Hoshizaki RTC-A series Bedienungsanleitung

RTC-A series

RTC-A 系列

FTC-A series

FTC-A 系列

INSTRUCTION MANUAL

使用手册

UNDERCOUNTER REFRIGERATOR/FREEZER

平台式冷藏柜 / 冷冻柜

L1T012302 (111512)

ENGLISH

WARNING

Do not wet this product or use it in

potentially wet conditions. This may

cause electric leakage, resulting in

electric shock or ﬁre.

IMPORTANT

1. This booklet is an integral and essential

part of the product and should be kept and

preserved by the user. Please read carefully

the guidelines and warnings contained

herein as they are intended to provide the

installer/user with essential information for

the proper installation and the continued

safe use and maintenance of the product.

Please preserve this booklet for any further

consultation that may be necessary.

2. This is a commercial refrigerator/freezer,

and should be destined only to be used

for the purpose for which it has been

expressly designed. Any other use should

be considered improper and therefore

dangerous. The manufacturer will not

be held liable or responsible for any

damage caused by improper, incorrect and

unreasonable use.

I. GENERAL INFORMATION

1. CONSTRUCTION

II. INSTALLATION AND OPERATING

INSTRUCTIONS

1. LOCATION

IMPORTANT

This refrigerator/freezer is not intended for

outdoor use. Normal operating ambient

temperature should be within 5°C to 43°C.

For best operating results:

* The refrigerator/freezer should not be located

next to ovens, grills or other high heat producing

equipment.

* The location should provide a firm foundation for

the equipment.

* To adjust the height of the unit, turn the Adjusters

of the Adjustable Legs. The unit should always be

level from side to side and back to front.

Keep Dry

CAUTION

The height of the Adjustable Legs must be

within 9 - 12 cm. If extended too much, the

Legs may become weak or the Adjusters can

come off, causing unexpected injuries.

*.dewollatonsignippirderehwetisadiovA

Especially, a side-by-side or back-to-back

installation (possibly with other manufacturer’s unit)

may cause condensation between the two units,

resulting in dripping onto the ﬂoor.

* Do not expose the unit to direct sunlight or higher

temperatures.

Note: Attach the four Legs (or Casters) provided to

the mounting holes located at the bottom of

the unit.

Fig. 1

Front Panel

Air Outlet

Door (L)

Door (R)

Top Panel

Front Panel

Air Inlet

Power Cord

Nameplate

Leg

(or Caster)

Shelf

Fig. 2

Adjustable Leg

Adjuster

Leg Height Longer Shorter

Window Panel

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been given supervision

or instruction concerning use of the appli-

ance by a person responsible for their

safety. Children should be supervised to

ensure that they do not play with the

appliance.

ENGLISH

4) .yawemasehtnisretsaCrosgeLraerehttnuoM

When mounting the Casters, lock the two front

Casters before mouting the rear ones, or the unit

will slide when tilted.

5) Before operating the unit, remove all shipping

carton, packing, tape(s) and protective plastic ﬁlm

on the exterior and Top Panel. Be careful not to

damage the exterior panels.

6) Position the unit in a selected site.

7) Clean the interior with a soft cloth soaked in cold

or warm water containing the proper amount of

neutral cleaner and wrung dry.

8) Level the refrigerator/freezer in both the left-to-

right and the front-to-rear directions.

3. SHELF AND SHELF CLIP

* The Shelf is adjustable in 1” increments. Adjust the

Shelf Clips according to the height of stored items.

* To attach the Shelf Clip, insert the upper tab into

an adjust hole in the Shelf Post to hook the Shelf

Clip, and push the lower tab into another adjust

hole until it locks in place. To detach the Shelf Clip,

reverse the above procedure.

Fig. 6

Shelf Clip

Shelf Post

Push

Hook

CAUTION

Attach the Shelf Clips properly to make the

Shelf level.

* Allow at least 50 cm clearance between the

Front Panel air inlet/outlet and the wall or other

equipment for proper air circulation. The front of

the unit should have enough space for smooth

adjustment of the cabinet temperature. If the

ambient temperature can exceed 38°C, allow at

least 10 cm clearance from the wall at the side of

the machine compartment to prevent overloading

and damaging the refrigeration circuit.

Fig. 3

Air Outlet

Air Inlet

Min. 50cm

2. SET UP

IMPORTANT

1. Do not tilt the unit more than 45° when

mounting the Legs or Casters.

2. Carry the unit by holding its bottom.

1) Cut the shipping band and remove the carton.

