Hoshizaki KM-650MAH-E Bedienungsanleitung

Hoshizaki

“A Superior Degree

of Reliability”

www.hoshizaki.com

Model

KM-650MAH-E

Modular Crescent Cuber

Hoshizaki America, Inc.

PARTS LIST

™

Number: 71286

Issued: 8-22-2008

89/336

73/23



CONTENTS

Auxiliary Codes ...................................................................................................................... 3

Auxiliary Code Breakdown .................................................................................................... 3

Note About Ordering Parts .................................................................................................... 3

Material Abbreviations ........................................................................................................... 4

A. Ice Cuber Assembly .......................................................................................................... 5

B. Refrigeration Circuit .......................................................................................................... 8

C. Water Circuit ................................................................................................................... 1

D. Control Box Assembly ..................................................................................................... 14

E. Label Location ................................................................................................................. 16

F. Top Panel Assembly ....................................................................................................... 18

G. Front Panel Assembly ..................................................................................................... 19

H. Pump Motor Assembly .................................................................................................... 0

J. Accessories & Packaging ................................................................................................ 1

Auxiliary Codes

KM-650MAH-E T-0 April 008

Auxiliary Code Breakdown

K-0

Designates the year. "K" indicates the year 000. Years progress or regress in alphabetical order.

"J" is 1999, "L" is 001, "M" is 00, and so on. The letters "I" and "O" were skipped.

Designates signicant part changes within the same year for this model. Base is 0 and this number

advances for each change.

Example: T-1

"T" indicates 008.

"1" indicates the rst signicant part change for 008.

Note About Ordering Parts

Most assemblies cannot be ordered as complete units; parts in the assemblies generally must be ordered

separately.

IMPORTANT

IEC standards require that the clamping means of earthing terminals be

adequately secured against accidental loosening and that accessible metal

parts of the icemaker which may become live in the event of an insulation

fault be permanently and reliably connected to an earthing terminal within the

icemaker or to the earthing contact of the icemaker inlet. This is accomplished

in this icemaker through the use of stainless steel toothed washers.

