Huawei E5783B-230 Technische Daten

Product Description

HUAWEI E5783B-230 Mobile WiFi

V100R001

Version 01

Date 2018-08-30

HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 2 of 21

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.

Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://consumer.huawei.com/en/

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 3 of 21

About This Document

Summary

This document introduces the major functions, supported services, and system

architecture of the HUAWEI E5783B-230 Mobile WiFi.

The following table lists the contents of this document.

Chapter Details

1 Overview Supported network modes, basic services and functions, and

the appearance of the product

2 Features Major features and technical specifications

3 Services and

Applications

Supported services

4 System

Architecture

System architecture

5 Packaging Box

Items

Items contained in the product box

6 Appendix Supported LTE bandwidths

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 4 of 21

History

Version Details Date

01 First release 2018-08-30

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 5 of 21

Contents

1 Overview..........................................................................................................................6

1.1 Introduction....................................................................................................................................... 6

1.2 Optional Features............................................................................................................................. 6

2 Features...........................................................................................................................7

2.1 Main Features .................................................................................................................................. 7

2.2 Technical Specifications ................................................................................................................... 8

2.2.1 Hardware ................................................................................................................................. 8

2.2.2 Software..................................................................................................................................11

3 Services and Applications ...........................................................................................13

3.1 Data Service................................................................................................................................... 13

3.1.1 Wireless Modem.................................................................................................................... 13

3.1.2 USB Modem .......................................................................................................................... 13

3.1.3 LTE/3G/Wi-Fi Auto Offload .................................................................................................... 14

3.2 SMS................................................................................................................................................ 14

4 System Architecture .....................................................................................................15

4.1 System Architecture ....................................................................................................................... 15

4.2 Functional Modules ........................................................................................................................ 16

5 Packaging Box Items....................................................................................................17

6 Appendix........................................................................................................................18

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 6 of 21

1 Overview

1.1 Introduction

HUAWEI E5783B-230 Mobile WiFi (hereinafter referred to as the E5783B-230) is a

high-speed packet access mobile hotspot. It is a multi-mode wireless terminal for

SOHO (Small Office and Home Office) and business professionals.

It provides users with packet data services and SMS through multiple network modes.

You can connect the micro USB port on the E5783B-230 to a computer using a micro

USB data cable, or connect multiple devices to the E5783B-230 over Wi-Fi. In the

service area of the network, the E5783B-230 allows you to surf the Internet, and

send/receive messages/emails , providing you with a fast, reliable, and convenient

user experience. It also helps carriers improve their average revenue per user

(ARPU).

Figure 1-1 shows the appearance of the E5783B-230.

Figure 1-1 E5783B-230 appearance

1.2 Optional Features

Optional features refer to features that are not supported on the standard version.

These features can be customized according to carrier or customer requirements. The

E5783B-230's optional features include the following:

SIM lock

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 7 of 21

2 Features

2.1 Main Features

The E5783B-230 features:

LTE FDD Cat4 (DL) packet data service of up to 150 Mbps

LTE FDD Cat6 (DL) packet data service of up to 300 Mbps

LTE FDD Cat4 (UL) packet data service of up to 50 Mbps

LTE FDD Cat6 (UL) packet data service of up to 100 Mbps

LTE TDD Cat4 (DL) packet data service of up to 112 Mbps

LTE TDD Cat6 (DL) packet data service of up to 224 Mbps

LTE TDD (UL) packet data service of up to 10 Mbps

DC-HSPA+ (DL) packet data service of up to 42 Mbps

DC-HSPA+ (UL) packet data service of up to 5.76 Mbps

HSPA+ (DL) packet data service of up to 21 Mbps

HSPA+ (UL) packet data service of up to 5.76 Mbps

HSDPA (DL) packet data service of up to 14.4 Mbps

UMTS (UL/DL) packet data service of up to 384 Kbps

SMS based on LTE/UMTS

Built-in LTE/UMTS and Wi-Fi antenna

2.4 GHz and 5 GHz Wi-Fi

LTE/3G/Wi-Fi auto offload

Compatible with HUAWEI SmartHome app

Plug and Play

IPv4v6 dual stack

Built-in DHCP Server, DNS RELAY, and NAT

Online software upgrade

Traffic statistics

WPS

Standard Micro USB port

Compatible with Windows 7, Windows 8, Windows 8.1, Windows 10 (excluding

Windows RT), MAC OS X 10.9, 10.10, 10.11 and 10.12 with latest upgrades

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 8 of 21

2.2 Technical Specifications

2.2.1 Hardware

Table 2-1 lists the hardware specifications.