Fig. 4

Carton (Base)

2) Take out the accessory Legs or Casters.

3) Tilt the unit backward to mount the front Legs or

Casters (work in pair).

Fig. 5

Carton

Shipping Band

* To lay the Shelf at the bottom of the cabinet, attach

two Shelf Holders each to the left and right frames

and one to the center frame as shown below.

Fig. 7

ENGLISH

* This refrigerator/freezer must be plugged into

the separated power receptacle which is readily

accessible and has enough capacity. The

maximum allowable voltage variation should not

exceed ± 10 percent of the nameplate rating. See

the Nameplate.

* If the supply cord and the plug should need to be

replaced, it should only be done by a qualified

service engineer to avoid any danger.

5. DRAIN CONNECTIONS

1) Connect the accessory Flexible Hose to the drain

outlet located at the bottom of the unit.

2) Bend the Flexible Hose into a trap as shown. Use

the accessory Cable Straps to fix the Flexible

Hose tightly on the bottom of the unit (mounting

holes provided).

IMPORTANT

1. To prevent disconnection, be sure to use the

Cable Straps to secure the Flexible Hose in

place.

2. The drain line should be as short and straight

as possible, sloped downward, and located

below the drain outlet.

Cable Strap

Flexible Hose

Drain Outlet

(defrost water)

Cable Strap

Detail A (front view)

An air gap of at least 5 cm should be

between the end of the Flexible Hose and

the ﬂoor drain.

5. The drain connections are required to

prevent ambient air from causing excessive

frost build up on the Evaporator, resulting in

reduction of the refrigeration capacity.

6. Do not let water drain directly onto the ﬂoor

before running into the drain. Foreign matter

on the ﬂoor may mix into the water and clog

the drain, or the water could run in a wrong

direction.

6. OPERATION

IMPORTANT

1. Be careful not to wet the machine

compartment. This might cause failure or

electric shock hazard.

2. To prevent electric shock, do not touch the

Attachment Plug with wet hands.

3. Do not store any volatile or flammable

substances, such as benzine, ether,

adhesives and LPG, in the unit.

4. This refrigerator/freezer is designed only for

temporary storage of foods. Use for any

other purposes (ex. storage of chemicals

or medical supplies such as vaccine and

serum) could cause deterioration of stored

items.

Flexible Hose

Water Surface

Min. 5cm

Commercial Elbow

(not provided)

Water Surface

Min. 5cm

Commercial Pipe

20mm DIA

(not provided)

3. To prevent backflow, do not connect the

Flexible Hose directly to the sewer system.

Fig. 8

4. If the Flexible Hose is too short to reach the

ﬂoor drain, connect a commercial pipe to the

Flexible Hose. Be sure to allow an air gap

of at least 5 cm between the end of the drain

pipe and the ﬂoor drain.

4. ELECTRICAL CONNECTIONS

IMPORTANT

This refrigerator/freezer is provided with no

power switch or earth leakage circuit breaker,

but with overcurrent protection (fuse) only.

Install a switch rated at least 10A on the main

power supply.

ENGLISH

5. Do not throw anything onto the Shelves or

load more than 30 kg on each of them. They

may fall off and cause injury.

6. Do not store bottles or cans near the air

outlet. They may freeze up and break,

causing a risk of injury.

7. Do not use combustible spray or place

volatile and ﬂammable substances near the

unit. They could catch ﬁre from a spark of a

switch or the like.

8. Do not put anything into the machine

compartment or the air inlet/outlet. The Fan

rotating rapidly inside may cause injury or

heat.

9. Energise the refrigerator/freezer for 1 hour

and check for proper temperature before

putting foods in the cabinet.

10. Do not block the air inlet/outlet with foods.

11. Do not pack the cabinet with foods. Allow

some space between them to ensure a good

air ﬂow.

12. Do not put in warm or hot foods. Let them

cool first, or they will raise the cabinet

temperature and could deteriorate other

foods in the cabinet or overload the

refrigerator/freezer.

13. Make sure all items are snug on each Shelf.

14. Moist or fresh foods and those with a strong

smell like seafood should be wrapped up

in a plastic film or packed in a container.

Otherwise the foods may dry up or give their

smells to other foods.

15. Foods containing acetic acid or yeast should

be wrapped up in a plastic ﬁlm. Otherwise

they may accelerate corrosion of the

Evaporator and Copper Tubes, resulting in

failure.

