Huawei SmartAX MT882a Bedienungsanleitung
SmartAX MT882a ADSL CPE
User Guide
HUAWEI TECHNOLOGIES CO., LTD.
SmartAX MT882a ADSL CPE
V100R001
User Guide
Issue 01
Date 2008-12-24
Part Number 103130
Huawei Technologies Co., Ltd. provides customers with comprehensive
technical support and service. Please feel free to contact our local office
or company headquarters.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [email protected]
Copyright © Huawei Technologies Co., Ltd. 2008. All
rights reserved.
No part of this document may be reproduced or transmitted in any form or
by any means without prior written consent of Huawei Technologies Co.,
Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei
Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the
property of their respective holders.
Notice
The information in this document is subject to change without notice.
Every effort has been made in the preparation of this document to ensure
accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any
kind, express or implied.
Contents
1Safety Precautions..................................................................................... 1
2Connecting the Cables and Getting Started............................................ 4
2.1 Simple Connection .......................................................................................4
2.2 Connecting One Telephone ..........................................................................5
2.3 Connecting Multiple Telephones .................................................................6
2.4 Getting Started .............................................................................................6
3Installing the USB Driver ......................................................................... 7
3.1 Installing the USB Driver on the Linux OS..................................................7
3.2 Installing the USB Driver on the MAC OS ..................................................9
3.3 Installing the USB Driver on the Windows OS..........................................11
4Setting the Network-Access Parameters ............................................... 15
4.1 Accessing the Network Through the Embedded PPP Dial-Up Software of the
MT882a .............................................................................................................15
4.2 Accessing the Network Through the PPP Dial-Up Software on the Computer
...........................................................................................................................16
5Configuring the MT882a ........................................................................ 17
5.1 Changing the Administrator Password Used for Logging In to the Web
Configuration Page ............................................................................................17
5.2 Changing the IP Address............................................................................18
5.3 Restoring Default Settings..........................................................................18
i
6FAQs......................................................................................................... 18
7Appendix.................................................................................................. 22
7.1 Indicators....................................................................................................22
7.2 Interfaces and Buttons................................................................................22
7.3 Default Settings..........................................................................................23
7.4 Technical Specifications.............................................................................23
ii
1
1 Safety Precautions
Thank you for purchasing SmartAX MT882a ADSL CPE (hereinafter referred to as the
MT882a).
For safety purposes, carefully read through these safety precautions and observe them
during operation.
Basic Requirements
zKeep the device dry during storage, transportation, and operation of the device.
zPrevent collision of the device with other objects during storage, transportation, and
operation of the device.
zDo not attempt to dismantle the device. In case of any fault, contact the authorized
maintenance center for assistance or repair.
zWithout prior written consent, no organization or individual is permitted to make
any change to the structure, safety, and performance design of the device.
zWhile using the device, observe all applicable laws, directives and regulations, and
respect the legal rights of other people.
Environmental Requirements
zPlace the device in a well-ventilated place. Do not expose the device to direct
sunlight.
zKeep the device clean, free of dust and stain.
zDo not place the device near a water source or in a damp area.
zPlace the device on a stable surface.
zDo not place any object on the top of the device. Reserve a minimum space of 10
cm at the four sides and on the top of the device for heat dissipation.
zDo not place the device on or near inflammable materials such as foam.
zKeep the device away from heat source or fire, such as a radiator or a candle.
zKeep the device away from any household appliances with strong magnetic field or
electric field, such as microwave oven, refrigerator, or mobile phone.
2
Operation Requirements
zDo not allow children to play with the device or accessories. Swallowing the
accessories may be fatal.
zUse the accessories such as the power adaptor provided or authorized only by the
manufacturer.
zMake sure that the device does not get wet. If water gets into the device, disconnect
the power supply immediately and unplug all the cables connected to the device.
zThe power supply of the device must meet the requirements of the input voltage of
the device.
zBefore plugging or unplugging any cable, shut down the device and disconnect the
power supply.
zWhile plugging or unplugging any cable, make sure that your hands are dry.
zDo not step on, pull, or stretch any cable. Otherwise, the cable may get damaged,
leading to malfunction of the device.
zDo not use old or damaged cables.
zKeep the power plug clean and dry, to prevent electric shock or other dangers.
zDuring lightning, disconnect the device from the power supply and unplug all the
cables connected to the device, such as the power cable, telephone cable, and RF
cable, to prevent lightning strike.
zIf the device is not used for a long time, disconnect the power supply and unplug the
all the cables connected to the device.
zIf smoke, sound, or smell is emitted from the device, stop using the device
immediately, disconnect the power supply, unplug the power supply and other
cables, and remove the batteries. Contact the authorized maintenance center for
repair.
zMake sure that no object (such as metal shavings) enters the device through the heat
dissipation vent.
zDo not scratch or abrade the shell of the device. The shed painting may lead to skin
allergy or malfunctions of the device. If the shed painting material drops into the
host, a short circuit may occur.
Cleaning Requirements
zBefore cleaning the device, stop using it, disconnect the power supply, and unplug
all the cables connected to the device.
zDo not clean the device cover with any cleaning solution or cleanser spray. Use a
piece of soft cloth to clean the device cover.
3
Environmental Protection
Do not dispose the abandoned device or battery in a garbage can. You need to dispose it
according to the local regulations on disposing of device packing materials, exhausted
battery and abandoned device, and support the recycling activity.
After the MT882a is used for a certain period of time, the cover will be
heated, which will not affect the function of the MT882a.
4
2 Connecting the Cables and Getting
Started
2.1 Simple Connection
If your telephone line is used for the broadband network access only and you do not
need to use a telephone, take the following figure as a reference for connecting the
cables.
1
2
3
POWER
LAN
RESET
ADSL
USB
1 Telephone jack on the wall 2 Computer 3 Power adapter
5
2.2 Connecting One Telephone
If your telephone line is used for both the broadband network access and a telephone
connection, take the following figure as a reference for connecting the cables.
POWER
LAN
RESET
1
2
3
4
ADSL
5
USB
1 Telephone jack on the wall 2 Splitter
3 Telephone 4 Computer
5 Power adapter
