondish

Rondish UT-11 Bedienungsanleitung

MG 10JRE Bedienungsanleitung

Burkert

Burkert 8177 Bedienungsanleitung

Firetide

Firetide HotPort 3203 Handbuch

Tele Radio

Tele Radio T9-02 Bedienungsanleitung

Rotronic

Rotronic HygroFlex HF3 Series Bedienungsanleitung

Jamara

Jamara FCX6 Pro Tel Bedienungsanleitung

Excalibur

Excalibur SoundMaster FM Transmitter 144 Bedienungsanleitung
