Huawei ANE-LX1 Bedienungsanleitung

Quick Start Guide

ANE-LX2

ANE-LX1

ANE-LX3

ANE-LX2J

Your device at a glance

Before you start, let's take a look at your new device.

lTo power on your device, press and hold the power button

until the screen turns on.

lTo power off your device, press and hold the power button,

and then touch .

NFC

Rear camera Flash

Fingerprint scanner Headset jack

USB-C port Primary microphone

Speaker Power button

Volume button Light sensor

Front camera Status indicator

Secondary microphone Earpiece

lOnly ANE-LX1 supports NFC. Please keep the NFC area

close to other devices or objects while using the NFC

function.

lTo force your device to restart, press and hold the

power button until your device vibrates.

Getting Started

Follow the instructions in the following gures to set up your

device.

Applicable to single card

OBOP4*.

Applicable to dual cards

OBOP4*.

lDo not insert or remove the SIM card when your device

is powered on.

lEnsure that the card is correctly aligned and that the

card tray is level when you insert it into your device.

Be careful not to scratch your device or hurt yourself

when using the eject pin. Store the eject pin out of the

reach of children to prevent accidental swallowing or

injury.

Do not use cut or modied SIM or microSD cards with

your device as these may not be recognized and could

damage the card tray (slot).

Dual card dual standby single

pass (applicable to dual cards)

Your device supports only dual card dual standby single pass,

which means you cannot use both SIM cards for calls or data

services simultaneously.

lWhen you are on a call using SIM card 1, SIM card 2 cannot

be used to make or answer calls. If someone calls SIM card

2, the caller will hear a voice message similar to "The

subscriber you dialed is out of the service area" or "The

subscriber you dialed cannot be connected for the moment,

please try again later." The actual message will vary by

service provider.

lWhen you are using SIM card 1's data service, SIM card 2's

data service will be disabled.

Your device's single pass feature helps reduce power

consumption and increase your device's standby time. It is not

related to your service provider's network conditions.

It may be a good idea to contact your service provider and

subscribe to missed call reminder and related assistance

services to avoid the conicts mentioned above.

For more information

If you encounter any problems while using your device, you

can obtain help from the following resources:

lVisit http://consumer.huawei.com/en to view device

information, frequently asked questions and other

information.

lVisit http://consumer.huawei.com/en/support for the most

up-to-date contact information for your country or region.

Go to Settings and touch System > About phone > Legal to

view legal information for your product.

Go to Settings and touch System > About phone > Legal >

Safety information to view safety information for your

product.

Go to Settings and touch System > About phone >

Authentication info to view regulatory information for your

product.

ANE-LX1 / ANE-LX2J / ANE-LX3: Go to Settings and touch

System > Certication logos to view more information on

certication logos for your product.

All pictures and illustrations in this guide, including but

not limited to the product color, size, and display content,

are for your reference only. The actual product may vary.

Nothing in this guide constitutes a warranty of any kind,

express or implied.

Safety Information

Please read all of the safety information carefully before using

your device to ensure its safe and proper operation and to

learn how to dispose of your device properly.

Operation and safety

l To prevent possible hearing damage, do not

listen at high volume levels for long periods.

lUsing an unapproved or incompatible power adapter,

charger, or battery may damage your device, shorten its

lifespan, or cause a re, explosion, or other hazards.

lIdeal operating temperatures are 0 °C to 35 °C. Ideal

storage temperatures are -20 °C to +45 °C.

lPacemaker manufacturers recommend that a minimum

distance of 15 cm be maintained between a device and a

pacemaker to prevent potential interference with the

pacemaker. If using a pacemaker, hold the device on the

side opposite the pacemaker and do not carry the device in

your front pocket.

lKeep the device and the battery away from excessive heat

and direct sunlight. Do not place them on or in heating

devices, such as microwave ovens, stoves, or radiators.

lObserve local laws and regulations while using the device.

To reduce the risk of accidents, do not use your wireless

device while driving.

lWhile ying in an aircraft or immediately before boarding,

only use your device according to instructions provided. Use

of a wireless device in an aircraft may disrupt wireless

networks, present a hazard to aircraft operation, or be

illegal.

lTo prevent damage to your device's parts or internal

circuits, do not use it in dusty, smoky, damp, or dirty

environments or near magnetic elds.

lWhen charging the device, make sure the power adapter is

plugged into a socket near the devices and is easily

accessible.

lUnplug the charger from electrical outlets and the device

when not in use.

lDo not use, store or transport the device where ammables

or explosives are stored (in a gas station, oil depot, or

chemical plant, for example). Using your device in these

environments increases the risk of explosion or re.

lDispose of this device, the battery, and accessories

according to local regulations. They should not be disposed

of in normal household waste. Improper battery use may

lead to re, explosion, or other hazards.

