Huawei WS5800 Bedienungsanleitung
Contents
Quick Start Guide ................................................... 1
Guide de démarrage rapide.................................... 14
Schnellstartanleitung............................................. 27
Guida rapida ....................................................... 40
Snelstartgids ....................................................... 53
Guia de início rápido ............................................. 66
Guía de inicio rápido ............................................. 79
1
Quick Start Guide
Getting Started
1
4
6
7
8
5
2 3
NFC detection area
RESET button
Power button: Press once to power on the device, or
press and hold for at least three seconds to power it o.
WAN port: Connect to optical modems, broadband
modems, etc.
LAN port: Connect to a wired Internet device, such as a
computer.
Power port
H button Indicator
Scan the QR code to download and install the HUAWEI smart
device management app on your mobile phone or tablet.
Step 1: Install the app
If the app is already installed on your
phone, make sure you have the latest
version of the app.
2
Step 2: Connect the cables
Take out a router from HUAWEI WiFi Mesh, connect it to the
optical/broadband/cable modem using a network cable, then
connect it to a power supply.
Optical/broadband/cable modem
(from your broadband provider)
Router
Insert the cable to the
WAN port on the router
Internet
If the indicator is steady red, this indicates that the router is not
connected to the Internet. Please refer to "Step 3: Set up the
router".
POWER
RESET
WAN
LAN1
LAN2
LAN3
POWER
LA N
ADSL
RESET
LAN WAN
Step 3: Set up the router
Method 1: Congure the router on the app
Connect your mobile phone to the Wi-Fi
®of the router
connected to the modem (no password required). Check for
the Wi-Fi name on the bottom of the router.
1
WiFi
WiFi
Connected
Wi-Fi Name: XXXXXX
3
Open the app. After the app has detected the router, touch
CONFIGURE.
If the prompt box does not appear,
touch +.
2
CONFIGURE
LATER
Touch GET STARTED.
3
GET STARTED
4Enter your broadband account and password.
If your Internet connection does not require an account and
password, please skip to the next step.
Step 1
VLAN
Broadband account
Broadband password
CONNECT
If you need to congure VLAN on
your network, contact your broadband
carrier to conrm the VLAN
parameters, and enable the VLAN
switch on the screen.
4
Step 2
Wi-Fi name
Wi-Fi password
Tri-band
auto-selection
Enable Tri-band auto-selection: The 2.4 GHz and 5 GHz
Wi-Fi names will be the same. You will automatically connect
to the faster Wi-Fi network.
• Reconnect to the router's Wi-Fi to access the Internet.
• If the router cannot be congured on the app, congure the
router on the web-based management page by following the
instructions in Method 2.
Set a new Wi-Fi name, Wi-Fi password, and management
password for the new router.
5
NEXT
Connect to Wi-Fi
5
Method 2: Congure the router on the web-based
management page
Connect your mobile phone to the Wi-Fi of the router
connected to the modem (no password required). Check for
the Wi-Fi name on the bottom of the router.
1
2Open the browser and you will be automatically redirected
to the web-based management page (if the page is not
displayed automatically, enter "192.168.3.1" in the browser
address bar). Follow the onscreen instructions to congure
the router.
Let's get started
WiFi
WiFi
Connected
Wi-Fi Name: XXXXXX
6
The other router(s) in the HUAWEI WiFi Mesh is/are plug and
play.
Place the router(s) where Wi-Fi signal reception is poor, and
connect it/them to the power supply. Wait for approximately two
minutes until the indicator turns steady blue, indicating that the
router is connected to the network. You can also check their
network connection through the app.
Step 4: Connect the other router(s) to the
power supply
• For best results, place the routers within 10 meters of each other
with one wall in-between at most.
• All routers share the same Wi-Fi name and password. When you
move across rooms, you will automatically connect to the faster
Wi-Fi network.
• If a router's indicator is steady red, this means that it cannot
connect to the Internet. Please refer to "Indicator - Steady red"
below for more details.
