Huawei HG552a1 Bedienungsanleitung

HUAWEI HG552a1 Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI HG552a1 Home Gateway

V100R001

User Guide

Issue 02

Date 2010-10-10

Part Number 202317

Huawei Proprietary and Confidential

Huawei Technologies Co., Ltd. provides customers with comprehensive technical

support and service. For any assistance, please contact our local office or company

headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: [email protected]

No part of this document may be reproduced or transmitted in any form or by

any means without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of

Huawei Technologies Co., Ltd and possible licensors. Customers shall not in

any manner reproduce, distribute, modify, decompile, disassemble, decrypt,

extract, reverse engineer, lease, assign, or sublicense the said software, unless

such restrictions are prohibited by applicable laws or such actions are approved

by respective copyright holders under licenses.

Trademarks and Permissions

, HUAWEI, and are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the

property of their respective owners.

Huawei Proprietary and Confidential

Notice

Some features of the product and its accessories described herein rely on the

software installed, capacities and settings of local network, and may not be

activated or may be limited by local network operators or network service

providers, thus the descriptions herein may not exactly match the product or its

accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any

information or specifications contained in this manual without prior notice or

obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,

RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO

CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY

SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR

LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR

ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations

and will obtain all necessary governmental permits and licenses in order to

export, re-export or import the product mentioned in this manual including the

software and technical data therein.

Contents

1Warnings and Precautions ....................................................................................... 1

2Product Overview ..................................................................................................... 3

2.1 Product Features ........................................................................................................... 3

2.2 Network Application..................................................................................................... 4

2.3 Indicators, Interfaces and Buttons................................................................................. 5

Indicators .................................................................................................................... 5

Interfaces and Buttons................................................................................................. 7

2.4 System Requirements ................................................................................................... 8

3Product Installation .................................................................................................. 8

3.1 Connecting the Cables .................................................................................................. 8

3.2 Getting Started.............................................................................................................. 9

4Functions Introduction............................................................................................. 9

4.1 Accessing the Web Configuration Page........................................................................ 9

4.2 Accessing Mobile Storage Devices............................................................................. 10

4.3 Changing the User Name and Password of the Web Configuration Page................... 11

4.4 Changing the IP Address ............................................................................................ 12

4.5 Restoring Default Settings .......................................................................................... 12

5Voice Services.......................................................................................................... 12

5.1 Introduction ................................................................................................................ 12

5.2 Voice Service Introduction ......................................................................................... 13

Networking ............................................................................................................... 13

Configuration Procedure ........................................................................................... 13

6Wireless Services..................................................................................................... 14

6.1 Configuring the Wireless Connection by the Web Page ............................................. 14

6.2 Configuring the Wireless Connection Manually......................................................... 15

7FAQs ........................................................................................................................ 15

Figures

Figure 2-1 Network application of the HG552a1.................................................................. 4

Figure 2-2 Indicators ............................................................................................................ 5

Figure 2-3 Interfaces and buttons ......................................................................................... 7

Figure 3-1 Connecting the HG552a1.................................................................................... 9

Figure 4-1 Connect to the USB interface............................................................................ 10

Figure 5-1 Network model of voice services ...................................................................... 13

Tables

Table 2-1 Description of the elements for the network application diagram......................... 5

Table 2-2 Meanings of the indicators.................................................................................... 6

Table 2-3 Functions of the interfaces and buttons................................................................. 7

Table 4-1 Requirements on PC settings .............................................................................. 10

Table 5-1 Description of the equipment in voice service networking................................. 13

Warnings and Precautions

1 Warnings and Precautions

To use the device properly and safely, read these warnings and precautions carefully and strictly

observe them during operation. Unless otherwise specified, the term "device" refers to the device

and its accessories.

Basic Requirements

zDuring storage, transportation, and operation of the device, keep it dry and prevent it from

colliding with other objects.

zDo not dismantle the device. In case of any fault, contact an authorized service center for

assistance or repair.

zWithout authorization, no organization or individual can change the mechanical, safety, or

performance design of the device.

zWhen using the device, observe all applicable laws and regulations and respect the legal rights

of other people.

Environmental Requirements for Using the Device

zBefore connecting and disconnecting cables, stop using the device, and then disconnect it from

the power supply. Ensure that your hands are dry during operation.

zKeep the device far from sources of heat and fire, such as a heater or a candle.

zKeep the device far from electronic appliances that generate strong magnetic or electric fields,

such as a microwave oven or a refrigerator.

zPlace the device on a stable surface.

zPlace the device in a cool and well-ventilated indoor area. Do not expose the device to direct

sunlight. Use the device in an area with a temperature ranging from 0°C to 40°C.

zDo not block the openings on the device with any object. Reserve a minimum space of 10 cm

around the device for heat dissipation.

zDo not place any object (such as a candle or a water container) on the device. If any foreign

object or liquid enters the device, stop using the device immediately, power it off, remove all

the cables connected to it, and then contact an authorized service center.

zDuring thunderstorms, power off the device, and then remove all the cables connected to it to

prevent it from getting damaged due to lightning strikes.

Precautions for Using Wireless Devices

zWhen using the device, ensure that the antenna of the device is at least 20 cm away from all

persons.

zDo not use the device where using wireless devices is prohibited or may cause interference or

danger.

Warnings and Precautions

zThe radio waves generated by the device may interfere with the operation of electronic medical

devices. If you are using any electrical medical device, contact its manufacturer for the

restrictions on the use of the device.

zDo not take the device into operating rooms, intensive care units (ICUs), or coronary care units

(CCUs).