16.Foods intended for direct human

consumption should be stored on the Shelf in

a proper container and protected from direct

contact with the cabinet walls.

17. Do not use the freezer to freeze foods. It is

designed only to store frozen foods. High

quality ice cream may melt during defrost

cycle and should not be stored in the freezer.

[a] START UP

1) Plug in the unit.

2) The Compressor and Condenser Fan Motor will

start in 3.5 minutes.

[b] CABINET TEMPERATURE SETTING

The cabinet temperature is factory-adjusted to

3°C for the refrigerator and -18°C for the freezer. If

necessary, readjust the temperature as follows:

1) Open the Front Panel.

2) Press the Set Point Button to display the current

set point temperature.

3) Keep pressing the Set Point Button, and push the

Temperature Control Button until the Temperature

.erutarepmetderisedehtswohswodniWyalpsiD

The cabinet temperature is adjustable between

-6°C and 12°C for the refrigerator and between -7°C

and -25°C for the freezer.

Note: The above temperature range may not be

available when the ambient temperature

exceeds 30°C.

Set Point Button

Temperature

Display Window

Temperature

Control Button

Fig. 9

18. The Doors may become difficult to open

just after closed because of the negative

pressure created inside the cabinet. Wait for

about 30 seconds.

19. This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

Young children should be supervised

to ensure that they do not play with the

appliance.

ENGLISH

[d] DEFROST

The refrigerator/freezer automatically defrosts the

Evaporator every 6 hours. The Temperature Display

Window shows “dF” during defrost cycle.

To start a manual defrost cycle, hold down the two

Temperature Control Buttons at the same time for a

while. The next defrost cycle will begin in 6 hours.

[e] SHUT DOWN

1) Before shutting down the unit, move the stored

foods into another refrigerator/freezer.

2) Unplug the unit or disconnect the main power

supply.

3) When preparing the unit for long storage, clean

the cabinet interior and Door Gaskets, dry them

thoroughly and store the unit in a dry place.

III. MAINTENANCE AND CLEANING

INSTRUCTIONS

IMPORTANT

1. Before carrying out any cleaning or

maintenance operations, unplug the unit.

2. Do not touch or wet the machine

compartment parts. This could result in

failure or breakdown.

1. INTERIOR, EXTERIOR, SHELF

* Clean the interior and exterior at least once a

week for sanitary use. The unit can be moved by

unlocking the Casters [caster models].

* Clean off the interior and exterior with a soft cloth

soaked in cold or warm water containing the proper

amount of neutral cleaner and wrung dry. Do not

use a water jet to clean the machine compartment.

* Chemical agents other than neutral cleaner might

cause damage to the interior and exterior surfaces.

* The Door Gasket and its contact surface get

soiled easily. Clean every surface of these parts

thoroughly. Remnants of food will accelerate

aging.

* Use a cloth to wipe off any water staying inside the

cabinet.

2. AIR FILTER

A plastic mesh air ﬁlter removes dirt or dust from the

air, and keeps the Condenser from getting clogged.

As the filter gets clogged, the refrigerator/freezer’s

performance will be reduced. Check the filter at

least twice a month. When clogged, use warm

water and a neutral cleaner to wash the ﬁlter. Do not

operate the unit with the Air Filter removed, or the

Condenser will get clogged, resulting in failure.

1) Open the Front Panel, and remove the Air Filter.

To prevent injury, do not touch the Condenser

Fins directly.

2) Wash the Air Filter carefully with cold or warm

water containing the proper amount of neutral

Fig. 10

Decimal Point

4) The displayed cabinet temperature is adjusted

to be almost equal to the temperature at the

center of the cabinet without foods. But it can be

different from the actual temperature depending

on arrangement of stored foods, frequency of door

opening or measuring points.

[c] RAPID REFRIGERATION

To refrigerate stored foods rapidly, choose the rapid

refrigeration mode. The Interior Fan Motor will

operate continuously to accelerate refrigeration.

1) Keep pressing the Rapid Button for 5 seconds to

operate the Interior Fan Motor continuously. The

decimal point on the Temperature Display Window

will disappear during the rapid refrigeration.

2) To resume normal operation, keep pressing the

Rapid Button for 5 seconds. The decimal point

will reappear on the Temperature Display Window.

3. To prevent possible damage, do not clean

the plastic parts with water above 40°C or in

a dishwasher.

ENGLISH

IV. BEFORE CALLING A SERVICE AGENT

IMPORTANT

1. If the Temperature Display Window on the

Operation Panel indicates an error code

or something seems wrong with the unit,

check for possible causes according to the

following instructions. If the problem still

exists, immediately contact an authorized

Hoshizaki service company.

