MFI2406 - Remote Low Side Flake Ice Maker

Rev: A-09/08

Part: 7013

MFI2406 Remote Low Side Flake Ice Maker

MFI2406 - Remote Low Side Flake Ice Maker

MFI2406 on B100

Features

•High capacity 42" (1067 mm) wide design.

•Remote low side unit

•Produces up to 2365 lbs (1072kg) of ice perday.

• Load Monitoring System constantly checks workload on gearbox — shutting

down system before a problem develops and preventing costly repairs.

•Water sensor eliminates low or no water failures and cannot

be affected by adverse water conditions.

•Rugged stainless steel evaporator and auger ensures reliability.

•Industrial-grade roller bearings and heavy duty gearbox

provide years of trouble free service.

Options & Accessories

Water Filters

Ice Machine

Model

Manifold Inline

System Replacement System

MFI2406 IFQ2 IOMQ (2) N/A

Ice Maker Warranty

Every Ice-O-Matic ice maker is backed by a warranty that provides

both parts and laborcoverage.

Parts & Labor

•Three years Parts and Labor.

•Five years Parts on compressor.

Ice Form

FLAKED ICE

Bin Chart

Kits for Combining Wider Bins with Smaller Models

Ice Storage Bins

ModelNo.

Capacity

Width

B25

255lbs(116kg)

30in(762mm).

B40

365lbs(165kg)

30in(762mm)

B42

374lbs(170kg)

22in(559mm)

B55

556lbs(252kg)

30in(762mm)

B100

927lbs(420kg)

48in(1219mm)

B120

1193lbs(541kg)

48in(1219mm)

B150

1499lbs(679kg)

60in(1524mm)

B170

1866lbs(846kg)

60in(1524mm)

Kits

MFI12406LS N/A N/A N/A N/A KBT26 KBT26 N/A N/A

*MFI Flakers are available internationally only.

*See Ice-O-Matic Price List for Adapter Kits to combine ice makers with most available ice/beverage dispensers.

ISO 9001 Certied

MFI2406 Remote Low Side Flake Ice Maker

11100 E. 45th Avenue

Denver, CO 80239

Phone: 1. 866. PURE. ICE

Fax: 303. 371.6296

www.iceomatic.com

Rev: A-01/09

Part: 7013

MFI2406 Remote Low Side Flake Ice Maker

Low Side Remote

A. Ice maker potable water in, ⁄" Male Flare

B. Drain, ¾" FPT.

C. Hole for electricalconnection.

D. Remote liquid inlet, ½" (12.7 mm) O.D.

E. Remote suction connection ⁄"

(22.23 mm) O.D.

42"

(1067 mm)

24"

(610 mm)

27" (686 mm)

27"

(686 mm)

18.80"

(478 mm)

9.43"

(240 mm)

21.66"

(550 mm)

20.84"

(529 mm)

5.25"

(133 mm)

3.00"

(76 mm)

12.43"

(316 mm)

15.53"

(394 mm)

17.80"

(452 mm) A. C.

D. E.

Rear View

Operating Requirements

Minimum Maximum

AmbientTemp. Range Air 50˚F (10˚C) 100˚F (38˚C)

WaterTemp. 40˚F (4.4˚C) 100˚F (38˚C)

Water Pressure 20 PSIG (1.4 BAR) 120 psig (8.3 BAR)

Dimensions

All Models

W x D x H (inches) 42 x 24 x 27

W x D x H (mm) 1067 x 610 x 686

Note: Requires a R404 refrigeration system of 12,000 Btu/h

Specifications

Model Number Cond. Unit

Ice Production

per 24hrs

Water Usage

gallons per 100 lbs of Ice

90°F air/70°F water kWH Used

per 100 lbs

of ice @

90°F air/

70°F water

Voltage

Characteristics

Min.

Circuit

Ampacity

Fuse

Size

Approx.

BTUs

per hour

70°F air/

50°F water

lbs (kg)

90°F air/

70°F water

lbs (kg)

Potable Condenser

MFI2406LS Remote

Low Side 2,365 (1,072) 2,000 (907) 12.0 3.26 208-230/60/1 2.7 15 12,000

NOTES:

Number of Wires: 3 (including ground)

Approx. Shipping Weight lbs (kg): MFI2406LS 255 (115)

Refrigerant Type: R404A