Disposal and recycling information

The crossed-out wheeled-bin symbol on your product, battery,

literature or packaging reminds you that all electronic products

and batteries must be taken to separate waste collection

points at the end of their working lives; they must not be

disposed of in the normal waste stream with household

garbage. It is the responsibility of the user to dispose of the

equipment using a designated collection point or service for

separate recycling of waste electrical and electronic equipment

(WEEE) and batteries according to local laws.

Proper collection and recycling of your equipment helps ensure

electrical and electronic equipment (EEE) waste is recycled in a

manner that conserves valuable materials and protects human

health and the environment, improper handling, accidental

breakage, damage, and/or improper recycling at the end of its

life may be harmful for health and environment. For more

information about where and how to drop off your EEE waste,

please contact your local authorities, retailer or household

waste disposal service or visit the website http://

consumer.huawei.com/en/.

Reduction of hazardous substances

This device and its electrical accessories are compliant with

local applicable rules on the restriction of the use of certain

hazardous substances in electrical and electronic equipment,

such as EU REACH, RoHS and Batteries (where included)

regulations. For declarations of conformity about REACH and

RoHS, please visit our web site http://consumer.huawei.com/

certication.

EU regulatory conformance (only applies to ANE-

LX1 / ANE-LX2 / ANE-LX2J)

Body worn operation

The device complies with RF specications when used near

your ear or at a distance of 0.50 cm from your body. Ensure

that the device accessories, such as a device case and device

holster, are not composed of metal components. Keep the

device away from your body to meet the distance requirement.

The highest SAR value reported for this device type when

tested at the ear is

ANE-LX1 0.75 W/kg

ANE-LX2 0.73 W/kg

ANE-LX2J 0.81 W/kg

And when properly worn on the body is

ANE-LX1 1.21 W/kg

ANE-LX2 0.88 W/kg

ANE-LX2J 1.12 W/kg

Statement

Hereby, Huawei Technologies Co., Ltd. declares that this device

is in compliance with the essential requirements and other

relevant provisions of Directive 2014/53/EU.

The most recent and valid version of the DoC (Declaration of

Conformity) can be viewed at http://consumer.huawei.com/

certication.

This device may be operated in all member states of the EU.

Observe national and local regulations where the device is

used.

This device may be restricted for use, depending on the local

network.

Restrictions in the 2.4 GHz band:

Norway: This subsection does not apply for the geographical

area within a radius of 20 km from the centre of Ny-Ålesund.

Restrictions in the 5 GHz band (only applies to ANE-

LX1 / ANE-LX2J):

According to Article 10 (10) of Directive 2014/53/EU, the

packaging shows that this radio equipment will be subject to

some restrictions when placed on the market in Belgium (BE),

Bulgaria (BG), the Czech Republic (CZ), Denmark (DK),

Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain (ES),

France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV),

Lithuania (LT), Luxembourg (LU), Hungary (HU), Malta (MT),

Netherlands (NL), Austria (AT), Poland (PL), Portugal (PT),

Romania (RO), Slovenia (SI), Slovakia (SK), Finland (FI), Sweden

(SE), the United Kingdom (UK), Turkey (TR), Norway (NO),

Switzerland (CH), Iceland (IS), and Liechtenstein (LI).

The WLAN function for this device is restricted to indoor use

only when operating in the 5150 to 5350 MHz frequency

range.

Frequency Bands and Power

(a) Frequency bands in which the radio equipment operates:

Some bands may not be available in all countries or all areas.

Please contact the local carrier for more details.

(b) Maximum radio-frequency power transmitted in the

frequency bands in which the radio equipment operates: The

maximum power for all bands is less than the highest limit

value specied in the related Harmonized Standard.

The frequency bands and transmitting power (radiated and/or

conducted) nominal limits applicable to this radio equipment

are as follows:

ANE-LX1 GSM 900: 35dBm, GSM 1800: 32 dBm,

WCDMA 900/2100: 25.7 dBm, LTE Band

1/3/7/8/20: 25.7 dBm, Wi-Fi 2.4G: 20 dBm,

Bluetooth: 20 dBm, Wi-Fi 5G: 5150-5350 MHz:

23 dBm, 5470-5725 MHz: 30dBm, NFC: 60

dBuA/m at 10m

ANE-LX2 GSM 900: 35dBm, GSM 1800: 32 dBm,

WCDMA 900/2100: 25.7 dBm, LTE Band

1/3/7/8/34/38/40: 25.7 dBm, Wi-Fi 2.4G: 20

dBm, Bluetooth: 20 dBm

ANE-LX2J GSM 900: 35dBm, GSM 1800: 32 dBm,

WCDMA 900/2100: 25.7 dBm, LTE Band

1/3/7/8/28: 25.7 dBm, Wi-Fi 2.4G: 20 dBm,

Bluetooth: 20 dBm, Wi-Fi 5G: 5150-5350 MHz:

23 dBm, 5470-5725 MHz: 30dBm

Accessories and Software Information

Some accessories are optional in certain countries or regions.

