I3 International Ax41C1M Bedienungsanleitung

Ax41C1M 1MP Network Camera

•PARTS' LOCATIONS AND FUNCTIONS

Connector 24V AC 12V DC

Red 24V AC Positive

White 24V AC Negative

SD card slot

Reset Button

Audio In(Port 4)

Audio Out(Port 6)

Power(White:-/Red:+)

RJ-45 Network Connection

Update Fireware Before Use

CAUTION

-Ensure the network connection and power

supply are all connected while updating

ﬁ rmware.

-Ensure to udpate the kernal ﬁ rmware ﬁ le

ﬁ rst and then the application ﬁ rmware ﬁ le.

-Ensure that the power supply correctly

connects to the +/- terminal.

Please read this manual thoroughly before using, and keep it handy for future reference.

Quick Start Guide

Security level settings

How to Change Security options in your browser

1. From the Tool menu, select Internet options.

2. Click on the Security tab.

3. If the camera is on the INTRAnet Click the Local intranet icon,

If the camera is on the INTERnet click the Internet icon.

4. Click on Custom level.

5. Check the following radio buttons in the display list:

Under ActiveX controls and plug-ins

* Enable "Download signed ActiveX controls"

* Enable "Run ActiveX control and plug-ins"

* Enable "Script ActiveX controls marked safe for scripting*"

6. Click OK.

Assigning an IP address

1. The network camera is designed to be used on an Ethernet network. The

camera is set to use the default IP address of 192.0.0.16. If your

network supports DHCP, you will need to enable this feature from the

camera network settings.

2. To connect to the camera, the PC needs to be on the same IP address

range as the camera (ie. if the camera is 192.0.0.16 then the PC must

be 192.0.0.10) the last digits on the PC IP address needs to be different

from the last digits on the cameras IP address.

3. To make sure you can connect to the camera with your PC, ping the IP

address you set. Open command prompt and type the IP address you

set. If the message of “Reply from…” appears, it means communication

is established.

4. Start a browser and enter the IP address: http://192.0.0.16, a pop-up

window will appear and will require you to login. Enter the default user

name: admin and password: 1234 to login.

5. Please install the ActiveX viewer that is required to monitor H.264,

MPEG4 and M-JPEG video modes.

6. Images of the camera can be viewed through your web browser IE V.6.0

& up. Before viewing, you have to follow the steps below.

Ax41C1M 1MP Network Camera

QUICK STA RT GUIDE

i³ INTERNATIONAL INC.

1.866.840.0004

www.i3international.com

Canada 780 Birchmount Road,

Unit 16, Scarborough,

ON, M1K 5H4

U.S.A. 440 Lawrence Bell Drive,

Suite 16, Williamsville

NY, 14221

This function is designed to update firmware. Stop all camera operations when you

update firmware. Do not turn off power or disconnect the internet connection during the

firmware update process. Click “Restart Camera” after you have updated firmware suc-

cessfully.

• Restart Camera – The camera is restarted without changing any settings. Typically used after

updating fir ware. After clicking, a pop up will appear asking you to confirm. Click Yes.

• Factory Default – Resets the camera to factory settings but keeps the Network settings. After

clicking, a pop up will appear asking you to confirm. Click Yes.

• Hard factory default – Resets the camera to factory settings and will cause all parameters

(including the IP address) to be reset. After clicking, a pop up will appear asking you to confirm.

Click Yes.
