human care 90709 Bedienungsanleitung
User Manual
Extension Kit, Floorline LTC
90709
2www.humancaregroup.com
Content ENGLISH
User Manual 3
Compliances and Standards 4
Technical Specicaons 5
Responsibility of users 5
Safety Advice 6
Intended Use 7
Assembly/Disassembly Instrucons 8
Operaon Instrucons 12
Maintenance and service 13
Recycling 13
www.humancaregroup.com 3
ENGLISH
Symbols
WARNING symbol indicates a
potenally hazardous situaon which,
if not avoided, could result in serious
injury to the user or damage to
property and/or the device itself.
INFORMATION symbol indicates
recommendaons and informaon for
proper, trouble-free usage.
WEIGHT CAPACITY symbol indicates
maximum user weight for the product.
Do not exceed this weight in any
circumstance.
CE MARKING symbol indicates product
meets requirements of EU Direcve
93/42/EEC (MDD) and/or EU
Regulaon 2017/745 (MDR).
RECYCLE according to local regulaons.
READ INSTRUCTIONS and ensure you
fully understand them before using
this product.
Important!
You must read the user manual for the bed as well as the user manual for the
accessory prior to usage. Keep this booklet and informaon handy for future
use.
Product modicaon is not
permied.
Before use, always check that the
product is not damaged or worn.
Human Care’s products are connuously
being developed and updated to provide our
customers with the highest quality. We reserve
the right to make design changes without prior
noce.
Always make sure that you have the most
recent version of the manual which is available
for downloading from our website at
www.humancaregroup.com.
Contact your local distributor if you have any
quesons about the product and its use.
Noce to user/paent in case of serious
incident
Any serious incident that has occurred in
relaon to the product, should be reported
to the local contact, who reports to the
manufacturer, and the competent authority
of the country in which the user/paent is
established.
MEDICAL DEVICE symbol indicates
that the product is a medical device
according to the denion of
medical device in EU Direcve 93/42/
EEC (MDD) and/or EU Regulaon
2017/745 (MDR).
User Manual
4www.humancaregroup.com
Extenon Kit, Floorline LTC
Human Care is an ISO 13485:2016 cered
Swedish medical device company. The Quality
Management System is in compliance with US
21 CFR part 820.
The product is CE marked in accordance with
EU Direcve 93/42/EEC (MDD) and/or EU
Regulaon 2017/745 (MDR), as class I medical
device.
The CE mark is on the product.
This bed complies with all requirements
of the IEC/ISO Internaonal Standards: IEC
60601‐2‐52:2009
Compliances and Standards
This User Manual informs you, as the operator,
and your users, about the product features,
assembly and operang funcons necessary
to ensure ease of operaon, and safe handling
of this product in its normal and expected
environment.
You should therefore also regard this User
Manual, as a praccal reference book, to be
kept near the product and readily available
at all mes, for anyone involved in its use or
operaon.
Is a warning triangle used for situaons which
require extra care and aenon.
CAUTION!
Do not assemble or operate the bed accessory,
before reading this manual, as personal injury
or damage to product may occur!
Please contact Human Care in the event
of any uncertaines or quesons.
Product lifeme
The product´s expected lifeme is ten (10)
years, if the product is used as intended and
maintained according to the manufacturer´s
instrucons, depending on the intensity of use
and maximum load applied during use. If the
product label is no longer legible, the product
should be discarded.
www.humancaregroup.com 5
ENGLISH
Technical Specicaons
Responsibility of users
Instrucons for the operator:
Please pay aenon to your obligaons, as the
operator, in order to ensure the permanently
safe operaon of this medical product,
minimising risks to the paent, user and/or
third pares.
Any piece of technical equipment, electrical or
otherwise, can prove hazardous, if not properly
operated and maintained in accordance with its
User Manual. It is recommended that you are
informed of all operaons and perform regular
maintenance on equipment.
Denions:
Operator
(e.g.: clinic, hospital, hospital management,
nursing home), is every natural or legal person
with property rights over the bed (including
when subject to hiring, rental or lease
arrangements).
Responsibility for the safe operaon of
this bed accessory lies with the operator.