Material Abbreviations

ALUMINUM

AL = Aluminum

COPPER

CU = Copper

PLASTIC

ABS = Acrylonitrile -butadiene-styrene

AC = Polyacetal

EVA = Ethylene vinyl acetate

PA = Polyamide = Nylon

PC = Polycarbonate

PE = Polyethylene

PES = Polyester

PETP = Polyethylene terephthalate = Tetlon

PP = Polypropylene

PS = Polystyrene

PTFE = Polytetrauoroethylene = Teon

PUR = Polyurethane

PVC = Polyvinyl chloride

RUBBER

VN = Vinyl Nitrile

EPDM = EP rubber

NBR = Nitrile butadiene rubber

NR = Natural rubber

NP = Neoprene

SI.R = Silicone rubber

SY.R = Synthetic rubber

EPH = Epichlorohydrin

STEEL

GS = Galvanized steel

SS = Stainless steel

PS = Plated steel

PAS = Primed steel

A. Ice Cuber Assembly

KM-650MAH-E

T-0

DD1

3a 3b

0

a

GG1

D

b

456

78 9 10

11 11a

1 1a 1b

16 16a

17 17a

19 19a

1

 a b

3

4 4a 4b

5

7 7a 7b

6 6a 6b 8

Title: A. Ice Cuber Assembly Model: KM-650MAH-E

Index

No. Description

Material or

Model Number Part Number

Required Number

T-0

B Refrigeration Circuit - 1A157A01 1

C Water Circuit - 1A1475A03 1

D Control Box Assembly - A4566A01 1

D1 T Screw 4×8 7P31-0408 3

D Split Lock Washer M4, SS 7L-0400 3

E Label Location - 3A4780A01 1

F Top Panel Assembly SS 3A3878A01 1

G Front Panel (A) Assembly SS A43G01 1

G1 Truss Head Screw 4×8, SS 7C3-0408 1

1 Evaporator Case - 1A0579G04 1

 Base - A146G15 1

a FT Screw 4×8 7F31-0408 7

b Split Lock Washer M4, SS 7L-0400 7

3 Frame - 3A503G01 1

3a Truss Head Screw 4×8, SS 7C3-0408 1

3b Truss Head Screw 4×5, SS 7C3-045 

4 Square Washer Brass 433537-0 1

5 Screw-Grounding Brass 433304-0 1

6 Split Lock Washer M5, SS 7L-0500 1

7 Power Supply Cord - 45359-0 1

8 Bushing - 450414-01 1

9 Cable Tie - 8911-000 1

10 Cable Tie Mount - 437618-01 1

11 Side Panel (R) SS A117G0 1

11a T Screw 4×8, SS 7P3-0408 1

1 Control Box Cover GS 3A371-01 1

1a T Screw 4×8 7P31-0408 3

1b Split Lock Washer M4, SS 7L-0400 3

13 Front Insulation PP, PUR 15731G0 1

14 Top Insulation PP, PUR 15730G01 1

15 Silicone Hose L=390 7730I381 1

16 Strap NBR 435487-01 1

16a Thumbscrew Black 415949G10 1

17 Bulb Holder PE 3A3903-01 1

17a Thumbscrew Black 415949G11 

18 Tape-Foam L=70 808-0005 1

19 Louver A - 1A0547-01 

19a Push Retainer PS15306PG 4A414-01 6

0 Air Filter A - A06G01 

1 Base Cover SS 3155G01 1

 Barrier GS 4A035-01 1

a T Screw 4×8 7P31-0408 

b Split Lock Washer M4, SS 7L-0400 

3 Gasket L=550 4A0808L0 1

4 Barrier-Insulation GS 4A1167-01 1

4a T Screw 4×8 7P31-0408 

4b Split Lock Washer M4, SS 7L-0400 

Title: A. Ice Cuber Assembly Model: KM-650MAH-E

Index

No. Description

Material or

Model Number Part Number

Required Number

T-0

5 Capillary Ring - 45307-01 1

6 Transformer PY1-1904 4460-01 1

6a Pan Head Screw

Assembly

4×8, SS 7C130408 4

6b Split Lock Washer M4, SS 7L-0400 4

7 Transformer Cover GS 446359-01 1

7a T Screw 4×8 7P31-0408 

7b Split Lock Washer M4, SS 7L-0400 

8 Bushing OCB-500 48394-0 1

B. Refrigeration Circuit

1/2

KM-650MAH-E

T-0

10 10a

1 

3 3a

66a

7 8

9a

9

8

36 37

10b

3b

6

9b

30a

30 30b

31a

31 31b

3a

3 3b

33a

33 33b

a



11b 1c

1

0

5

4

18 19 15

788b

B. Refrigeration Circuit

2/2

KM-650MAH-E

T-0

38 41

34 35

Title: B. Refrigeration Circuit Model: KM-650MAH-E

Index

No. Description

Material or

Model Number Part Number

Required Number

T-0

1 Compressor RST64C1E-CAZ-0 4A446-01 1

1a Spacer - 4A595-01 4

1b Grommet - 4A593-01 4

1c Bolt 8×45 437889-01 4

 Fan Motor 50 WATT–

GEHI

4A3158-01 1

a Self-Locking Nut NO. 8-3 7N1I083 4

3 Fan Motor Bracket GS 37180-01 1

3a Hex Bolt w/Washer (LF) 5×1 7B013051 4

4 Fan Blade - 4A3959-01 1

5 Heat Exchanger - A4585G01 1

6 Evaporator - 106396G01 1

6a T Screw 4×16, SS 7P3-0416 4

6b T Screw 4×1, SS 7P3-041 

7 Valve Body-Hot Gas - 4A3978-01 1

8 Coil-Valve - 4A377-01 1

8a Bolt - 4A377F01 1

8b Truss Head Screw 4×8 7C31-0408 

8c Split Lock Washer M4, SS 7L-0400 

9 Pressure Switch - 433441-07 1

10 Pressure Switch Bracket GS 434938-01 1

10a T Screw 4×8 7P31-0408 1

10b Split Lock Washer M4, SS 7L-0400 1

11 Strainer - 441569-0 1

1 Expansion Valve HFE-15 NHD- 4A148-01 1

13 Copper Tube (A)-High

Side

- 3A480G01 1

14 Copper Tube (B)-High

Side

- 3A4803G01 1

15 Copper Tube (C)-High

Side

- 3A4004G01 1

16 Copper Tube (F)-High

Side

- 4A4084-01 1

17 Copper Tube-Hot Gas - A4588G01 1

18 Copper Tube-Access

Valve

- 3A4783G01 1

19 Access Valve - 45779-01 

0 Elbow - 417395-03 1

1 Rubber Insulation (A) - 3A1044-01 1

 Rubber Insulation (B) - 3A1045-01 1

3 Insulation Holder SS 4A1550-01 1

3a T Screw 4×8, SS 7P3-0408 

3b Split Lock Washer M4, SS 7L-0400 

4 Drier - 4A666-01 1

5 Nylon Tie PLWP3H-TL 8911-0301 1

6 Clamp - 4A338-01 1

7 Insulation Tube L=40 776-100 3

8 Cable Tie - 8911-000 1