2. When contacting a service company, let them

know the model name, serial number, date of

installation (see Warranty Card) and state of

the trouble.

3. Do not attempt to repair the unit yourself.

1. TROUBLES WITH ERROR CODE

INDICATION

When the Temperature Display Window on the

Operation Panel ﬂashes alternately between an error

code and the cabinet temperature, check the error

code and follow the instructions below.

1) If one of the following error codes is displayed,

immediately contact an authorized Hoshizaki

service company.

Code Problem

E3 Defrost time too long.

E8, E9 Thermistor defective.

EA, ED Controller Board defective.

2) If one of the following error codes is displayed,

check and correct the condition of the unit

according to the following instructions:

Code Problem and Remedy

E1 Cabinet temperature too high.

(1) Door(s) left open. Close.

(2) Warm or hot foods inside. Take them

out.

(3) Ambient temperature too high. Avoid

installation near high heat producing

equipments or exposure to direct

sunlight.

E2 Cabinet temperature too low.

(1) Ambient temperature too low. Use in

the range from 5°C to 43°C.

(2) Frozen foods being defrosted. Error

code will disappear when defrosting is

completed.

E4, E7 Condenser clogged or ambient temperature

too high.

(1) Air Filter clogged. Clean.

(2) Ambient temperature too high. Avoid

installation near high heat producing

equipments or exposure to direct

sunlight.

E1, E2: Automatically resets when a proper cabinet

temperature is resumed.

E4, E7: After the above checks and corrections,

turn the power supply off and back on

again.

If the error code still appears in the Temperature

Display Window even after the above checks and

corrections, immediately contact an authorized

Hoshizaki service company.

2. TROUBLES WITHOUT ERROR CODE

INDICATION

1) Unit fails to operate:

(1) Unplugged.

(2) Power failure.

(3) Main power supply disconnected.

2) Poor cooling performance:

(1) Ambient temperature too high (above 43°C).

(2) Door(s) opened too often.

(3) Cabinet temperature setting too high.

(4) Too packed with foods or air inlet/outlet

blocked.

(5) Air Filter not clean.

(6) Door(s) left open.

(7) Warm or hot foods inside.

Fig. 11

Air Filter

(2) Attach to Condenser

Magnet

Front Panel

Condenser

(1) Hook on Condenser bottom

cleaner. Rinse and dry the Air Filter thoroughly.

3) To reﬁt the Air Filter, ﬁrst hook it on the bottom of

the Condenser, then attach the Air Filter to the

Condenser.

4) Close the Front Panel.

ENGLISH

(8) Unit in defrost process. The cabinet

temperature may rise temporarily during

defrost cycle but will not affect the foods inside.

3) Condensation around Door(s):

(1) Ambient humidity too high.

(2) Door(s) not closed tightly.

4) Noise:

(1) Normal operating sounds from Compressor,

Condenser Fan Motor or Interior Fan Motor.

(2) Installed on an unsteady floor. Contact an

authorized Hoshizaki service company.

(3) Not leveled in the left-to-right or front-to-rear

directions. Contact an authorized Hoshizaki

service company.

5) Frosting inside compartment:

(1) Ambient humidity too high.

(2) Door(s) opened too often.

V. DISPOSAL

When disposing of the refrigerator/freezer, contact

an authorized Hoshizaki service company or a

specialized waste disposal company.

IMPORTANT

The insulation foaming agent

used for the unit body contains

flammable gas cyclopentane.

With this in mind, dispose of the

refrigerator/freezer properly.

VI. WARRANTY

Hoshizaki warrants to the original owner/user that all

Hoshizaki branded products shall be free of defects

in material and/or workmanship for the duration

of the “warranty period”. The warranty shall be

effective for one year from the date of installation.

Hoshizaki’s liability under the terms of the warranty

are limited and shall exclude routine servicing,

cleaning, essential maintenance and/or repairs

occasioned by misuse and installations not in

accordance with Hoshizaki guidelines.

Warranty repairs should be completed by an

approved Hoshizaki dealer or service agency using

genuine Hoshizaki components.