Areas with Inflammables and Explosives

zDo not use the device where inflammables or explosives are stored, for example, in a gas

station, oil depot, or chemical plant. Otherwise, explosions or fires may occur. In addition,

follow the instructions indicated in text or symbols.

zDo not store or transport the device in the same box as inflammable liquids, gases, or

explosives.

Accessory Requirements

zUse only the accessories supplied or authorized by the device manufacturer. Otherwise, the

performance of the device may get affected, the warranty for the device or the laws and

regulations related to telecommunications terminals may become null and void, or an injury

may occur.

zDo not use the power adapter if its cable is damaged. Otherwise, electric shocks or fires may

occur.

zEnsure that the power adapter meets the specifications indicated on the device nameplate.

zEnsure that the power adapter meets the requirements of Clause 2.5 in

IEC60950-1/EN60950-1 and it is tested and approved according to national or local standards.

zFor pluggable device, the socket-outlet shall be installed near the device and shall be easily

accessible.

Safety of Children

Keep the device and its accessories out of the reach of children. Otherwise, they may damage the

device and its accessories by mistake, or they may swallow the small components of the device,

causing suffocation or other dangerous situations.

Maintenance

zIf the device is not used for a long time, power it off, and then remove all the cables connected

to it.

zIf any exception occurs, for example, if the device emits any smoke or unusual sound or smell,

stop using the device immediately, power it off, remove all the cables connected to it, and then

contact an authorized service center.

zDo not trample, pull, or overbend any cable. Otherwise, the cable may get damaged, causing

malfunction of the device.

zBefore cleaning the device, stop using it, power it off, and then remove all the cables connected

to it.

Product Overview

zUse a clean, soft, and dry cloth to clean the device shell. Do not use any cleaning agent or spray

to clean the device shell.

2 Product Overview

2.1 Product Features

The EchoLife HG552a1 (hereinafter referred to as the HG552a1) is a high-performance

Asymmetrical Digital Subscriber Line (ADSL) voice gateway designed for home users and small

office and home office (SOHO) users. This section describes the features of the HG552a1.

Flexible Routing

zProviding an embedded Point to Point Protocol over Ethernet (PPPoE) dialer

zSupporting the Dynamic Host Configuration Protocol (DHCP) server

zSupporting simultaneous multi-user access

Abundant Service Interfaces

zProviding four high-speed Ethernet interfaces

zSupporting the routing mode and the bridge mode

zProviding the voice function through the Plain Old Telephone Service (POTS) interface

zSupporting the multi-service set identifier (MSSID) of Wireless Fidelity (WiFi), which

enables users to use wireless networks conveniently and securely

zProviding mobile storage capability through the USB host interface

Outstanding Voice Functions

Providing VoIP service and T.38 facsimile service

Standard TR-069 Management Capability

zProviding complete compatibility with the TR-069 standard of the Digital Subscriber Line

(DSL) Forum

zProviding complete remote management and diagnosis

zProviding a zero-configuration solution, which significantly lowers the operation and

maintenance costs and can be combined with the automatic upgrade and service provisioning

processes to conveniently distribute customized services

ADSL/ADSL2+ Interface

zProviding embedded ADSL/ADSL2+ broadband network functions

zSupporting the ITU-T G.994.1 (G.hs) handshake protocol

Product Overview

zProviding compatibility with Annex A ANSI T1.413 Issue 2, ITU-T G.992.1 (G.dmt), G.992.3

(ADSL2), and G.992.5 (ADSL2+)

Wide Area Network (WAN) Protocol

zSupporting multiple AAL5 protocols, such as LLC and VC-MUX (RFC1483/2684)

zSupporting PPPoE (RFC2516)

zSupporting routing and bridging in conformance with RFC 2684

2.2 Network Application

Figure 2-1 shows the network application of the HG552a1.

Figure 2-1 Network application of the HG552a1

z: indicates an actual network connection.

z: indicates a logical management channel.

Table 2-1 describes the elements shown in Figure 2-1.

Inhaltsverzeichnis

Andere Huawei Tor Handbücher

Huawei

Huawei HG630B Bedienungsanleitung

Huawei

Huawei EchoLife HG521 Bedienungsanleitung

Huawei

Huawei HG256s Bedienungsanleitung

Huawei

Huawei EchoLife HG532a Bedienungsanleitung

Huawei

Huawei RRU3808 V200 Bedienungsanleitung

Huawei

Huawei HG532e Bedienungsanleitung

Huawei

Huawei ICE D-20 EC506 Bedienungsanleitung

Huawei

Huawei HG523a Bedienungsanleitung

Huawei

Huawei Echolife HG520b Bedienungsanleitung

Huawei

Huawei B890 LTE Bedienungsanleitung

Huawei

Huawei OptiXstar B850G-8E8P3W3 Bedienungsanleitung

Huawei

Huawei BTS3902E WCDMA Leitfaden

Huawei

Huawei DBS3900 IBS Leitfaden

Huawei

Huawei HG530 Bedienungsanleitung

Huawei

Huawei HG658d Bedienungsanleitung

Huawei

Huawei IAD108A Bedienungsanleitung

Huawei

Huawei HG532c Bedienungsanleitung

Huawei

Huawei EchoLife HG520 Bedienungsanleitung

Huawei

Huawei eSpace EGW1520 Bedienungsanleitung

Huawei

Huawei EchoLife HG532 Bedienungsanleitung

Huawei

Huawei HG530 Bedienungsanleitung

Huawei

Huawei HG533 Bedienungsanleitung

Huawei

Huawei AR-Sc Series Bedienungsanleitung

Huawei

Huawei HG633 Bedienungsanleitung

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung

RTA

RTA 460MCBC-N2E Technisches Datenblatt