User
(specialist medical sta, nurses, doctors,
aendants and care sta) are persons who,
on the basis of their training, experience or
thorough instrucon, are entled to operate
the bed on their own responsibility, or to carry
out work on it, or who have received instrucon
in the handling of this bed. Furthermore, they
are able to recognize and avoid possible hazards
as well as assess the clinical condion of the
paents.
Paent, Resident or Guest
In this manual, a paent is described as any
person being ill, inrm, disabled, in need of
care, or otherwise occupying this bed.
Each me the bed accessory is allocated, it is
recommended that the paent is instructed in
all the funcons that are important for him/her,
by the operator or user.
Specifications (cm / inch)
Extension of bed 17,5 cm / 7.0”
6www.humancaregroup.com
Extenon Kit, Floorline LTC
Safety Advice
Safety Symbol
In this manual the adjacent safety warning
symbol is shown as:
This safety symbol does not
replace all the wrien safety
advice. You are instructed to read the
safety advice and follow it precisely.
Safety for the operator
With the aid of this manual, which must be
handed over together with the product, you
must ensure that every user is instructed in the
safe operaon of the product before it is put
into service for the rst me.
Draw every user’s aenon to the possible
hazards that can arise if the product is not used
properly.
Pay aenon to your obligaons in order to
ensure the permanently safe operaon of this
product to minimise all risks to the paent, user
and/or third pares.
Regular preventave maintenance is the
Operator’s responsibility.
Only allow this product to be used by persons
who have been instructed in its safe operaon.
Make sure that stand‐in or temporary sta are
suciently well instructed in the safe operaon
of the product.
Safety advice for the user
Make sure that the operator instructs you in the
safe operaon of this product.
Each me, before using the product, check that
it is in perfect working order.
Make sure that there are no obstacles (eg:
bedside lockers, chairs, hoists, wall mounted
xtures, or equipment etc.) which could impede
any adjusng or movement of the bed.
www.humancaregroup.com 7
ENGLISH
Intended Use
The Extension Kit, Floorline LTC, is used to
extend the bed plaorm with 17,5 cm/7.0” for
taller paents.
Accessory intended for the following Floorline Beds
This accessory should only be used with
Floorline models from Human Care with the
following arcle numbers.
It is important that only Human Care accessories
are ed to Human Care beds, as any incompable
accessories can create hazards.
Product Name Article Number
Floorline LTC EU 90600
Floorline LTC EU wooden panel 90601
Floorline LTC UK 90602
Floorline LTC UK wooden panel 90603
Floorline LTC US class 1 90606
Floorline LTC US class 1 wooden panel 90607
Floorline LTC AU 90608
Floorline LTC AU wooden panel 90609
8www.humancaregroup.com
Extenon Kit, Floorline LTC
Assembly/Disassembly Instrucons
Content:
Number Descripon Qty.
1 Extension Brackets 2
2Extension Maress Plaorm Panel 1
3Extension Panel Plaorm Bolts/Nuts 4
Extension Kit, Floorline LTC ‐ 90709
1
2
3
www.humancaregroup.com 9
ENGLISH
Extension Kit
The sleeping space of the bed is extended by
175mm (7”) with the addion of this kit. A
bolster maress is available, measuring 175mm
(7”) long by 900mm (35”) wide and 125mm (5”)
deep.
The standard length of the FloorLine LTC
bed’s maress platorm is 2000mm (783/4 ”)
measured internally between the head and foot
pedestal ends (sleeping space).
The extension kit will lengthen the sleeping
space by 175mm (7 ”) to 2175mm (851/2 ”) to
accommodate taller people. The overall bed
length also extends.
At the foot end of the maress plaorm beams,
extension brackets will replace the standard
brackets and an addional maress plaorm
panel is ed over the extension brackets.
Required Tools
• A Mains Power Outlet/Power‐Point
• A 4mm & a 5mm Allen Key
• A 10mm & 13mm Spanner/Socket Wrench
• A 100mm2 Wood Block to support frame
• A Penknife
Qualified assembly persons must be very
familiar with this User Manual and all
facets of bed assembly and operation.
