SL42
-2-
Top Cover External Paper Roll Inlet
Kick-stand Cover Lock
Folding Paper Storage
External Paper Roll Holder
Standard Oponal
Quick Start Guide
Rev.1.0
Xiamen Hanin Electronic Technology Co.,Ltd.
ADD：5F, 8#, Aide Airport Industrial Park, Huli District,Xiamen, China 361009
TEL： 0592-5885991
WEB：www.hprt.com
Packing List
Printer Power Cord
USB Cable Quick Start Guide
！Note: the packing materials are actually based on the order.
Note: the views above are for your reference. Ports vary by your choice.
！
Appearance and Components
Front View Rear View
Inside View
Feed Buon
(Status Indicator)
Cover Open Levers
Power Switch
USB PortPower Receptacle
Moveable Label Guides
Platen
Print Head Module
Movable Paper Sensor
CD
-3- -4-
Power Cord
2
3
1
OFF ON
Folding Paper Loading
External Paper Roll Loading
2. Open the printer cover.
3. Take out the jammed paper, then clean
up the print head and platen.
4. Reload a new paper.
2. The external paper roll holder needs to be aligned with the hooks at the boom of
the printer.
Note:
！
Note: turn off the printer power when taking the above steps.
！
Note: Please refer to the SL42 User Manual for the tool and driver installaon.
！
Rev.1.0
Loading the Roll
1. Turn the power on, adjust the paper
guides to fit the width of paper.
2. Insert the paper into the entry slot.
3. The paper will be inhaled into the path
automacally.
1. When the printer is power on, the paper will be inhaled into the path automacally.
Paper Jam Handling
Paper Jam Handling
1. Press the cover open levers and hold
upwards.
1.Make sure the power switch is in “ off ”.
2.Connect the power cord to power receptacle.
3.Connect the other end of power cord to the outlet.
Power Connecon