Table 2-1 Hardware specifications

Item Specifications

Technical

standard

WAN: LTE FDD/LTE TDD/DC-HSPA+/HSPA+/HSPA/UMTS

Wi-Fi/WLAN: IEEE 802.11a/b/g/n/ac

Operating

frequency

LTE FDD: B1/B3/B7/B8/B20/B28/B32

LTE TDD: B38/B40(2300~2395MHz)

LTE CA：

UL CA：Intra-Band continuous：B3+B3,B7+B7

DL CA:

Intra-Band continuous：

B1+B1, B3+B3, B7+B7, B38+B38, B40+B40

Intra-Band non-continuous：B3+B3, B7+B7

Intra-Band：

B1+B8(B1 as PCC), B1+B20, B1+B28(B1 as PCC), B3+B7, B3+

B8, B3+B20, B3+B28(B3 as PCC), B7+B8, B7+B20, B7+B28(B7

as PCC), B20+B32(B20 as PCC), B20+B38(B20 as PCC), B1+B

See the Appendix for the supported LTE channel bandwidths.

DC-HSPA+/HSPA+/HSPA/UMTS:

Band1(2100MHz)/Band8(900MHz)

Wi-Fi/WLAN: 2.4 GHz

Wi-Fi/WLAN: 5 GHz

Memory RAM: 256 MB DDR

ROM: 256 MB NAND Flash

Transmit power

LTE: Conforms to Power Class 3 Definition

WCDMA/HSPA/HSPA+: Conforms to Power Class 3 Definition

Wi-Fi/WLAN

2.4 GHz

802.11b: 12.5 dBm

802.11g: 12 dBm

802.11n: 11(20MHz)/11(40MHz) dBm

Wi-Fi/WLAN

5 GHz

802.11a: 11 dBm

802.11ac: 10(20MHz)/9(40MHz)/9(80MHz) dBm

802.11n: 10 dBm

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 9 of 21

Item Specifications

Note: The value above represents a typical transmit power in

Wi-Fi/WLAN mode, and may vary slightly by device.

Receiver

sensitivity

LTE: Conforms to 3GPP

WCDMA/HSPA/HSPA+: Conforms to 3GPP

Wi-Fi/WLAN

2.4 GHz

802.11b: -76dBm@11Mbps/-82dBm@1Mbps

802.11g: -65dBm@54Mbps

802.11n: -64dBm@65Mbps

Wi-Fi/WLAN

5 GHz

802.11a: -65dBm@54Mbps

802.11ac: -64dBm@65Mbps

802.11n: -64dBm@65Mbps

Wi-Fi/WLAN

speed

802.11a: Up to 54Mbps

802.11b: Up to 11 Mbps

802.11g: Up to 54 Mbps

802.11n HT20: Supports MCS0–MCS7; Up to 72.2 Mbps.

Supports MCS8–MCS15; Up to 144.4

Mbps.

HT40: Supports MCS0–MCS7; Up to 150 Mbps.

Supports MCS8–MCS15; Up to 300 Mbps.

802.11ac: Up to 867 Mbps

Power

consumption

3.5 W

Charger

(Optional)

AC: 100–240 V

DC: 5 V, 1 A

Battery Type: Rechargeable lithium battery (Removable)

Capacity: 3.8 V, 1500 mAh

Maximum working hours: 6 (depending on the network)

Maximum standby hours: 350 (depending on the network)

External ports Micro USB port

micro-SIM card slot (3FF)

Indicators LED signal, battery, and SMS indicators

Buttons Power button, RESET button

HUAWEI E5783B-230 Mobile WiFi V100R001

Product Description

Version 01 ( 2018-08-30) Secret and confidential Page 10 of 21

Item Specifications

Antenna Built-in LTE/UMTS main antenna

Built-in LTE/UMTS diversity antenna

Built-in Wi-Fi/WLAN antenna

Dimensions

(W × D × H)

Mobile WiFi 108mm x 62mm x 16mm

With package 151mm x 94 mm x 66 mm

Weight Mobile WiFi Approximately 87 g (including the battery)

With package Approximately 151g

Temperature Operating temperature: 0℃to 35℃

Storage temperature: -20℃to +70℃

Humidity 5% to 95% (non-condensing)