To obtain full details of your warranty and approved

service agency, please contact your dealer/supplier,

or the nearest Hoshizaki Service ofﬁce:

Hoshizaki Singapore

TEL: +65 6225 2612

FAX: +65 6225 3219

Hoshizaki Lancer Paciﬁc

TEL: +61 8 8268 1388

FAX: +61 8 8268 1978

Hoshizaki Suzhou

TEL: +86 512 62807850

FAX: +86 512 62807860

Hoshizaki Shanghai

TEL: +86 21 51801998

FAX: +86 21 51801947

˖஠



᝜ն

ឯӇາఴֵڙ໷ڙᄉ໼າဖܑ

ʽ΍ၸఴֵǌՠѶԺᑞ࠭ᒰ໣ႂὋ

ᤈᏪᤴᝎႂ༡༪ǌ

᧗᜵

ఴб௦ఴֵʿԺѫҞᄉʶᦉѫὋၸݯ

ؒҪγክǌឯᝢᄽ󰩾ឳб˖դᄉૈӮ֖

᝜նᮉὋځ˝߱˝߶ᜈᏧ  ၸଡΘ˿ൣ

ᆷ߶ᜈԢ૆፝߶Кڠ΍ၸ֖γШఴֵ

ᭉᄉ۲ఴζোǌឯݯؒγክఴбὋܫ௅Ր

ᭉ᜵ௐಉ󰩾ǌ



ఴֵ˝׷ၸчᘨ಄  чш಄ὋԵᑞၸ᝹᝟

ၸ᤬ǌఴֵʿ᤟ՋၸʹФၸ᤬ὋՠѶ

Ժᑞᤴӿᬖǌࠪ΍ၸʿǋᩱឧ΍ၸ֖

ʿՋူ΍ၸᤴᄉʹ૮ڭὋ҃ᤴ׷ഏʿ᠆᠉ǌ

 ఴֵʿ᤟Ջ൴ᬩǋఄᬩԢᎤ˫ᄰፂᰍ֖ᅻ

ខᄉܢ὇ӉહЇቧὈӬ࿗΍ၸὋᬓ᭣థ˃

᠆᠉Ф߶КὋࣲࠪФ΍ၸఴֵҪᄢᅕ֖ૈ

࠭ǌԲܰᤆࠪЇቧҪᄹክὋᆷγФʿဓ

Ꮻఴֵǌ

* ഏᤗ

 ፆౝ

**߶ᜈ֖΍ၸឬ௙

 ߶ᜈᎵ

᧗᜵

ఴчᘨ಄  чш಄ΘࠈЮ΍ၸǌൣ࣡ᄉࢹͺ

ဖܑຝڙ ąᒯ ąᄉᔴډЮǌ

˝˿ᖌణ·বᑞὙ

 ឯӇ࠱чᘨ಄  чш಄߶ᜈڙ༮ߔǋཏ౵Ф߱

ၶᰳຝᄉ᝹ܫᬃᤂǌ

߶ᜈᎵڱࠃὋᡛԩ᝹ܫ᧗᧙ǌ

ᔩ᜵ុᓫఴ఺ᰳὋឯᣀҮԺុᓫஂᒑᄉុᓫ٧ǌ

ఴ఺ݼጻڙࢺԾ֖ґՐழՓγ૆පࣰǌ

γ૆࣯ྋ

ซ

Ժុᓫஂᒑᄉᰳᮋ˝  ᾝ DNǌݟ౦᣾

󰩢ὋԺᑞђஂᒑὋᏧ࠭ᒰុᓫ٧ᑱ

ᖿὋᤴܰᄉᢵࠎǌ

ᥗБ࠱Ф߶ᜈڙʿЉ᝴Ѣဗໞᖿᄉڣǌ࠾Ф᧓

ၸࣲଅᐿ᭤ᐿ߶ᜈழ  ԺˀФ҃ᤴ׷ᄉ

ֵʶᡐ߶ᜈௐὋၿˏԻ఺٧˧󰩮ԺᑞѢဗчѕὋ

Ꮺ࠭ᒰчѕපໞᖿҁڠ౛ʼǌ

ឯӇ࠱ఴ఺఑᭚ڙᄯ࠰󰪚Џᰳຝʽǌ

ซὙ ࠱ଡΘᄉٽ్ஂᒑ  ᑭᣂ  ߶ᜈҁ఺٧

ᦉᄉ߶ᜈߗ˖ǌ

ڎ

ґ౛

ґ౛Ѣ᮲ԯ

ࢺ఺󰩣

Ծ఺󰩣

ᮆ౛

ґ౛ᤈ᮲ԯ

ႂຸጲ

ᩆྠ

ஂᒑ

 ᑭᣂ 

ࡎ౛

ڎ

Ժុᓫஂᒑ

ុᓫ٧

ஂᒑᰳ 󰩢᎕ᆀ

ቓ౛

中文

先锁定两个前脚轮，再安装后脚轮，否则本机在倾

斜时会滑倒。

5) 使用本机前，请拆下所有的绑带、包装、胶带以及

外壳和顶板上的塑料保护膜。请小心不要损坏外板。

6) 将本机放置在选定的场所。

7) 将软布浸泡在由冷水或温水加适量中性清洁剂混合

而成的溶液中，然后取出软布并拧干，再使用该软

布清洁本机内部。

8) 本冷藏柜 / 冷冻柜应在左右和前后方向上保持水平。

3. 层板和层板托

* 层板高度可以 1" 为增量进行调节。请根据存放物品

的高度调节层板托。

* 若要安装层板托，请将上部凸片插入层板立柱中的

调节孔以钩住层板托，然后将下部凸片推入另一个

调节孔，直至其锁止到位。若要拆下层板托，请按

照相反的步骤进行操作。

图6

层板托

层板立柱

推压

钩住

注意

请正确安装层板托，以保持层板水平。

* 如下图所示，将层板放于柜体的底部，然后在左右

边框和中间边框处分别安装两个和一个层板支架。

图7

* 在本机前板的进风口 / 出风口和墙壁或其它设备之

间至少应留出 50cm 间隙，以确保空气流通顺畅。

本机前方应留出足够空间，以确保顺畅调节柜内温

度。如果环境温度超过 38℃，制冷装置室一侧离墙

壁至少应留出 10cm 的间隙，以防止过载并损坏制

冷回路。

