HP Visualize c200 - Workstation Bedienungsanleitung

Installing the C200 to C240 CPU Upgrade

HP Part No. A4200-90035

E0997

Printed in USA

Hewlett-Packard Co. 1997

Printing History

First Printing: September 1997

UNIX is a registered trademark in the United States and other countries,

licensed exclusively through X/Open Company Limited.

NOTICE

The information contained in this document is subject to change without

notice.

HEWLETT-PACKARD MAKES NO WARRANTY OF ANY KIND WITH

REGARD TO THIS MATERIAL INCLUDING BUT NOT LIMITED TO

THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FIT-

NESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be lia-

ble for errors contained herein or for incidental or consequential damages in

connection with the furnishing, performance or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copy-

reproduced or translated to another language without the prior written con-

sent of Hewlett-Packard Company.

RESTRICTED RIGHTS LEGEND. Use, duplication, or disclosure by gov-

ernment is subject to restrictions as set forth in subdivision (c) (1) (ii) of the

Rights in Technical Data and Computer Software Clause at DFARS

252.227.7013. Hewlett-Packard Co., 3000 Hanover St., Palo Alto, CA

94304.

10 9 8 7 6 5 4 3 2 1

Introduction

This section introduces the Model C200 to a Model C240 upgrade.

Upgrading your Model C200 to a Model C240

Your upgrade kit contains a C240 CPU Board, which, when installed,

upgrades your Model C200 to a Model C240.

NOTE: Installing this upgrade in your Model C200 does not affect the regulatory and safety

classifications or approvals. The upgraded system meets all of the regulatory and

safety standards listed in Appendix A of your original owner’s guide.

Installation Prerequisites

Before upgrading your Model C200 to a Model C240, your current system

must be running HP-UX 10.20 or greater with Additional Core Enhance-

ments (ACE) for Workstations.

Upgrade Instructions Overview

The general steps for performing the upgrade are outlined as follows and

should be performed in the sequence listed. Refer to the individual sections

of this guide for the actual step-by-step procedures for upgrading the C200

to a C240.

1Prepare your workstation

• Determine and WRITE DOWN the graphics configuration of your system.

• Determine and WRITE DOWN the LAN ID of your system. You will need

to re-enter it in the new system board.

• Power off the workstation and any peripherals.

• Unplug the power cords and disconnect any peripheral cables.

• Remove the floor stand.

2Remove the main tray assembly.

3Remove the C200 CPU board from the main tray assembly.

4Transfer the memory modules from the C200 CPU board to the C240 CPU board.

5Place the C240 CPU board in the main tray assembly.

6Place the new main tray assembly into the workstation chassis.

7Connect power cords and cables, restart the workstation, and enter the LAN ID if

prompted.

Preparing Your Workstation

Before starting the upgrade, use the following procedure to prepare the

workstation:

1The workstation must be running HP-UX 10.20 or later with Additional Core En-

hancements (ACE) to accommodate the C240 upgrade. If the workstation is run-

ning an older version of HP-UX, update the operating system software before

continuing. Run swlist as super user to view what software products are loaded

in your system. If the product list includes B6193AA, you do not need to update

HP-UX.

2Determine the workstation’s LAN ID by entering the following command:

/usr/sbin/lanscan

The output is similar to the following:

Hardware Station Dev Hardware Net-Interface NM Encapsulation Mjr

Path Address lu State NameUnit State ID Methods Num

2.0.2 0x08000970ECC0 0 UP lan0 UP 4 ETHER 52

Record the LAN ID here. You will need it after installing the new system

board:

Enter LAN ID: ___ ___ ___ ___ ___ ___ -___ ___ ___ ___ ___ ___

You must supply the dash (-) between the ﬁrst six digits and the last six digits.

Using the above output example, the LAN ID is 080009-70ECC0.

After you install the new CPU board or I/O board and power on the system for

the ﬁrst time, you will be prompted for the LAN ID.

3Log out of your system and enter a command line session as follows:

HP VUE: At the login window, select Options, then select No Windows.

HP CDE: At the login window, select Option, then select

Command Line Login.

4Power off your workstation by pressing the power button on the front panel.

When you press the power button, the workstation automatically shuts down the

operating system before it powers off the system.

Preparing Your Workstation

5When the workstation has completed shutting down, power off the monitor, and

any peripheral devices connected to the workstation.

WARNING: To avoid electrical shock, make sure you unplug the power cable from

the wall outlet and the system unit before proceeding any further.

6Unplug the power cord of the system unit, the monitor, and any peripheral devic-

es from AC wall outlets.

7Unplug the power cord from the back of the system unit.

8If your monitor is sitting on top of the system unit, remove the monitor from the

top of the system unit and set it aside.

CAUTION: Remove the monitor from the top of the system unit to prevent possible damage to

the system unit or the monitor while performing this upgrade.

Preparing Your Workstation

9Remove the floor stand from the system unit, as shown in Figure 1.

Figure 1 Removing the Floor Stand

10 Lay the system unit on a flat surface, such as a table top.

11 Attach a static-grounding wrist strap to bare metal on the back of the system unit.

Preparing Your Workstation

CAUTION: The internal components of your workstation are susceptible to mechanical and

electrostatic shock. To prevent such damage from occurring, observe the following

precautions during the installation procedure:

Stand on a static-free mat (if available).

Wear a static-grounding wrist strap to ensure that any accumulated

electrostatic charge discharges from your body to ground. Attach the static-

grounding wrist strap by following the instructions on the package that

contains the strap. Be sure to attach one end of the strap to the system

chassis.

Removing the Main Tray Assembly

Once you have prepared the workstation, you need to remove the main tray

from the system unit, as described in the following procedure:

CAUTION: Do NOT attempt to remove the main tray assembly when the workstation is in a

vertical orientation.

1Completely loosen the five thumb screws on the rear of the system unit, as shown

in Figure 2.

Figure 2 Removing Main Tray Assembly

2Place one hand on the top of the system unit and apply pressure to prevent the

system unit from moving, while pulling the handle on the rear panel with your

other hand. See Figure 2.

3Slide the main tray assembly out of the chassis.

Thumb Screws

Thumb

Screws

Removing the C200 CPU Board

Perform the following steps to remove the C200 CPU board from the system

unit:

1Remove the Main Tray Assembly.

2Remove the two CPU board retaining screws, as shown in Figure 3.

3Pull the two ejector handles at the same time, as shown in Figure 3.

Figure 3 Removing the CPU Board (C200)

4Slide the CPU board out approximately one inch, then lift it straight up to re-

move it. Be sure to support the board under the heat sink or you will damage

the CPU board.
