Hoshizaki PTR1SSB-FSFS Bedienungsanleitung

Cabinet Const uction

•Stainless steel interior and exterior for long life, durability

and easy maintenance

•Ducted air distribution system achieves a uniform box

temperature elimnating “hot spots” even when full

•(3) heavy duty epoxy shelves per section are standard;

adjustable in 1" increments

•Cabinet door perimeter heater provides condensation

control and is equipped with a back-up heater. Manual

on/off switch allows for energy savings

•Cabinet walls are insulated with 2 3/8” of R-134A,

CFC free foamed in place polyurethane

•Interior incandescent light automatically activated

•Die cast legs and stainless steel feet offer increased durability

Doo Const uction

•Full height or half height doors are constructed of

high grade 300 Series stainless steel inside and out

•Flush mount door handles maximize aisle space by

eliminating protruding parts

•Door hinges are all metal with tension spring closure and

will not wear out like traditional cam-lift hinges; Doors stay

open at 90˚ and are self-closing at 85˚

•Step door design protects door gasket when product is

removed from the box; Snap in magnetic door gaskets are durable and easily removed

•Door hinging is field reversible

•Cylinder door locks are standard

Ref ige ation System

•High efficiency refrigeration system is designed with a large capacity condenser and evaporator

resulting in lower overall power consumption

•TempGuard’s®EverCheck®controls monitor high and low temperatures, high pressure, high and low

voltage, clean filter and cabinet temperature functions.The controls are located on operators side of

the unit

•Refrigeration system is mounted on a fully insulated rotocast platform and is easily removable from

the main unit

•Evaporator coil is coated for extended life

•Refrigeration system is equipped with solid state digital controls

•Removable, cleanable air filter protects condenser and reduces cleaning requirements

•Hot gas condensate evaporator is standard

•115 volt units equipped with cord and plug

•Refrigerant: R-404A with expansion valve control

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com

PPTTRR11SSSSBB--__SS__SS DDIIMMEENNSSIIOONNSS

W x D x H

PTR1SSB-_S_S

5/08

Item # 13202

TEMPG ARD®STAINLESS STEEL DOOR PASS THR REFRIGERATORS

Warranty

Valid in United States, Canada, Puerto Rico, & U.S. Territories. Contact factory for warranty in

other countries.

Two Yea - Parts & Labor on entire machine.

Five Yea - Parts on: Compressor.

PTR1SSB-_S_S

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

27.5 x 35.9 x 84.5*

*with 6" adj. legs

TEMPG ARD®Self-Contained, Stainless Steel Door Pass Thru Refrigerators

with EverCheck®Audio Alert

PTR1SSB-FSFS

Shown

*AutoCad available on CL

PTR1SSB-HSHS

115/60/1

12.0

15.0

5 - 15P

12.0

1700

3610 (1/2HP)

104 - 126

45° - 100°F

36° to 50°F

R-404A

Hoshizaki

DDIIMMEENNSSIIOONNSS

W x D x H

PTR1SSB-_S_S

27.5 x 35.9 x 84.5*

* with 6" adj. legs

PASS THRU RE FRI G ERATO R

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com Printed in U.S.A.

PTR1SSB-_S_S

STAINLESS STEEL DOOR PASS THR REFRIGERATOR

• 1 section pass thru refrigerator with half stainless steel doors

• 1 section pass thru refrigerator with full stainless steel doors

OPTIONS

• 4” Heavy duty casters • Universal tray/pan slides

• Additional epo y shelves • Stainless steel shelves

• Foot pedall • Reverse door hinging

• Padlock hasp

DIMENSIONS/CAPACITY

Mo el #

Interior Storage Capacity (CF)

Overall Wi th

Overall Depth

Height (including 6" dj. legs)

Depth with Door open at 90°

Door Opening Wi th

Door Opening Height

A justable Shelves

Shelf Dimensions (W x D)

Crate Shipping Weight

Crate Height

Crate Wi th

Crate Depth

One Section

PTR1SSB-HSHS

ELECTRICAL & REFRIGERATION DATA

Mo el #

Voltage

Amperage

HACR Breaker

Electrical Connection(NEMA)

*Energy Consumption(kwh/d y)

* Heat Rejection(BTU/Hr.)

Approximate Nominal

Compressor BTU/Hr.(HP)

Voltage Range

Ambient Temp. Range

Control Setpoint Range

*Refrigerant

23.8 ft3

27.5"

35.9"

84.5"

85.7"

21.75"

26.75"

21.2" x 30.75"

475 lb

85"

32"

38"

* B sed on 100°F mbient cycling t setpoint (NSF)

One Section

PTR1SSB-HSHS

DOOR SWING

SIDE VIEW

PLAN VIEW

PTR1SSB-HSHS

(Operators Si e)

85.7"

24.9"

6.7"

35.9"

24.9"

St ys open t 105°

St ys open t 90°

35.9"

84.5"

78.5"

26.75"

65.0"

27.5"

35.9"

84.5"

One Section

PTR1SSB-FSFS

23.8 ft3

27.5"

35.9"

84.5"

85.7"

21.75"

59.25"

21.2" x 30.75"

475 lb

85"

32"

38"

115/60/1

12.0

15.0

5 - 15P

12.0

1700

3610 (1/2HP)

104 - 126

45° - 100°F

36° to 50°F

R-404A

One Section

PTR1SSB-FSFS

84.5”

PTR1SSB-FSFS

(Operators Si e)