Fing the extension kit
1. Conrm the kit’s contents.
2. Clear sucient space to conduct
installaon and remove the maress and
any side rails from the bed.
3. Ensure all castors are aligned and locked
under the outrigger castor beam.
4. Posion the Wood Block directly under
the kneebreak actuator cross beam. This
will support the main bed frame when
the
5. Conrm that mains power is connected.
6. Using the handset, aen out/neutralise
the bed funcons (Backrest, Kneebreak,
Trendelenburg posions).
7. Lower the bed carefully down onto the
wood block. The foot end wheel castors
should just gently li o the oor.
8. Unplug the mains power cable from the
from the wall and keep cable safe.
9. Li the kneebreak panel for easy access
to the Liing Actuator Cable, the Stepped
Pivot Bolts and Countersunk Bolts.
10. Using a penknife, carefully remove the
white plasc retaining clip, from the Foot
End Actuator Mini‐Fit Connector.
NOTE: Do not lose retaining clip!
11. Disconnect the foot end li actuator cable
from its Mini‐Fit Connector.
10 www.humancaregroup.com
Extenon Kit, Floorline LTC
Do not use handset again unl foot end
actuator is re-connected electrical
damage may occur!
12. Loosen but DO NOT REMOVE the two foot
end Bracket Stepped Pivot Bolts (4mm
Allen key) and their Nyloc Nuts (10mm
spanner).
13. Remove the 2 Foot End Bracket Nyloc Nuts
(13mm spanner) and Countersunk Bolts
(5mm Allen key).
14. Return the kneebreak panel back into
place.
15. Carefully fold the Foot End Pedestal at
onto the maress platorm.
16. Now remove the two Foot End Bracket
Stepped Pivot Bolts.
NOTE: Keep all nuts, bolts and washers
safe.
17. Carefully li and move Foot End Pedestal
away from the bed frame, to a safe place,
away from work area.
18. Li the kneebreak panel again for easy
access to the Plaorm Bolts on the end of
the maress plaorm beams.
19. On one side of the bed, remove the 4 x
Foot End Plaorm Nyloc Nuts (13mm
spanner) on the Plaorm Bolts that aach
the standard bracket to the maress
plaorm beam.
Do not remove the plaorm bolts.
20. Remove the standard bracket and t the
new extension bracket, onto the bolts.
Keep extension bracket support tab to the
under side of frame.
Inhaltsverzeichnis
Andere human care Mobilitätshilfe Handbücher
human care
human care NeXus 3 Gebrauchsanweisung
human care
human care neXus Gebrauchsanweisung
human care
human care Carl-Oskar Bedienungsanleitung
human care
human care 93310 Bedienungsanleitung
human care
human care Fellow Classic Bedienungsanleitung
human care
human care 43211 Bedienungsanleitung
human care
human care 90705 Bedienungsanleitung
human care
human care Staffan RA Gebrauchsanweisung
human care
human care 4200LX Bedienungsanleitung
human care
human care Altair Bedienungsanleitung
human care
human care Fellow Classic Bedienungsanleitung
human care
human care 90706 Bedienungsanleitung
human care
human care Fellow Classic Bedienungsanleitung
human care
human care NeXus 3 Bedienungsanleitung
human care
human care Rebel Bedienungsanleitung
human care
human care NSB-401 Bedienungsanleitung
human care
human care Carl-Oskar Bedienungsanleitung
human care
human care Carl-Oskar RA Gebrauchsanweisung
human care
human care NSB-103 Bedienungsanleitung
human care
human care Carl-Oskar Bedienungsanleitung
Beliebte Mobilitätshilfe Handbücher anderer Marken
Rhythm Healthcare
Rhythm Healthcare B3800F Bedienungsanleitung
AMF-BRUNS
AMF-BRUNS PROTEKTOR Bedienungsanleitung
Drive DeVilbiss Healthcare
Drive DeVilbiss Healthcare OTTER Bedienungsanleitung
Rhythm Healthcare
Rhythm Healthcare C500U Bedienungsanleitung
Lumex
Lumex RJ4200A Bedienungsanleitung
Rebotec
Rebotec Jumbo Bedienungsanleitung
