UPS5000 Optional BSC Card

User Manual

About This Document

Issue 02 (2019-12-10)

About This Document

Purpose

This document describes the optional BSC card for the UPS5000 in terms of its performance

specifications, appearance, structure, installation, and operation and maintenance (O&M).

Intended Audience

This document is intended for:

Sales engineers

Technical support engineers

System engineers

Hardware installation engineers

Commissioning engineers

Data configuration engineers

Maintenance engineers

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Symbol

Description

Indicates a hazard with a high level of risk which, if not

avoided, will result in death or serious injury.

Indicates a hazard with a medium level of risk which, if

not avoided, could result in death or serious injury.

Indicates a hazard with a low level of risk which, if not

avoided, could result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not

avoided, could result in equipment damage, data loss,

performance deterioration, or unanticipated results.

NOTICE is used to address practices not related to

personal injury.

UPS5000 Optional BSC Card

User Manual

About This Document

Issue 02 (2019-12-10)

iii

Symbol

Description

Supplements the important information in the main text.

NOTE is used to address information not related to

personal injury, equipment damage, and environment

deterioration.

Change History

Changes between document issues are cumulative. The latest document issue contains all the

changes made in earlier issues.

Issue 02 (2019-12-10)

Updated the sampling cable description.

Issue 01 (2017-12-04)

This issue is the first official release.

UPS5000 Optional BSC Card

User Manual

Contents

Issue 02 (2019-12-10)

Contents

About This Document ............................................................................................................... ii

1 Safety Precautions.................................................................................................................... 1

2 Optional BSC Card................................................................................................................... 2

3 Installing an Optional BSC Card ........................................................................................... 3

4 Setting BSC Card Parameters ................................................................................................. 5

5 Parts Replacement.................................................................................................................... 6

5.1 Replacing a Fuse................................................................................................................................................... 6

5.2 Replacing an Optional BSC Card........................................................................................................................... 7

6 Alarm References ..................................................................................................................... 8

A Acronyms and Abbreviations................................................................................................ 9

UPS5000 Optional BSC Card

User Manual

1 Safety Precautions

Issue 02 (2019-12-10)

1 Safety Precautions

Only professional technical personnel designated by Huawei are allowed to install and

operate the product.

High voltage operations and installation ofAC-powered facilities must be performed by

qualified personnel.

Read this document carefully before operating the product.

Before installing the product, insulate tools and remove conductors such as watches and

rings.

UPS5000 Optional BSC Card

User Manual

2 Optional BSC Card

Issue 02 (2019-12-10)

2 Optional BSC Card

An optional BSC card enables Huawei's UPS and other vendor's UPS to form a dual-bus

system.

With the optional BSC card, Huawei UPS can function as a slave device to trace the output

phases of other vendor's UPS or the phases of other 80–280 VAC power supplies in real time.

The following describes how to sample the output phases of other vendor's UPS.

Figure 2-1 Appearance

Table 2-1 Product description

Item

Description

Indicator description

POWER (green)

On: Other vendor's UPS has output.

Off: Other vendor's UPS has no output.

FAULT (red)

On: L and N wires of the sampling cable are incorrectly

connected.

Off: L and N wires of the sampling cable are correctly connected.

BSC1 and BSC2 ports

Signal ports, connected to the ECM, transmit BSC signals

L/N ports

Sampling ports, connected to the output U and N of other vendor's

UPS or other 80–280 V AC power supplies

Sampling voltage range: 80–280 V AC

Sampling frequency range: 44–66 Hz

Operating temperature

0–40°C

UPS5000 Optional BSC Card

User Manual

3 Installing an Optional BSC Card

Issue 02 (2019-12-10)

3 Installing an Optional BSC Card

Context

Figure 3-1 Sampling cable

(1) In-line spring

connector

(2) Fuse box (fuse: 400 V/1

(3) Sampling wiring

terminal

A1.5 mm2sampling cable is recommended.

Install the fuse close to the power supply to be traced. The fuse breaking capacity should be at least

20 kA.

The fuse box and sampling wiring terminal shown in the figure are for reference only. The sampling

cable length, terminal, and fuse box installation mode need to be determined based on site survey

results. The customer can also purchase and install these components by themselves.

Procedure

Step 1 Connect the ground cable for the ESD wrist strap, and put on the ESD wrist strap and ESD

gloves.

UPS5000 Optional BSC Card

User Manual

3 Installing an Optional BSC Card

Issue 02 (2019-12-10)

Step 2 Insert the optional BSC card into the control module in Huawei's UPS and secure the card.

The optional BSC card must be installed in the control module that contains a monitoring interface card.

Step 3 Verify that the output side of other vendor's UPS is de-energized. Then connect the sampling

cable and signal cables to the BSC card.

Figure 3-2 Connecting the BSC card

(1) Signal cable

(2) Sampling cable

(3) Output side of other vendor's UPS

Step 4 Power on Huawei's UPS and energize the output side of other vendor's UPS. Check that only

the POWER indicator on the BSC card is on.

----End

UPS5000 Optional BSC Card

User Manual

4 Setting BSC Card Parameters

Issue 02 (2019-12-10)

4 Setting BSC Card Parameters

Procedure

Step 1 Log in to Huawei's UPS LCD. The initial passwords for admin and operator are both 000001.

This document corresponds to the monitor display module (MDU) version V126B083D00 and is for

reference only.

Step 2 Choose System Info > Settings > System Settings, set BSC mode to Optional BSC card

mode.

----End