图3

出风口

进风口

最小 50cm

2. 设置

重要

当安装支腿或脚轮时，请勿将本机倾斜超过 45°。

2. 握住本机底部以搬动机器。

1) 剪断绑带，然后拆下纸板箱。

图4

2) 取出附属的支腿或脚轮。

3) 将本机向后倾斜，以安装前支腿或脚轮 ( 两人作业 )。

图5

4) 以相同的方法安装后支腿或脚轮。当安装脚轮时，

纸板箱(底部)

纸板箱

绑带

Andere Handbücher für RTC-A series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hoshizaki Kühlschrank Handbücher

Hoshizaki

Hoshizaki HRFW-77MS4 Bedienungsanleitung

Hoshizaki

Hoshizaki B Series Bedienungsanleitung

Hoshizaki

Hoshizaki Premier BW80 Bedienungsanleitung

Hoshizaki

Hoshizaki SafeTemp RH1-AAC Bedienungsanleitung

Hoshizaki

Hoshizaki PREMIER K 70 Bedienungsanleitung

Hoshizaki

Hoshizaki HR24C Bedienungsanleitung

Hoshizaki

Hoshizaki Pass Thru Series PTR2SSB-HSHS Bedienungsanleitung

Hoshizaki

Hoshizaki AM-50BAE Bedienungsanleitung

Hoshizaki

Hoshizaki PTR1SSB-FSFS Bedienungsanleitung

Hoshizaki

Hoshizaki HRFE-77B-CHD Bedienungsanleitung

Hoshizaki

Hoshizaki Pass Thru Series PTR2SSB-FGFG Bedienungsanleitung

Hoshizaki

Hoshizaki Temp Guard RH1-SSB-GD Bedienungsanleitung

Hoshizaki

Hoshizaki Snowflake GII Series Bedienungsanleitung

Hoshizaki

Hoshizaki Temp Guard RH2-SSB-GD Bedienungsanleitung

Hoshizaki

Hoshizaki TempGuard PTR1SSB Series Bedienungsanleitung

Hoshizaki

Hoshizaki RTC-A series Bedienungsanleitung

Hoshizaki

Hoshizaki PTR1SSB-FGFG Bedienungsanleitung

Hoshizaki

Hoshizaki HR-78MA-A Bedienungsanleitung

Hoshizaki

Hoshizaki HRE-70B(-F) Bedienungsanleitung

Hoshizaki

Hoshizaki HR24A Bedienungsanleitung

Hoshizaki

Hoshizaki PTR1SSB-HGHS Bedienungsanleitung

Hoshizaki

Hoshizaki FH1-SSB(-HD) Bedienungsanleitung

Hoshizaki

Hoshizaki COUNTER SHOWCASE HNC-120BA-L/R-S Bedienungsanleitung

Hoshizaki

Hoshizaki Temp Guard RFH1-SSB-HD Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
