Huawei HW-02G Bedienungsanleitung

Thank you for purchasing the HW-02G. This HW-02G

brings you a high speed wireless network connection.

This document will help you understand your HW-02G so you can start using it right away.

Please read this document carefully before using your HW-02G.

For detailed instructions for logging in to the web management page, refer to "Logging In to

the Web Management Page" on page 14.

Getting to Know Your HW-02G

Note:

The HW-02G function descriptions and illustrations in this document are for your

reference only. The product you have purchased may vary.

Application Scenarios

Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can

all access the Internet through HW-02G. The specific connection procedure depends on the

operating system of the Wi-Fi device or computer. Establish a connection according to your

device's specific instructions.

To access the Internet through a USB port connection, install the driver according to the

instructions.

Scenario 1: Connecting multiple devices

through Wi-Fi

Scenario 2: Connecting multiple devices

through Wi-Fi and USB simultaneously

Appearance

Power button

Lanyard hole

Screen

Micro USB port

Screen

Status bar

Character zone

When connect to GSM/3G/LTE network, show the operator name

When connect to public Wi-Fi hotspot, show the SSID name of the hotspot

When SIM card is not normal, show "PIN1 code required"/"PIN unlock code required";

Public WLAN

User can tap on to turn on or turn off Wi-Fi.

Data usage information

If user set the data information, show used data and total data.If user turn off the display of data on Home

screen, hide this zone.

Menu

Tap on to view more functions. If user turn on Auto-check for updates and there is new

available update, show an colored image on the right-up of the button.

Wi-Fi connection guide

Signal strength

R: when in roaming status; Show network mode, including "3G/LTE".

: when connecting to public Wi-Fi hotspot.

Icon of traffic.

Show the icon when connect to network. When there is upload and download data the icon

changes color. When disconnect from network, hide the icon.

Time information

Wi-Fi

Wi-Fi turned on.

Number of connected Wi-Fi devices.

Wi-Fi Mode

DFS

When HW-02G is during DFS checking progress, the DFS icon show and flashes. When

HW-02G connect to the 5G_W52/W53 network that can be only used indoor only, show this

icon. Otherwise hide the icon.

USB

Show it when connected to USB cable and HW-02G supports Charging with standard

functions process. If connected to USB cable only for charging, hide this icon.

Battery

: Battery level from low to high.

SSID and Wireless Network Encryption Key

When a Wi-Fi device establishes a connection to the HW-02G for the first time, you may need

to enter the default Service Set Identifier (SSID) and wireless network encryption key. These are

printed on the HW-02G.

To view the current SSID and wireless network encryption key on the screen:

1. Press the

About

SSID&password

the homepage.

2. The SSID and Password display on the

screen.

Getting Started

Installing a SIM Card

Caution:

Use a standard miniUIM card compatible with the HW-02G, otherwise you will damage

your HW-02G.

Charging the Battery

If the battery has not been used for an extended period of time, recharge it before use.

Note:

Only use chargers compatible with the HW-02G and provided by a designated

manufacturer. Use of an incompatible charger or one from an unknown manufacturer

may cause the HW-02G to malfunction, fail, or could even cause a fire. Such use voids

all warranties, whether expressed or implied, on the product.

The HW-02G’s charger model is HW-050100XYW. X and Y represent letters or

numbers that vary by region. For details about the specific charger model, contact an

authorized dealer.
