Quidway® AR 46 Router E3/T3 Interface Module

http://datacomm.huawei.com

Quidway® AR 46 Router E3/T3 Interface Module

Overview

The E3/T3 interface module of the AR46 router includes four types: FIC-1CE3, FIC-1CT3,

FIC-1AE3 and FIC-1AT3.

The major functions of E3 interface module, FIC-1CE3, of the AR46 router are:

In the E3 working mode, it can transmit and process one-channel E3 high-speed data flow and

provide the access service for E3 data flow.

In the CE3 working mode, it can provide N × 64 Kbps (N is no more than 128) lower-rate

access service for users.

The major functions of T3 interface module, FIC-1CT3, of the AR46 router are:

In the T3 working mode, it can transmit and process one-channel T3 high-speed data flow and

provide the access service for T3 data flow.

In the CT3 working mode, it can provide N × 64 Kbps or 56 Kbps (N is no more than 128)

lower-rate access service for users.

FIC-1AE3 is the abbreviation of 1-port 34.368 Mbps ATM-E3 interface card. FIC-1AT3 indicates

1-port 44.736 Mbps ATM-T3 interface card. Where, ATM stands for Asynchronous Transfer Mode.

They have the following function features in the system:

Support two ATM cell mapping modes: ATM Direct Mapping (ADM) and Physical Layer

Convergence Protocol (PLCP).

Allow scrambling transmission in data sending.

Support two clock modes: line clock (when serving as DTE interface) and internal clock (when

serving as DCE interface).

Support four self-loop test modes: local cell loop, local loop, remote load loop and remote line

loop.

Specifications

The specifications of E3/T3 interface module of the AR46 router are shown in the following table.

Product Number Connector Type Description

RT-FIC-1AE3 SMB AR46 1-portATM Over E3 module

RT-FIC-1AT3 SMB AR46 1-port ATM Over T3 module

RT-FIC-1CE3 SMB AR46 1-prot E3/CE3 compatible interface module

RT-FIC-1CT3 SMB AR46 1-port T3/CT3 compatible interface module

Quidway® AR 46 Router E3/T3 Interface Module

http://datacomm.huawei.com

Interface attribute

The interface attributes of E3/T3 interface module of the AR46 router are shown in the following

tables.

FIC-1AE3 interface attribute

Attribute FIC-1AE3

Connector type SMB

Connector quantity 2

Interface standard G.703，G.751，G.832，G.823

Interface rate 34.368 Mbps

Interface cable type E3/T3 cable (75Ωcoaxial cable)

Service supported ATM Traffic CBR (Constant Bit Rate), rt_VBR (Variable Bit Rate-Real Time),

nrt_VBR (Variable Bit Rate-Non Real Time), UBR (Unspecified Bit Rate)

FIC-1AT3 interface attribute

Attribute FIC-1AT3

Connector type SMB

Connector quantity 2

Interface standard G.703, G.704, G.823

Interface rate 44.736 Mbps

Interface cable type E3/T3 cable (75Ωcoaxial cable)

Service supported ATM Traffic CBR (Constant Bit Rate), rt_VBR (Variable Bit Rate-Real Time),

nrt_VBR (Variable Bit Rate-Non Real Time), UBR (Unspecified Bit Rate)

FIC-1CE3 interface attribute

Attribute Description

Connector type SMB

Connector quantity 2/4

Interface standard G.703，G.704，G.751

Interface rate 34.368 Mbps

Interface cable type E3 cable (75Ωcoaxial cable)

Working mode E3

CE3

Service supported E3

Quidway® AR 46 Router E3/T3 Interface Module

http://datacomm.huawei.com

FIC-1CT3 interface attribute

Attribute Description

Connector type SMB

Connector quantity 2

Interface standard

G.703

G.704

G.752

AT&T TR 54014

AT&T TR 62415

ANSI T1.107

Interface rate 44.736 Mbps

Interface cable type T3 cable (75Ωcoaxial cable)

Working mode T3

CT3

Service supported T3 leased line
