Huawei WS7001 Bedienungsanleitung
Contents
Quick Start Guide....................................................1
................................................15
快速入門...................................................................28
クイックスタートガイド..........................................40
Panduan Memulai Cepat................................56
1
Getting Started
Quick Start Guide
WPS/RESET button: Provides the functions of both the WPS button and the RESET
button.
WAN/LAN c port: Connects to the Internet (such as optical modem, broadband
modems, etc.) and wired network device such as a computer.
Power port
Indicator 2
3
4
1
WPS/RESET
POWER
2 43
1000M WAN/LAN
1 2 3
1
2
POWER
LAN
PON
RESET
WPS/RESET
POWER
1000M WAN/LAN
1 2 3
Step 1: Connecting the cables
Internet
Optical/Broadband/cable modem
(from your broadband provider)
•Erect the all antennas upright to ensure optimized Wi-Fi®signal.
•If the indicator stays red, this indicates that the router is not connected to the Internet.
Please refer to "Step 2: Conguring the network settings".
• For routers that support WAN/LAN auto-adaptation, the network ports are WAN/LAN
combo ports. You can also specify a xed WAN port on the router's web-based management
page.
WAN
LAN
3
1Connect your mobile phone or computer
to the router's Wi-Fi network (no
password required).
Check for the Wi-Fi name on the bottom of
the new router.
2Open the browser, you will be
automatically redirected.
(If the page is not displayed
automatically, enter 192.168.3.1).
Let's get started
Step 2: Conguring the network settings
Wi-Fi
Wi-Fi
Connected
XXXXXX Wi-Fi Name: XXXXXX
4
3Enter your broadband account and password.
If your Internet connection does not require an account and password, please skip to
the next step.
Internet access wizard
Broadband account
Broadband password
VLAN
Next
•If you have forgotten your broadband
account and password, contact your
broadband carrier to obtain a broadband
account and password.
• If you need to congure VLAN on your
network, contact your broadband carrier to
conrm the VLAN parameters, and enable
the VLAN switch on the screen.
5
4Set a new Wi-Fi name, Wi-Fi password, and admin password for the new router.
Internet access wizard
Prioritize 5 GHz
Wi-Fi network name
Wi-Fi network password
Login password
Next
Internet access wizard
Conguration complete.
Enable Prioritize 5 GHz: Priority usage of 5 GHz Wi-Fi band over 2.4 GHz band when signal
strength is equal to increase connection speeds.
Conrm password
6
Indicator
Steady green
Steady red
Flashing
Connected to the network
Not connected to the network
•Loose cable or connect error. Check the cable.
•Broadband network error. Contact your broadband carrier.
The router has detected a pairable device.
When other HUAWEI devices (support HarmonyOS Connect) are detected, the
indicator on the HUAWEI WiFi AX2 will ash. When this happens, press the
HUAWEI WiFi AX2's WPS/RESET button. The indicator should ash quickly,
indicating that the pairable device is connecting to the HUAWEI WiFi AX2.
The connection process is complete when the indicator stops ashing.
If you touched the WPS/RESET button by accident, wait for 2 minutes till the
indicator returns to normal.
Manage the router with our mobile app
Scan the QR code to download and install the HUAWEI AI Life
App on your mobile phone or tablet. You can use the app to
manage your router.
7
Frequently Asked Questions (FAQ)
Q1: What can I do if I encounter any of the following issues when conguring the router?
• If your device did not detect the router's Wi-Fi: Ensure that the router is powered on. Wait for a
moment (till the router is started) and try to search again on your device.
•If you cannot visit the router's conguration page on your device: Ensure that your device is
connected to the router's Wi-Fi network, and then enter 192.168.3.1 in the browser to visit this
page on your device.
•If the page displays "Cable disconnected": Ensure that the router's WAN port is connected to
the modem's LAN port, and the modem has Internet access. Check that all joints are securely
connected and in good contact, and the network cables are in good condition.
If the issue persists, restore the router to the factory settings, and follow the guide to reconnect the
cables and congure the router.
Q2: How do I restore the router to its factory settings?
Connect the router to the power supply and wait until the router completes the startup process.
Use a needle or pin to press the WPS/RESET button on the router for more than 8 seconds
until the indicator light goes out. Wait for the router to complete the restart process. When the
indicator turns red, this indicates that the router has been restored to its factory settings.
If the router has been factory reset, you need to congure it again.
8
Q5: What should I do if I forget my login password for the app or the router's web-
based management page?
Try using the router's Wi-Fi password to login. If the issue persists, restore the router to the
factory settings.
Q3: How do I connect an add-on HUAWEI router to my HUAWEI WiFi AX2's network?
You can connect the router in either of the following ways:
•Wired connection. Connect the WAN port of the add-on router (new or restored to factory
settings) to the LAN port of the congured HUAWEI WiFi AX2 using an Ethernet cable.
•Wireless connection. Step 1: Place the add-on router (new or restored to factory settings) within
one meter of the congured HUAWEI WiFi AX2 and connect it to the power supply. Step 2:
When the indicator on the HUAWEI WiFi AX2 starts to ash, press the WPS/RESET button on it.
Wait until the indicator on the add-on router shows it is connected to the network.
"HUAWEI router" refers to routers that support HarmonyOS Mesh+. Please check if your
device supports such feature.
Q4: How do I connect a Wi-Fi device to my router using WPS?
When your router is powered on, press its WPS/RESET button, and then press the WPS button on
the Wi-Fi device (such as a phone) within two minutes, to initiate standard WPS negotiation and
connect the Wi-Fi device to the router's Wi-Fi network.
