EF 450 Series

Flake ICE Maker

EF 450

Problem

ICE-O-Matic®Tough

Constructed with a brass evaporator and rugged stainless

steel transport system enclosed in polyurethane insulation

Multiple Solutions

Storage of 143 pounds, 213 pounds

or 315 pounds of flaked ICE

ICE-O-Matic ®is the Best ICE Making Solution for:

Hard Water, Food Safety and Tight Spaces

Solution

Operating Environments

Built to last?

Optimal Bin Storage

Bin not large enough?

Tight-Fitting Spaces

Kitchen space utilization

✓

Produces up to 472 lbs. (215 Kgs.)* of ICE per day

✓Self-contained insulated storage available in 143 lbs.

(65 Kgs), 213 lbs. (97 Kgs.) or 315 lbs. (143 Kgs.)

✓Constructed from sturdy, corrosion-resistant

300 series stainless steel

✓ Ultra-low profile - 41 inches (1041 mm) tall

✓Available with an air-cooled condenser

*Rated at 70 ° (21°) Air / 50° (10°) Water

Maximum ICE

Maximum ICE production in a minimum amount

of space with an ultra-low profile:

• 41 inches tall

• Air intake only on one side

• Choice of 32, 38 or 48 inches wide

Dirty Air Filter

Forget to change the air filter?

Filter-Free Air

No air filter to change

EF450A32S 32 (813) 143 (65) Air 472 (215) 361 (164) 12.0 (45) n/a 5.8 5261 115/60/1 3 14.2 15 250 (114)

EF450A38S 38 (965) 213 (97) Air 472 (215) 360 (164) 12.0 (45) n/a 5.8 5261 115/60/1 3 14.2 15 260 (118)

EF450A48S 48 (1219) 315 (143) Air 472 (215) 360 (164) 12.0 (45) n/a 5.8 5261 115/60/1 3 14.2 15 300 (136)

Please note: air-cooled units require 6” (152 mm) clearance for air intake and exhaust.

Water Used-Gals. (Lits.) Kilowatts

ICE Production ICE Production per 100 lbs. of ICE Used per

Application per 24 hrs. at per 24 hrs. at 90° Air/70° Water 100 lbs. of ICE Min. Max. Shipping

Model Cab Size Bin Storage Cond. 70° Air/50° Water 90° Air/70° Water 90° Air Voltage No. of Circuit Fuse Weight

No. Width ”(mm) Lbs. (Kgs.) Unit lbs. (Kgs.) lbs. (Kgs.) 70° Water Btuh Characteristics Wires Amp. Size lbs. (Kgs.)

ICE Prod. Cond.

Use Use

60 Hz

ORDERING AND SPECIFICATION INFORMATION

EF 450

Conds. Air Temp. Water Temp. °F (°C)

Unit °F (°C) 80°(27°) 70°(21°) 50°(10°)

90° (32°) 335 (152) 360 (164) 405 (184)

80° (27°) 371 (168) 399 (181) 438 (199)

70° (21°) 399 (181) 429 (195) 472 (215)

All specifications and performance data

are subject to normal manufacturing variances.

ICE PRODUCTION CHART POUNDS

(KILOGRAMS) PER 24 HOURS

Air

Cooled

EF 450 Series Flake ICE Maker Self-Contained

OPERATING LIMITS

Ambient Temp. Range

Air & Water 50° - 110°F (10° - 43°C)

Water Temp. Range 40° - 100°F (4.5° - 38°C)

Water Pressure Ice Maker Min. 20 psi (1.4 bar)

Water in Max. 60 psi (6.9 bar)

Condenser Inlet Water Min. 20 psi (1.4 bar)

(Water cooled only) Max. 60 psi (6.9 bar)

We reserve the right to make changes in design and construction at any time

without obligation.

2003© ICE-O-Matic Rev Code: 2001A-07/03-SS

ICE-O-Matic 11100 E. 45th Avenue, Denver, CO 80239

Tel. 303 371-3737 Fax. 303 371-6296 www.iceomatic.com

28"

(711mm)

ää

1.50"

(38mm)

Electrical Inlet

Icemaker Water Inlet

" FPT

Condenser Water Inlet

" (10mm) O.D. Copper Tubing

(Water Cooled)

Condenser Drain

" (10mm) O.D. Copper Tubing

(Water Cooled)

Drain

" (13mm) I.D. Plastic Tubing

27"

(686mm)

32.25"

(819mm)

24"

(610mm)

1.75"

(45mm)

(76mm)

6.75"

(172mm)

(203mm)

(19mm)

Bin Drain

" (19mm)-

14 F.P.T.

35"

(889mm)

41"

(1041mm)

32"

(813mm)

6" (152mm)

to 7" (178mm)

Adj. Legs

32” front view 32” back view

32”, 38”, 48” side view

27"

(686mm)

Bin Drain

" (19mm)-

FPT

(76mm)

6.75"

(172mm)

(203mm)

27"

(686mm)

32.25"

(819mm)

(19mm)

1.75"

(45mm)

32"

(813mm)

Bin Drain

"(19mm)

-FPT

27"

(686mm)

32.25"

(819mm)

(19mm)

1.75"

(45mm)

(76mm)

6.75"

(172mm)

(203mm)

38” front view 38” back view

48” front view 48” back view

➤

32"

(813 mm)

Dimensions and Air Flow

Air in-

Left side of icemaker

28”

(711 mm)

32” Width

41"

(1041 mm)

Air out -

front of icemaker

38"

(965mm)

35"

(889mm)

41"

(1041mm)

6" (152mm)

to 7" (178mm)

Adj. Legs

38” Width

➤

38"

(965 mm)

Air in -

Left side of ICE Maker

28”

(711 mm)

41”

(1041 mm)

Air out -

front of ICE Maker

48"

(1219mm)

6"(152mm)

to 7" (178mm)

Adj. Legs

35"

(889mm)

41"

(1041mm)

48” Width

➤

48"

(1219 mm)

Air in -

Left side of ICE Maker

28”

(711 mm)

41”

(1041 mm)

Air out -

front of ICE Maker
