Huawei HG630a Bedienungsanleitung

HG630a Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

HG630a Home Gateway

V100R001

User Guide

Issue 01

Date 2012-07-24

Part Number 202517

Huawei Technologies Co., Ltd. provides customers with comprehensive

technical support and service. Please feel free to contact our local office

or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: mobile@huawei.com

rights reserved.

No part of this document may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei

Technologies Co., Ltd and possible licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse

engineer, lease, assign, or sublicense the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by respective copyright

holders under licenses.

Trademarks and Permissions

, , and

are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of

their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software

installed, capacities and settings of local network, and may not be activated or may be

limited by local network operators or network service providers. Thus the descriptions

herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or

specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS’’. EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE

SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,

INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,

BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will

obtain all necessary governmental permits and licenses in order to export, re-export or

import the product mentioned in this manual including the software and technical data

therein.

Contents

1 Connecting the Cables and Getting Started ........................... 1

1.1 Connecting Cables Using the DSL Port..........................................1

1.2 Connecting Cables Using the WAN Port.........................................3

1.3 Connecting Cables Using the USB Port ....................................4

2 Setting Network Access Parameters....................................... 5

2.1 Logging In to the Web-based Configuration Utility..........................5

2.2 Configuring a Dial-up Connection for Internet Access...............6

3 Setting Up a Wireless Connection........................................... 7

3.1 Setting Up a Wireless Connection With the WPS Button ..........7

3.2 Setting Up a Wireless Connection Manually..............................8

4 Maintenance Guide ................................................................. 10

4.1 Changing the User Name and Password for the Web-Based

Configuration Utility.........................................................................10

4.2 Enabling or Disabling the Wireless Network Function ...................10

4.3 Changing the Wireless Network Name and Password.....................11

4.4 Changing the IP Address Used to Log In to the Web-based

Configuration Utility.........................................................................12

4.5 Restoring Default Settings ...........................................................13

4.6 Configuring the Firewall .............................................................13

5 Applications Guide ................................................................. 14

5.1 Accessing a Portable Storage Device Using the FTP Client....14

5.2 Allowing Internet Users to Access an Internal Resource Server

.......................................................................................................15

6 FAQs......................................................................................... 17

7 Appendix.................................................................................. 21

7.1 Indicators ...................................................................................21

7.2 Ports and Buttons........................................................................24

7.3 Default Settings ..........................................................................26

7.4 Technical Specifications ...........................................................26

1 Connecting the Cables and Getting

Started

Thank you for purchasing the HG630a Home Gateway (hereinafter referred to

as the HG630a).

You can go online using the DSL, Ethernet, and USB modem services.

However, you can only use one type of service at one time. The default way of

going online is using the DSL service, though you can go online using the USB

modem service when you cannot access the network using the DSL or Ethernet

services.

1.1 Connecting Cables Using the DSL Port

Connecting Cables

If there is at least one available telephone wall jack in your home, you can go

online using the DSL service.

1. Telephone wall jack

2. Splitter

3. Telephone

4. Desktop computer

5. Power adapter

6. Laptop computer

7. HG630a

a. LINE port

b. PHONE port

c. MODEM port

Getting Started

After connecting the cables, press the On/Off button on the side panel to power

on the HG630a.

After you power on the HG630a, the Power indicator turns on. The DSL

indicator lights up and starts blinking. This indicates that the DSL port activation

is in progress. The blinking may last less than 3 minutes. When the DSL

indicator stops blinking and remains on, the HG630a is working properly.

To power off the HG630a, press the On/Off button on the side

panel, and then unplug the power adapter.

1.2 Connecting Cables Using the WAN Port

Connecting Cables

If there is at least one available Ethernet wall jack in your home, you can go

online using the Ethernet service.

Laptop computer 2.

Desktop computer 3.

Ethernet wall jack

Power adapter 5.

HG630a

Getting Started

After connecting the cables, press the On/Off button on the side panel to power

on the HG630a.

After you power on the HG630a, the Power indicator turns on, the WAN

indicator turns on. This indicates that the HG630a is working properly. When the

WAN indicator starts blinking, data is being transmitted between the HG630a

and the connected device.

1.3 Connecting Cables Using the USB Port

Connecting Cables

Laptop computer 2.

Desktop computer 3.

USB modem

Power adapter 5.

HG630a

Getting Started

After connecting the cables, press the On/Off button on the side of the HG630a

to power on the HG630a.

After you power on the HG630a, the Power indicator turns on, the USB

indicator turns on. This indicates that the HG630a is working properly. When the

USB indicator starts blinking, data is being transmitted between the HG630a

and the connected device.

2 Setting Network Access Parameters

2.1 Logging In to the Web-based Configuration

Utility

Most of the HG630a parameters are preset before delivery to meet common

home application scenarios. To check the HG630a's working status or configure

certain advanced network functions, use the web-based configuration utility.

To log in to the web-based configuration utility,

Step 1 Set up network access for your computer. Set the network connection

of your computer to obtain an IP address automatically.

Step 2 Open a web browser on your computer and ensure that the browser

does not use any proxy servers.

Using Internet Explorer 8.0 as an example to ensure no proxy servers

are used:

1. Choose Tools > Internet Options.

2. On the Connections tab of the Internet Options dialog box, click

LAN Settings.

3. In the Proxy server area, ensure that Use a proxy server for your

LAN is cleared. If Use a proxy server for your LAN is selected, clear

Use a proxy server for your LAN, and then click OK.

Step 3 Enter http://192.168.1.1 in the address bar, and then press Enter.

Step 4 Enter the user name (default is user) and password (default is

HuaweiUser) in the Username and Password text boxes.

Step 5 Click Login.

By default, the Dynamic Host Configuration Protocol (DHCP)

function is enabled. The HG630a then assigns an IP address to your

computer automatically. If you disable the DHCP function, please

ensure that the IP address of the computer and that of the HG630a

LAN port are in the same network segment to enable the computer to

access the web-based configuration utility.