Optional accessories can be purchased from a licensed vendor

as required. The following accessories are recommended:

Adapters: HW-059200XHQ, HW-090200XH0 (X represents the

different plug types used, which can be either C, U, J, E, B, A, I,

R, Z or K, depending on your region)

Batteries: HB366481ECW

Earphones: MEMD1532B528A00, HA1-3W, EPAB542-2WH03-

DH, 1293-3283-3.5mm-300

The product software version is ANE-LX1: ANE-LX1

8.0.0.41(SP1C900) / ANE-LX2: ANE-LX2 8.0.0.41(SP2C900) /

ANE-LX2J: ANE-LX2J 8.0.0.46(C900). Software updates will be

released by the manufacturer to x bugs or enhance functions

after the product has been released. All software versions

released by the manufacturer have been veried and are still

compliant with the related rules.

All RF parameters (for example, frequency range and output

power) are not accessible to the user, and cannot be changed

by the user.

For the most recent information about accessories and

software, please see the DoC (Declaration of Conformity) at

http://consumer.huawei.com/certication.

ErP Product Information (only applies to ANE-

LX1)

Huawei Technologies Co., Ltd. hereby declares that its

products conform to the Energy-related Products Directive

(ErP) 2009/125/EC. For detailed ErP information and the user

manuals required by Commission Regulation (EU) No

801/2013, please visit: http://consumer.huawei.com/en/

certication.

FCC Regulatory Compliance (only applies to

ANE-LX1 / ANE-LX2J / ANE-LX3)

Body worn operation

The device complies with RF specications when used near

your ear or at a distance of 1.50 cm from your body. Ensure

that the device accessories, such as a device case and device

holster, are not composed of metal components. Keep the

device away from your body to meet the distance requirement.

Certication information (SAR)

This device is also designed to meet the requirements for

exposure to radio waves established by the Federal

Communications Commission (USA).

The SAR limit adopted by the USA is 1.6 W/kg averaged over

one gram of tissue. The highest SAR value reported to the FCC

for this device type complies with this limit.

The highest SAR value reported to the FCC for this device type

when using it at the ear is

ANE-LX1 1.21 W/kg

ANE-LX2J 1.10 W/kg

ANE-LX3 0.88 W/kg

And when properly worn on the body is

ANE-LX1 1.08 W/kg

ANE-LX2J 0.97 W/kg

ANE-LX3 0.82 W/kg

And when using the Wi-Fi hotspot function is

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Huawei Handy Handbücher

Huawei

Huawei Mate 50 Pro Bedienungsanleitung

Huawei

Huawei U8230 Bedienungsanleitung

Huawei

Huawei nova Y60 Bedienungsanleitung

Huawei

Huawei ARS-L22 Bedienungsanleitung

Huawei

Huawei C5100 Bedienungsanleitung

Huawei

Huawei VTR-L09 Bedienungsanleitung

Huawei

Huawei P20 Lite 2019 Bedienungsanleitung

Huawei

Huawei G2200C Bedienungsanleitung

Huawei

Huawei Ascend G630 Bedienungsanleitung

Huawei

Huawei G700-U10 Bedienungsanleitung

Huawei

Huawei Ascend Y330-U08 Bedienungsanleitung

Huawei

Huawei H892L Bedienungsanleitung

Huawei

Huawei c3308 Bedienungsanleitung

Huawei

Huawei SLA-L22 Bedienungsanleitung

Huawei

Huawei Vitria Bedienungsanleitung

Huawei

Huawei GR3 Bedienungsanleitung

Huawei

Huawei Honor 8 Bedienungsanleitung

Huawei

Huawei U8185 Bedienungsanleitung

Huawei

Huawei Mobile Phones Bedienungsanleitung

Huawei

Huawei Ascend G740 Bedienungsanleitung

Huawei

Huawei G5760 Bedienungsanleitung

Huawei

Huawei Ascend P7 Bedienungsanleitung

Huawei

Huawei Ascend Y5 Bedienungsanleitung

Huawei

Huawei G3620 Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
