Huawei EG8120L5 Bedienungsanleitung

EG8120L5

Quick Start

Issue 02

Date 2019-09-10

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and the

customer. All or part of the products, services and features described in this document may not be within the

purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,

and recommendations in this document are provided "AS IS" without warranties, guarantees or

representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: [email protected]

Contents

1 Placing the Device......................................................................................................................... 1

2 Connecting Cables.........................................................................................................................3

3 Indicator Description....................................................................................................................5

4 Technical Specifications...............................................................................................................7

5 FAQs.................................................................................................................................................8

EG8120L5

Quick Start Contents

1 Placing the Device

NOTE

lDo not install the ONT outdoors or in an outdoor cabinet.

lThe ONT can be mounted onto a wall or placed on a desk. Do not install the ONT in other modes,

such as ceiling.

lKeep 10 cm clearance on all sides to ensure adequate ventilation.

lIt is recommended that the computer and ONT be put far away from electric appliances that generate

strong magnetic or electric fields, such as microwave ovens.

Mounting an ONT on the desk

The figure below shows an ONT that is horizontally placed on a desk.

NOTE

The appearance shown in this document may be different from the actual appearance of the product. The

actual product prevails.

EG8120L5

Quick Start 1 Placing the Device

Mounting an ONT onto the wall

1. Mark two positions with the same spacing as that between the two mounting holes of the

ONT using a marker on a wall.

2. Select a proper drill bit according to the outer diameter of the screws. Use a hammer drill

to drill the marked positions on the wall. Then clean the holes and install two expansion

bolts.

3. Use a screwdriver to fasten the screws into the expansion bolts, reserving 5 mm ends out

of the wall, and mount the ONT onto the screws.

NOTE

It is recommended that the screw be about 4 mm in diameter and longer than 20 mm.

EG8120L5

Quick Start 1 Placing the Device

2 Connecting Cables

NOTE

lThe fiber connector connected to the optical port on the wall varies depending on actual conditions.

lTo ensure normal use of fibers, make sure that the fiber bending radius is larger than 30 mm.

EG8120L5

Quick Start 2 Connecting Cables

No. Item Description

1 TEL Connects to the port on a telephone or fax machine.

2 LAN1-LAN2 Connects to PCs or IP set-top boxes (STBs).

3 Power Connects to a power adapter.

4 On/Off Powers the ONT on or off.

5 Reset Press the button for a short time to reset the device; or press

the button for a long time (longer than 10s) to restore the

device to the default settings and reset the device.

NOTE

Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to

access the Internet. If an ONT cannot access the Internet after a reset,

contact your Internet service provider.

6 Optical port The optical port is equipped with a rubber plug and connected

to a fiber for upstream transmission.

The type of the optical connector connected to the optical port

can be SC/APC.

EG8120L5

Quick Start 2 Connecting Cables

3 Indicator Description

Indicator Status Description

Power Steady on The ONT is powered on.

Off The power supply is cut off.

PON/LOS See the following table.

LAN1-

LAN2

Steady on The Ethernet connection is in the normal state.

Blinking Data is being transmitted over the Ethernet port.

Off The Ethernet connection is not set up.

TEL Steady on The ONT is registered with the softswitch but no

service flows are transmitted.

Blinks twice a

second

The ONT is registered with the softswitch, and data is

being transmitted on the port.

Blinks once every

2 seconds

The ONT fails to be registered with the softswitch.

Off The POTS port is disabled.

Status

No.

PON Status LOS Status Description

1 Off Off The ONT is prohibited by the upper-layer

device or blinks abnormally. Contact the

service provider for help.

2 Blinks twice a

second

Blinks twice a

second

EG8120L5

Quick Start 3 Indicator Description

Status

No.

PON Status LOS Status Description

3 Blinks twice a

second

Off The ONT attempts to set up a connection

with its upper-layer device.

4 Steady on Off A connection is set up between the ONT

and its upper-layer device.

5 Off Blinks once

every 2

seconds

The ONT is not connected to fibers or does

not receive optical signals.

6 Blinks once

every 2

seconds

Blinks once

every 2

seconds

The hardware is faulty.

EG8120L5

Quick Start 3 Indicator Description

4 Technical Specifications

Product Function

EG8120L5 l2 Ethernet ports (1*GE+1*FE)

l1 POTS port

lPower adapter input: See the nameplate on the adapter.

lSystem power supply: See the nameplate on the device.

lAmbient temperature: 0ºC to +40ºC

lAmbient humidity: 5%–95% (non-condensing)

lDimensions (H x W x D): 145 mm x 97 mm x 32 mm

lWeight: About 145 g

lMaximum system power consumption: 5 W

EG8120L5

Quick Start 4 Technical Specifications
