Huawei HiLink E3231 Technische Daten

Product Description

HiLink E3231 HSPA+ USB Stick

V100R001

Issue

Date

2012-2-24

HUAWEI TECHNOLOGIES CO., LTD.

Issue 01 (2011-2-24)

Commercial in Confidence

Page 1 of 17

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.

Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address:

Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website:

http://www.huawei.com

Email:

[email protected]

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 2 of 17

About This Document

Summary

This document provides information about the major functions, supported services,

system architecture, and technical references of HiLink E3231 HSPA+ USB Stick

(hereinafter referred to as the HiLink E3231).

The following table lists the contents of this document.

Chapter

Describes

1 Overview

The supported network modes, basic services and functions,

and the appearance of the HiLink E3231.

2 Features

The supported features and technical specifications of the

HiLink E3231.

3 Services and Applications

The services and applications of the HiLink E3231.

4 System Architecture

The architecture of the HiLink E3231.

5 Technical Reference

The technical references of the HiLink E3231.

6 Packing List

The items contained in the package of the HiLink E3231.

A Acronyms and Abbreviations

The acronyms and abbreviations mentioned in this document.

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 3 of 17

History

Issue

Details

Date

Author

Approved by

Initial draft completed.

2012-2-24

Huangxing/194155

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 4 of 17

Contents

1 Overview..........................................................................................................................5

2 Features...........................................................................................................................6

2.1 Main Features .................................................................................................................................. 6

2.2 Technical Specifications ................................................................................................................... 7

2.2.1 Hardware................................................................................................................................. 7

2.2.2 Software Specifications ........................................................................................................... 8

3 Services and Applications .............................................................................................9

3.1 Packet Data Service......................................................................................................................... 9

4 System Architecture.....................................................................................................10

4.1 System Architecture ....................................................................................................................... 10

4.2 Functional Modules.........................................................................................................................11

5 Technical Reference.....................................................................................................12

5.1 Layer 1 Specifications (Physical) ................................................................................................... 12

5.2 Layer 2 Specifications (MAC/RLC)................................................................................................. 12

5.3 Layer 3 Specifications (RRC)......................................................................................................... 12

5.4 Layer 3 NAS/Core Network (MM/CM)............................................................................................ 12

5.5 General Specifications ................................................................................................................... 13

5.6 Performance/Test Specifications.................................................................................................... 13

5.7 SIM Specifications.......................................................................................................................... 13

6 Packing List...................................................................................................................14

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 5 of 17

1 Overview

The HiLink E3231 supports the following standards:

High-speed packet access plus (HSPA+)

Universal Mobile Telecommunications System (UMTS)

Wideband Code Division MultipleAccess (WCDMA)

The HiLink E3231 provides the following services:

HSPA+ packet data service

HSUPA packet data service

HSDPA/UMTS packet data service

You can connect the HiLink E3231 with the USB interface of a computer. In the service

area of the HSPA+/UMTS network, you can surf the Internet and send/receive emails.

The HiLink E3231 is fast, reliable, and easy to operate. Thus, mobile users can

experience many new features and services with the HiLink E3231. These features

and services will enable a large number of users to use the HiLink E3231 and the

average revenue per user (ARPU) of operators will increase substantially.

Figure 1-1 shows the profile of the HiLink E3231.

Figure 1-1 HiLink E3231 profile

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 6 of 17

2 Features

2.1 Main Features

The HiLink E3231 mainly supports the following features:

HSPA+/UMTS 2100MHz;

Equalizer and receive diversity（EEIC）

HSPA+ data service of up to 21.6 Mbps

HSUPA data service of up to 5.76 Mbps

UMTS PS domain data service of up to 384 kbps

Micro Secure Digital Memory (microSD) Card;

USB Stick, easy to connect;

Plug and play;

Standard USB interface（Type A）

Dual internal antenna

Windows XP SP3、Windows Vista SP1/SP2、Windows 7、Mac OS X 10.5, 10.6

and 10.7 with latest upgrades;

HiLink features (Driverless, Web UI, Auto connect)

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 7 of 17

2.2 Technical Specifications

2.2.1 Hardware

Table 2-1 Hardware specifications

Item

Specifications

Technical

standard

WCDMA/HSDPA R5, HSUPA R7，HSPA+ R7

Operating

frequency

WCDMA/HSPA/HSPA+ 2100MHz：

1920MHz~1980 MHz/2110MHz~2170 MHz(UL/DL)

External

interfaces

USB 2.0 High Speed

SIM/USIM card: standard 6-pin SIM card interface

microSD Card Slot

LED

indicating the status of the HiLink E3231

Maximum

transmitter

power

WCDMA/HSPA+ 2100MHz: 24dBm +1/-3 (Power Class 3)

Static receiver

sensitivity

WCDMA/HSPA+ 2100 MHz:

Compliant with 3GPP TS 25.101(R8)

Power supply

4.75V-5.25V

Dimensions

(D × W × H)

86.5X26X11mm

Weight

<30g

Temperature

Operating: –10℃to +45℃

Storage: –20℃to +70℃

Humidity

5% to 95%

Notes:

3GPP = The 3rd Generation Partnership Project

EGPRS = enhanced GPRS

LED = light-emitting diode

MSC = mobile switching center

SIM = subscriber identity module

TS = technical specification

USIM = UMTS subscriber identity module

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 8 of 17

2.2.2 Software Specifications

Table 2-2 Software specifications

Item

Description

Basic specifications

Driverless

Web UI

Auto connect, auto reconnect

Display the device information by website

PIN management

PIN unlock

Special SMS reminding

Support the display of unread service messages

(Customizing service number required)

Device information

display

Connection status

Signal

Operator name

Network mode

Roam status

System requirement

Windows XP SP3、Windows Vista SP1/SP2、Windows

7、Mac OS X 10.5, 10.6 and 10.7 with latest upgrades;

Your computer’s hardware system should meet or

exceed the recommended system requirements for the

installed version of OS

Display resolution: 800 × 600 or above

Notes:

PIN = personal identification number

PUK = PIN unblocking key

HiLink E3231 HSPA+ USB Stick

Product Description

Issue 01 (2011-2-24)

Commercial in Confidence

Page 9 of 17

3 Services and Applications

3.1 Packet Data Service

The HiLink E3231 supports the data service based on HSPA+/HSUPA/HSDPA/UMTS.

After you connect the HiLink E3231 to a PC with the USB interface, the HiLink E3231

will connect the network automatically. Then you can send or receive E-mail, access

the network through wireless connection, and download files through wireless data

channels.
