Hoshizaki KMD-850MAH Bedienungsanleitung

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com

CUBER DIMENSIONS

WxDxH

KMD-850M_H

7/08

Item # 13230

MODULAR CRESCEN CUBER

Warranty

Valid in United States, Canada, Puerto Rico, & U.S.Territories. Contact factory for warranty in

other countries.

hree Year - Parts & Labor on entire machine.

Five Year - Parts & Labor on: Evaporator.

Five Year - Parts on: Compressor, air-cooled condenser coil.

KMD-850M_H

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KMD-850M_H

30 x 245/8 x 28

*AutoCad available on KCL

•Up to 836 lbs. of ice production per 24 hours

•Ice on beverage design

•Durable stainless steel exterior

•Individual crescent cube

•Protected by HoshiGuard Anti icrobial Agent

•CycleSaver®Design

•EverCheck®alert syste

•Stainless steel evaporator

•Re ovable air filters (Air-cooled odel only)

•R-404A Refrigerant

•Complies with California Energy Commission guidelines (CEC)

* The KMD-850MRH is ENERGY STAR certified.

KMD-850MAH

Air-Cooled

Shown on an optional

Lancer 30” Dispenser

KMD-850MWH

Water-Cooled

KMD-850MRH

Remote Air-Cooled

Hoshizaki

DIMENSIONS

WxDxH

©HOSHIZAKI AMERICA, INC.

KMD-850M_H

MODULAR CRESCEN CUBER

U ILI Y CONSUMP ION

AIR-COOLED

Model Number

70˚

50˚ 70˚

786

90˚

80˚

90˚

Ice Production

Per Cycle KWH per

100 LBS.

90/70

Potable

Water Gal.

per 100 lbs.

90/70

Lbs. Cubes

KMD-850MWH

Air Temp˚ F.

Water Temp˚ F.

SPECIFICA IONS

Model Number Condenser Amperage Min. Circuit

Ampacity Shipping

Weight

8.3 20 249 lbs.

Water-Cooled

KMD-850MWH

5.9 19.5

753

743

686

685

629

580

11.8 624

639

Condenser

Water Gal.

per 100 lbs.

90/70

N/A

O P E R A I N G L I M I S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water Pressure 10 - 113psig

• Voltage Range 187 - 253V

C O N D E N S I N G U N I

• Voltage Range 104 - 127V

• Ambient Temp Range -20 - 122˚F

ELEC RICAL&PLUMBING/KMD-850M_H

• 208-230V/60/1 (3 wire with dedicated neutral for 115V)

• 20 amp Max Fuse/HACR Breaker Size

• 3/8” D copper or equivalent independent potable water supply

• 3/4” FPT independent drain connection

SERVICE

• Panels easily removed and all components

accessible for service.

• Removable/cleanable air filters.

(Air-Cooled model only)

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com Printed in .S.A.

KMD-850M_H

30 x 245/8 x 28

WA ER-COOLED

70˚

50˚ 70˚

836

90˚

80˚

90˚

Air Temp˚ F.

Water Temp˚ F.

831

830

822

786

759

815

KMD-850MAH

4.1 20.2

12.1 624 127

9.8 20 249 lbs.

Air-Cooled

KMD-850MAH

• Air-cooled

• Water-cooled

• Remote Air-cooled

REMO E AIR-COOLED

70˚

50˚ 70˚

833

90˚

80˚

90˚

Air Temp˚ F.

Water Temp˚ F.

803

793

741

738

686

641

698

KMD-850MRH 5.4 19.5

11.6 624 N/A

9.8 20 235 lbs.

Remote

Air-Cooled

KMD-850MRH

KMD-850MAH

FRONT IEW

AIR-COOLED UNIT

WATER-COOLED UNIT

REMOTE AIR-COOLED UNIT

SIDE IEW

ICE DROP ZONE

KMD-850MRH & MWH

FRONT IEW

32 3/16

15 11/16

36 15/16

URC-9F

Air Flow

211/16

21/2

18 1/8

2115/16

34 5/16

Liquid Refrigerant

Line

Discharge Line

Electrical

Conduit

Access

Pre-Charged ubing Kits

(Sold Separately)

20’ R404-2068-2

35’ R404-3568-2

Voltage supply for the URC Remote

Condenser is supplied from the Ice Maker.

No additional circuit is required.

URC-9F Remote Condenser (Sold Separately)

For Use with KMD-850MRH
