USE AND CARE GUIDE

5 DRAWER TOOL CABINET

Item #

Model # H5TR2LEC

8 a.m – 7 p.m., EST, Monday-Friday

9 a.m – 6 p.m., EST, Saturday

1-888-HD-HUSKY

HUSKYTOOLS.COM

.............. 3Alternative Tools For Assembly (Not Included)

Table of Contents

Table of Contents..................................................2

Safety Information ...............................................2

Warranty ................................................................3

Specifications ........................................................3

Package Contents..................................................3

Hardware Included ........................................................... 3

Assembly ...............................................................5

5............................... ...................................

ecnanetn

iaM

6.........................................................

Operation

.................................................6

Care and Cleaning

Safety Information

1. Do not pull this unit, push it when moving.

2. Use the brakes when this product is not being

moved. This prevents the product from rolling.

3. Secure this product properly before moving it with a

forklift.

4. Do not tow the product with power equipment.

5. Do not alter this product in any manner. For

example, do not weld external lock bars or attach

electrical equipment.

6. When locking a cabinet, close the drawers completely

in order for the rear

Do not attach or mount this

product to a vehicle. This may cause personal

injury or product damage. Mounting this

product to any vehicle in any manner will void

warranty.

Do not stand on this product. You

may fall which may cause personal injury.

Be careful when opening more than

one drawer. The product may become unstable

and tip, which may cause personal injury or

product damage.

CAUTION: Keep the product on level surfaces.

The product may become unstable and tip if

stored or moved on an unlevel surface, which

may cause personal injury or product damage.

CAUTION:

Lock the drawers before moving

this product. The drawers could come open and

make the product unstable and tip, which may

cause personal or product damage.

lock bars to work properly.

Wrench

HUSKYTOOLS.COM

3 Please contact 1-888-HD-HUSKY for further assistance.

Warranty

Specifications

Casters support up to 1000 lbs.

NOTE: Begin product assembly close to t nal

intended location of your cabinet. This product is

heavy and may be di cult to move after assembly.

)rewardtenibac(repthgiewmumixaM 100 lbs.

Package Contents

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.

Part Description

M8 x 25 bolt

M6 x 16 bolt

Quantity

AA BB CC

The manufacturer warrants the product to be free from defects in materials and workmanship for a period of three (3) years from date of

purchase. This warranty applies only to the original consumer and only to products used in normal use and service. If this product is found to

be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s

mishandling.

This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way not in accordance with

the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse,

negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not apply to

ar purpose,

consequential

or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.

Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.huskytools.com.

ALTERNATIVE TOOLS FOR ASSEMBLY

(Not Included)

*10 mm wrench or socket

*12 mm wrench or socket

Package Contents (continued)

NOTE:

Part Description Quantity

Cabinet 1

Cabinet handle 1

Swivel caster

Fixed caster

The keys are taped to the top of the

unit.

Assembly

Attaching the cabinet handle

Position the cabinet handle (B) over the holes on the

cabinet (A).

Attach with the bolts (BB) and tighten with supplied

wrench (CC) or 10mm wrench/socket.

NOTE:

The holes in the cabinet are tapped and do not

require nuts.

HUSKYTOOLS.COM

5 Please contact 1-888-HD-HUSKY for further assistance.

Attaching the casters

□Be sure the drawers are locked and lay the cabinet (A)

□emasehtno,tinuehtot)D(sretsacleviwsehthcattA

side as the handle, inserting bolts (AA) through the swivel

casters(D) and into the cabinet (A).

□Tighten with supplied wrench (CC) or 12 mm wrench/socket.

□Repeat this process for the xed casters (C) on the

opposite side of the cabinet (A).

□Return the cabinet (A) to its upright position.

CAUTION: Do not over tighten the bolts.

Operation

Removing the drawers 2

Re-inserting the drawers

Fully extend the empty drawer.

□

elihwrevelesaelerenoehtpuhsuP pulling

down on the other release lever.

□Pull the drawer outward until it is released from the

drawer slide.

Extend the drawer slides.

□

Insert the brackets on each side of the drawer into

the slots in the slides, being careful that they are

properly positioned.

□Once properly inserted, completely close the drawer

to set the slides in their proper positions.

Care and Cleaning

□Periodically clean the drawer fronts, drawer trim, and other surfaces with a mild detergent and

water.

□

Maintenance

1 Caster maintenance 2 Drawer maintenance

□Grease the casters annually using high-quality

bearing grease.

□Lubricate the slides semi-annually.

Questions, problems, missing parts? Before returning to the store call

Husky Customer Service

8 a.m. - 7 p.m., EST, Monday-Friday

9 a.m. - 6 p.m., EST, Saturday

1-888-HD-HUSKY

HUSKYTOOLS.COM

Retain this manual for future use.
